100kw Natural Gas Generator for Sustainable Electricity Solutions No. of Cylinders 6 Piston Stroke 135mm Start Type Motor Start
1 Piece
$3,0001 Piece
$4,500Product information
High-quality 100kw Natural Gas Generator for Sustainable Electricity Solutions No. of Cylinders 6 Piston Stroke 135mm Start Type Motor Start supplied by Shandong Shengtang Power Equipment Co., Ltd.. Bulk wholesale pricing ranges from $3,000 to $4,500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Power Factor:
0.8
Minimum Order Quantity:
1 Piece
Specification:
100GF
Compression Ratio:
11.5:1
Cylinder Bore:
126mm
Model NO.:
12V190
Piston Stroke:
135mm
Rated Speed:
1500rpm/1800rpm
Specifications
Power Factor:
0.8
Minimum Order Quantity:
1 Piece
Specification:
100GF
Compression Ratio:
11.5:1
Cylinder Bore:
126mm
Model NO.:
12V190
Piston Stroke:
135mm
Rated Speed:
1500rpm/1800rpm
Rated Current:
180A
Production Capacity:
3000 Sets Per Year
Rated Volt:
400V
Rated Frequency:
50/60Hz
No. Of Cylinders:
6
HS Code:
85022000
Displacement:
9.726L
Output Type:
AC Three Phase
Origin:
China
Model No.:
Cm100r10n
Natural Gas Engine Model:
Cmr6126nz
Trade Term:
FOB
Alternator Model:
Henjo
Trademark:
Jichai
Exhaust Temp Before Turbo:
Less Than 650 Degrees
Start Type:
Motor Start
Payment Term:
To be discussed
Transport Package:
Wooden Box
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Product descriptions from the supplier
| Product Description |
|
1. Main structure of the natural gas generator set
These natural gas-powered generator units consist of biogas-driven piston engines, alternators, electrical components, management systems, heat dissipation units, oil circulation mechanisms, emission systems, fuel delivery units, and supporting hardware. All components, save the exhaust pipe and muffler within the emission system, are secured onto a steel frame. The unit is a permanently installed, stationary power system. The steel base structure is fastened to a concrete base.
2. Main structure of the biogas engine
The gas fuel of this engine series can be natural gas, biogas, syngas, coal mine gas, and etc. In order to meet the requirements of different customers, this gas engine can be packaged into generating set or other power take-off. 3. Alternator These brushless, voltage-stable synchronous generators feature a self-excited design with an electronic voltage regulator built into the excitation setup. They serve as primary or backup power sources in terrestrial power setups and marine electrical networks and are powered by diesel, gas, steam, hydro turbines, and electric motors. Structure: The alternator includes the primary generator and its excitation setup. The primary generator features a rotating magnetic field, using a cylindrical rotor and a damper winding. The exciter is an armature-type rotating machine. Power from the exciter is transmitted to the main generator's rotor through rotating rectifiers. 4. Genset control panel The gas generator's control unit is built as a enclosed cabinet housing a control system, multiple display devices, adjustment switches, safety alerts, and an emergency stop function to track generator performance. Power output is managed via an electronic speed regulator, with precise adjustments available using the panel’s control buttons. Generator voltage is set automatically using the panel’s dedicated buttons. |
| Genset Specification | |
| Model | CM100R10N |
| Diesel engine model | CMR6126NZ |
| Alternator model | Henjo |
| Control panel | Smartgen |
| Rated power (kW) | 100 |
| Rated voltage (V) | 400 |
| Rated frequency (Hz) | 50/60 |
| Power factor | 0.8 |
| Connection mode | Three-phase four-wire, star connection |
| Protection class | IP23 |
| Insulation class | H |
| Voltage steady-state adjusting rate (%) | ±2.5 |
| Voltage transient-state adjusting rate (%) | -15~+20 |
| Voltage stable time (S) | 1.5 |
| Voltage fluctuation rate (%) | 0.5 |
| Voltage regulation range (%) | 95-105 |
| Frequency steady-state adjusting rate (%) | 5 |
| Frequency transient-state adjusting rate (%) | ±10 |
| Frequency stable time (S) | 7 |
| Frequency fluctuation rate (%) | 0.5 |
| Dimension L*B*H (mm) | 2650x1000x1500 |
| Net weight (Kg) | 2000 |
| Genset Specification | |
| Model | CM100R10N |
| Diesel engine model | CMR6126NZ |
| Alternator model | Henjo |
| Control panel | Smartgen |
| Rated power (kW) | 100 |
| Rated voltage (V) | 400 |
| Rated frequency (Hz) | 50/60 |
| Power factor | 0.8 |
| Connection mode | Three-phase four-wire, star connection |
| Protection class | IP23 |
| Insulation class | H |
| Voltage steady-state adjusting rate (%) | ±2.5 |
| Voltage transient-state adjusting rate (%) | -15~+20 |
| Voltage stable time (S) | 1.5 |
| Voltage fluctuation rate (%) | 0.5 |
| Voltage regulation range (%) | 95-105 |
| Frequency steady-state adjusting rate (%) | 5 |
| Frequency transient-state adjusting rate (%) | ±10 |
| Frequency stable time (S) | 7 |
| Frequency fluctuation rate (%) | 0.5 |
| Dimension L*B*H (mm) | 2650x1000x1500 |
| Net weight (Kg) | 2000 |
| Natural Gas Engine Specification | |
| Model | CMR6126NZ |
| Rated power (kW) | 120 |
| Speed (rpm) | 1500 |
| Idle speed (rpm) | 700 |
| Type | Four-stroke, turbocharged, inlet air cooling, spark ignition,external-mixing electronic control |
| No. and layout of cylinders | 6 in line |
| Cylinder bore (mm) | 126 |
| Piston stroke (mm) | 135 |
| Displacement (L) | 9.726 |
| Compression ratio | 11.5:1 |
| Heat consumption (kj/kWh) | ≤9500 |
| Oil consumption (g/kWh) | ≤0.8 |
| Exhaust temp before turbine (ºC) | ≤650 |
| Water temperature (ºC) | ≤85 |
| Oil temperature (ºC) | ≤90 |
| Lubricating | Press and spray lubrication |
| Cooling method | Pressurized water cooling |
| Start mode | Air motor or electric motor |
SHANDONG SHENGTANG Power Equipment Co., Ltd. specializes in distributing and enhancing generator systems, such as biogas, natural gas, and diesel-powered units, among others.
Advantages:
We boast a highly skilled and experienced professional repair team capable of efficiently addressing various equipment issues while offering comprehensive diagnostic and repair services. Whether it's routine equipment maintenance or troubleshooting and repairing complex faults, our team leverages professional expertise and a meticulous approach to restore equipment to optimal operating conditions, minimizing downtime and ensuring maximum productivity for our clients.
Currently, our global service network covers multiple regions across Asia, Europe, and North America, ensuring prompt and efficient technical support for clients worldwide.
Q1: Do you offer guarantee for the products?
A: Yes, we offer 12 month years warranty to our products.
Q2. Is it OK to print my logo on diesel generator sets product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on .
Q3. How to proceed an order for diesel generator set?
A: Firstly let us know your requirements or application.
Secondly We provide solution according to your need.
Thirdly customer confirms the detail specs of the order, and arrange pay the deposit.
Fourthly We arrange the production after payment received.
Q4. How do you ship the goods and how long does it take to arrive?
A: Normally by sea shipping .Shipping time depends on distance.
Q5: How to deal with the faulty?
If any spare components fail due to non-human factors during the warranty period, we will supply the required parts to you, or you may purchase them directly from our generator set inventory. We offer continuous online technical assistance. Should you encounter operational issues with your generator, our qualified technical experts can visit your site to provide on-site guidance and resolve the problem.
