250HP Refrigeration Screw Condensing Unit with Frascold Compressor for Freezing Equipment
1 Set
$2,8901 Set
$28,900Product information
High-quality 250HP Refrigeration Screw Condensing Unit with Frascold Compressor for Freezing Equipment supplied by Jiangsu Zhexue Cold Chain Equipment Co., Ltd.. Bulk wholesale pricing ranges from $2,890 to $28,900 per Set with a minimum order of 1 Set. Inquiry for latest prices.
For Room Temp.:
-50~+10 Degree
Production Capacity:
20 Sets/Day
Package Gross Weight:
300.000kg
Package Size:
320.00cm * 210.00cm * 220.00cm
Specification:
3200*2100*2200mm
Voltage:
380V/3p/50Hz
Cooling Capacity:
390.2kw
HS Code:
8418692090
Specifications
For Room Temp.:
-50~+10 Degree
Production Capacity:
20 Sets/Day
Package Gross Weight:
300.000kg
Package Size:
320.00cm * 210.00cm * 220.00cm
Specification:
3200*2100*2200mm
Voltage:
380V/3p/50Hz
Cooling Capacity:
390.2kw
HS Code:
8418692090
Power Source:
AC Power
Cooling:
Air Cooled
Material:
Cast Iron
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Drive Mode:
Electric
Condenser:
Evaporative Condenser
Trade Term:
FOB, CIF, CFR, EXW
Compressor Brand:
Frascold
Model:
Fvr-L-125-430y
Payment Term:
LC, T/T
Application:
Low Back Pressure Type
Performance:
Low Noise, Variable Frequency, Explosion-Proof
Lubrication Style:
Lubricated
Model NO.:
MFRLGF2-250(L)JY
Mute:
Mute
Configuration:
Portable
Refrigerant:
R404A/R507
Principle:
Screw Compressor
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Transport Package:
Wooden Case
Trademark:
Zhexue
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-10-27
Annual Revenue Amount:
Not specified
Numbers Of Employees:
100
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
Others
Product descriptions from the supplier
The condensing unit with Frascold Screw compressor for low temperature room
Zhexue brand MFRLGF series products are applicable to the large size -50~-10ºC room temperature refrigeration system, as the large size low temperature cold rooms, ice making, and blast freezing etc.
Features:
1.Reliable system: famous brand compressor, PLC controller, high efficient oil separating system.
2.International famous brand low temperature screw compressor, with the features of high efficiency, long service life, tiny vibration and low noise.
3.this series produset of world famous components, protection devices for compressor wrong direction, over heat, over load, over discharging temperature, low oil level, over high/low pressure of oil flow etc.
4.the unit is matched with economizer, which can effectively increase the capacity for low temperature operation.
1.Reliable system: famous brand compressor, PLC controller, high efficient oil separating system.
2.International famous brand low temperature screw compressor, with the features of high efficiency, long service life, tiny vibration and low noise.
3.this series produset of world famous components, protection devices for compressor wrong direction, over heat, over load, over discharging temperature, low oil level, over high/low pressure of oil flow etc.
4.the unit is matched with economizer, which can effectively increase the capacity for low temperature operation.
Model Description:
M BZ LG F 2 - S 100 / J Y
M:MEOJILE products
BZ:Compressor brand
(BZ:B itzer HZ:Hanbell FS:FUSHENG RF:Refcomp FR:Frascold)
LG:Compressor type
(LG:screw BF:piston WX:scroll)
F:Condensation mode
(F:evaporation cooling/air cooling S:water cooling)
2:Compressor QTY
S:Double stage semi hermatic /:Single stage semi hermatic
100:Compressor motor rated power(HP)
J:Temperature
(H:high temp. +5~+20ºC M:middle temp. -10~+5ºC
L:low temp. -30~-10ºC J:blast freezing -50~-30ºC)
Y:Polyester oil /:Mineral oil
Main Components :
Compressor, condenser , pressure controller, pressure oil gauge, pressure sensor,filter vat filter core, liquid angle valve , accumulator, suction check valve, oil separator , oil safety valve, oil pipe ball valve, oil cooler, oil cooler valves, filter, oil dry filter, filter core, solenoid valve, economizer, sight glass, expansion valve,touch screen, LP sensor , PLC controller, Siemens HMI.
M BZ LG F 2 - S 100 / J Y
M:MEOJILE products
BZ:Compressor brand
(BZ:B itzer HZ:Hanbell FS:FUSHENG RF:Refcomp FR:Frascold)
LG:Compressor type
(LG:screw BF:piston WX:scroll)
F:Condensation mode
(F:evaporation cooling/air cooling S:water cooling)
2:Compressor QTY
S:Double stage semi hermatic /:Single stage semi hermatic
100:Compressor motor rated power(HP)
J:Temperature
(H:high temp. +5~+20ºC M:middle temp. -10~+5ºC
L:low temp. -30~-10ºC J:blast freezing -50~-30ºC)
Y:Polyester oil /:Mineral oil
Main Components :
Compressor, condenser , pressure controller, pressure oil gauge, pressure sensor,filter vat filter core, liquid angle valve , accumulator, suction check valve, oil separator , oil safety valve, oil pipe ball valve, oil cooler, oil cooler valves, filter, oil dry filter, filter core, solenoid valve, economizer, sight glass, expansion valve,touch screen, LP sensor , PLC controller, Siemens HMI.
Specification:
| Refrigeration unit with Frascold screw compressors | ||||||
| Unit model | MFRLGF2-60(L)JY | MFRLGF2-80(L)JY | MFRLGF2-100(L)JY | MFRLGF2-120(L)JY | MFRLGF2-140(L)JY | |
| Refrigerant | R507(R404A) | |||||
| Power supply | 380V/3P/50HZ | |||||
| Compressor | Model | FVR-L-30-120Y | FVR-L-40-140Y | FVR-L-50-160Y | FVR-L-60-200Y | FVR-L-70-230Y |
| Qty | 2 | 2 | 2 | 2 | 2 | |
| Evaporating Temperature | -50ºC~-10ºC | |||||
| Evap. Temp -25ºC |
Cooling capacity(KW) | 102 | 121.8 | 138.2 | 184.2 | 211.8 |
| Power input(KW) | 55.6 | 64.4 | 72 | 139.6 | 108.6 | |
| Evap. Temp -42ºC |
Cooling capacity(KW) | 47.6 | 58.4 | 66.2 | 87.8 | 99.6 |
| Power input(KW) | 48.4 | 54.2 | 58.2 | 80 | 87.6 | |
| Liquid pipe(mm) | Φ28 | Φ35 | Φ35 | Φ42 | Φ42 | |
| Suction pipe(mm) | DN80 | DN80 | DN80 | DN100 | DN100 | |
| Oil separator outlet(mm) | DN50 | DN50 | DN50 | DN65 | DN65 | |
| Receiver inlet(mm) | Φ35 | DN40 | DN40 | DN50 | DN50 | |
| Overall size | L(mm) | 2600 | 2600 | 2600 | 2600 | 2600 |
| W(mm) | 1950 | 1950 | 1950 | 1950 | 1950 | |
| H(mm) | 1800 | 1800 | 1800 | 1800 | 1800 | |
| cooling capacity and power are set based on condensing temperature of 35ºC,used for evaporation condenser. | ||||||
| Refrigeration unit with Frascold screw compressors | |||||||
| Unit model | MFRLGF2- 160(L)JY |
MFRLGF2- 180(L)JY |
MFRLGF2- 200(L)JY |
MFRLGF2- 220(L)JY |
MFRLGF2- 250(L)JY |
MFRLGF2- 320(L)JY |
|
| Refrigerant | R507(R404A) | ||||||
| Power supply | 380V/3P/50HZ | ||||||
| Compressor | Model | FVR-L-80-270Y | FVR-L-90-300Y | FVR-L-100-350Y | FVR-L-110-380Y | FVR-L-125-430Y | FVR-L-160-540Y |
| Qty | 2 | 2 | 2 | 2 | 2 | 2 | |
| Evaporating Temperature | -50ºC~-10ºC | ||||||
| Evap. Temp -25ºC |
Cooling capacity(KW) | 244 | 273.6 | 311.6 | 330.4 | 390.2 | 461.4 |
| Power input(KW) | 122.4 | 140.8 | 155.4 | 166 | 186.8 | 235.6 | |
| Evap. Temp -42ºC |
Cooling capacity(KW) | 118.4 | 130.4 | 148.8 | 159 | 183.8 | 219.2 |
| Power input(KW) | 101.8 | 113.6 | 126.6 | 138.2 | 160 | 202.4 | |
| Liquid pipe(mm) | Φ42 | DN50 | DN50 | DN50 | DN50 | DN50 | |
| Suction pipe(mm) | DN100 | DN125 | DN125 | DN125 | DN150 | DN150 | |
| Oil separator outlet(mm) | DN65 | DN80 | DN80 | DN80 | DN80 | DN80 | |
| Receiver inlet(mm) | DN50 | DN65 | DN65 | DN65 | DN65 | DN65 | |
| Overall size | L(mm) | 2600 | 2600 | 2600 | 2600 | 3200 | 3200 |
| W(mm) | 1950 | 1950 | 1950 | 1950 | 2100 | 2100 | |
| H(mm) | 1800 | 1800 | 1800 | 1800 | 2200 | 2200 | |
| cooling capacity and power are set based on condensing temperature of 35ºC,used for evaporation condenser. | |||||||
