4mm High Temperature Basalt Air Slide Origin China Customized Yes Trademark RUIQI Model NO. RIQIB6 HS Code 591140000 Weight 3500g to
1-49 Square Meter
$45050-99 Square Meter
$400100 Square Meter
$350Product information
High-quality 4mm High Temperature Basalt Air Slide Origin China Customized Yes Trademark RUIQI Model NO. RIQIB6 HS Code 591140000 Weight 3500g to supplied by Riqi ( Hangzhou ) Filter Technology Co., Ltd.. Bulk wholesale pricing ranges from $350 to $450 per Square Meter with a minimum order of 1 Square Meter. Inquiry for latest prices.
Width:
100mm to 2800mm
Package Size:
30.00cm * 30.00cm * 30.00cm
Weight:
3500g to 5000g
Thickness:
4mm ,5mm, 6mm
Package Gross Weight:
5.000kg
Production Capacity:
5000m/Week
HS Code:
591140000
Origin:
China
Specifications
Width:
100mm to 2800mm
Package Size:
30.00cm * 30.00cm * 30.00cm
Weight:
3500g to 5000g
Thickness:
4mm ,5mm, 6mm
Package Gross Weight:
5.000kg
Production Capacity:
5000m/Week
HS Code:
591140000
Origin:
China
Trade Term:
FOB, CIF, EXW, CFR
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Feature:
Oil-Resistant, Acid And Alkali Resistant, Tear-Resistant, Heat-Resistant, Wear-Resistant
Inside Material:
Polyester, Cotton
Model NO.:
RIQIB6
Trademark:
RUIQI
Port Of Loading:
Shanghai Port; Ningbo Port
Transport Package:
Standard Export Package
Tensile Strength:
Strong
Customized:
Yes
Specification:
customized size
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2018-08-14
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, EXW, CFR
Port Of Loading:
Shanghai Port; Ningbo Port
Certificates:
AUDIT REPORT, filter cloth nylon test report, ISO, Product Inspection Report
Product descriptions from the supplier
Product Description
Product:Air Slide Belt
Material:Basalt
Weight:8.5-9.0KGS/Square Meter
Layers:5
Air permeability:3.2m³/ square meter Min
Tensile strength:>500KG/40mm
Fracture elongation rate:≤3%
Temperature:650-750ºC
Polyester canvas cement airslide fabric for cement plant
Specification data:
Raw Material =100% spun fiber polyester
Weight in average = 4000 g/m2
Thickness = 5mm
Mean Air Permeability = 400 m3/m2h @350H2O
Pressure: 2000pa for middle air resistance
4000pa for high air resistance
Breaking Strength- Warp=>6000 N/5cm X 20cm
Breaking Strength- Weft= >3000 N/ 5cm X 20cm
Breaking Elongation - warp=<5%
Breaking Elongation -weft=<5%
Max Width: 2800mm
Operating Temperature < 150 deg.C
Recommended Maximum Continues <180 deg.C
Recommended Maximum Surge = 180 deg.C
Technique data:
| name | material | warp tensile strength(N/mm) | thickness(mm) | temperatuer ≤ | instant temperature ≤ | 980Pa air permeability (m3/m2min) |
specification(mm) |
|
4layer |
polyester | ≥ 425 | 3~8 | 160 °C | 180 °C | 0.5~2.5 | 100~1700 |
| 2layer | polyester | ≥ 210 | 2.5~3 | 160 °C | 180 °C | 0.5~2.5 | 100~1700 |
Advantages
- No moisture absorption
- No caking
- Resistant to rotting and decomposition
- Complete unloading without residues
- Consistent fluidization over the complete surface
- Good resistance to abrasion
- Low wear and therefore longer life
- Low shrinkage even when used under hot and humid conditions
Working principle
In cement plant:
An Airslide belt is in the middle of a chute. Powder material will come into the chute above Airslide belt. Material will flow to the chute lower side as pneumatic blower down Airslide belt. That's why we say Airslide belt can move powder material because of the wind power. And then, the rest wind will go out from the top of the chute. Through the moving, no parts moved except powder material. So that it can spare more energy and maintain cost, etc.
In fluidization silo:
Our Airslide canvas is installed on the surface of the silo bottom. It is supplied for installation as aeration units on the sloped conical bottoms of bins and silos to aid in the withdrawal of dry relatively free-flowing material.
Each Airslide aeration unit package consists of 200mm open-type. Airslide conveyor units in lengths of 1.5 or 3m depend on the slope length of the conical storage area. Some spoke patterns are normally used with materials which have good fluidization characteristics. Others spoke patterns provide maximum aeration for difficult materials which can be fluidized.
In cement vessel's hold:
The sloped bottom of the cargo hold is covered with fluidizing panels. Our airslide fabric is on the surface of fluidizing panels. Rotary piston blowers supply the panels with oil-free compressed air and make the cement flow to the lowest point, where the discharge gate is installed. Powder and particulate material available the Airslide canvas fabric conveyor belt
Application:
In industry
Power Stations: Filtered dust, Flue ash, discharging flue ash, Coal dust
Building and Construction: Cement, furnace dust, gypsum, limestone, finely ground quartz, Calcium hydroxide, lead monoxide, quicklime, acid crystals, Pure clay, phosphates, magnesite concentrate, finely ground fluorid, production of aluminum
Chemical Industry:Thomas meal (Fertilizer), Rubber compounds, sinter dust, catalysts,Sodium sulfate, Soap powder
In machinery:
Silos / Tanks : Discharging systems, Warehouse units, Mixing equipment, Homogenizing systems
Chute Bottoms: Conveyor systems, Ventilator systems, Aeration systems
Vehicles : Silo truck discharging cones, Railway wagon discharging cones, Vessel aeration & discharging bottoms, Container aeration & discharging bottoms
Powder Coating Machinery
Bottoms for sinter basin
