24/26/28DHA Fine Wire Drawing Machine
Piece
Negotiable
Product information
High-quality 24/26/28DHA Fine Wire Drawing Machine supplied by Dongguan Wirecan Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Outlet Diameter:
0.1-1.2mm
Package Size:
1680.00cm * 1310.00cm * 1350.00cm
Production Capacity:
20 Sets/Month
Max. Number Of Block:
21
Max.Inlet Wire Dia.:
3.6mm
Package Gross Weight:
500.000kg
Block Dia.:
600mm
Origin:
China
Specifications
Outlet Diameter:
0.1-1.2mm
Package Size:
1680.00cm * 1310.00cm * 1350.00cm
Production Capacity:
20 Sets/Month
Max. Number Of Block:
21
Max.Inlet Wire Dia.:
3.6mm
Package Gross Weight:
500.000kg
Block Dia.:
600mm
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Metal Material:
Copper
Machine Type:
Copper Wire Drawing Machine
Trade Term:
FOB, CIF, CFR, EXW
Type:
Horizontal Metal Drawing Machine
Certification:
ISO
Specification:
Ingredients: Iron
Condition:
New
Port Of Loading:
Shenzhen Port
Payment Methods:
Support payments in USD
Payment Term:
To be discussed
Application:
Used for Reducing The Diameter of Copper Wire Thro
Trademark:
WIRECAN
Model NO.:
WRK-28DHA
Usage:
Wire
Transport Package:
Wooden Packing
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
2015-10-20
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port
Certificates:
CE
Product descriptions from the supplier
A Fine Wire Drawing Machine, also known as a wire drawing bench or wire drawing mill, is a specialized piece of equipment used in the manufacturing industry to reduce the diameter of wire rods or coils to create finer wire. This process is essential for producing wires used in various applications, including electrical wiring, cables, automotive components, jewelry, and more.
The choice of a fine wire drawing machine depends on factors like the initial wire diameter, desired final diameter, material properties, and production volume. These machines play a crucial role in industries that require high-quality, fine-gauge wire for their products.
The choice of a fine wire drawing machine depends on factors like the initial wire diameter, desired final diameter, material properties, and production volume. These machines play a crucial role in industries that require high-quality, fine-gauge wire for their products.
Here are some key features and functions of a fine wire drawing machine:
1. Wire Reduction:
The primary function of the machine is to reduce the diameter of wire rods or coils. It typically consists of multiple drawing dies, each with a slightly smaller diameter than the previous one. The wire is pulled through these dies to progressively reduce its diameter.
2. Die Passes:
The wire typically goes through multiple passes, with each pass reducing the wire diameter further. The number of passes depends on the desired final wire diameter.
3. Tension Control:
Fine wire drawing machines include tension control systems to ensure that the wire is pulled through the dies at the right speed and with the appropriate tension to achieve the desired results.
4. Cooling and Lubrication:
During the drawing process, the wire can generate heat due to friction. Cooling and lubrication systems are used to control the temperature and reduce wear on the drawing dies.
5. Monitoring and Control:
These machines often have monitoring and control systems to track parameters such as wire diameter, speed, and tension. Operators can make adjustments based on real-time data.
6. Wire Straightening:
Some fine wire drawing machines also incorporate wire straightening units to ensure that the drawn wire is straight and uniform.
7. Wire Spooling:
Once the wire has been drawn to the desired diameter, it is usually wound onto spools or reels for further processing or distribution.
Applications of fine wire drawing machines vary widely and include the production of ultra-fine wires for electronics, fine jewelry wires, medical wires, and other specialized applications where precision and small diameters are critical.
| Feature | Description |
|---|---|
| Machine Type | Copper Wire Drawing Machine |
| Application | Used for reducing the diameter of copper wire through multiple drawing dies |
| Material Compatibility | Designed for drawing copper wire |
| Wire Diameter Range | Specifies the range of initial and final wire diameters it can handle |
| Number of Dies | Indicates the quantity of drawing dies in the machine |
| Drawing Speed | Adjustable speed control for the drawing process |
| Tension Control | Mechanisms to ensure consistent tension on the wire during drawing |
| Cooling System | Die cooling system to dissipate heat generated during the process |
| Precision | High precision in reducing wire diameter with minimal deviations |
| Material Handling | Gentle handling to prevent damage to the copper wire |
| Monitoring and Control | Control interface for adjusting parameters and monitoring the process |
| Durability | Built to withstand continuous operation and maintain longevity |
| Customizability | Ability to customize machine specifications based on requirements |
| Maintenance | Regular maintenance requirements to keep the machine in optimal condition |
| Safety Features | Safety mechanisms to ensure safe operation |
