5.5 Inch 256X64 OLED Display Modules for ESL E-Paper E-Ink Display
999-4998 Piece
$364999-9998 Piece
$349999 Piece
$3210000 Piece
$30Product information
High-quality 5.5 Inch 256X64 OLED Display Modules for ESL E-Paper E-Ink Display supplied by Shenzhen Ansilon Technology Co., Ltd. Bulk wholesale pricing ranges from $30 to $36 per Piece with a minimum order of 999 Piece. Inquiry for latest prices.
Package Gross Weight:
0.500kg
Package Size:
15.00cm * 11.00cm * 9.00cm
Production Capacity:
50000 Pieces/Month
HS Code:
8531200000
Model NO.:
ASL05525664ASGGF01
Trademark:
Ansilon
Transport Package:
Carton
Origin:
China
Specifications
Package Gross Weight:
0.500kg
Package Size:
15.00cm * 11.00cm * 9.00cm
Production Capacity:
50000 Pieces/Month
HS Code:
8531200000
Model NO.:
ASL05525664ASGGF01
Trademark:
Ansilon
Transport Package:
Carton
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, CIF, CFR, EXW
Payment Term:
LC, T/T, PayPal, Western Union, D/P
Port Of Loading:
Shenzhen Port
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2020-09-21
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union, D/P
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port
Certificates:
Certificates
Product descriptions from the supplier
Ansilon leads the industry in OLED (Organic Light-Emitting Diode) display technology:
Super high contrast (10000:1)
Ultra wide viewing angle
Quick response ( ≤10μs)
Ultra-thin, ultra-light, durable
Wide temperature range (-40℃~85℃)
Self-luminous
Wide range of uses, suitable for products in various fields
Future monitor usage trends
Green energy, environmentally friendly products
Safety certificate
RoHS Compliant
Halogen Free
REACH Certificate
Ultra wide viewing angle
Quick response ( ≤10μs)
Ultra-thin, ultra-light, durable
Wide temperature range (-40℃~85℃)
Self-luminous
Wide range of uses, suitable for products in various fields
Future monitor usage trends
Green energy, environmentally friendly products
Safety certificate
RoHS Compliant
Halogen Free
REACH Certificate
Specification
The 5.5 inch PMOLED display is a Passive Matrix Organic Light-Emitting Diode (PMOLED) panel with a resolution of 256 pixels (width) × 64pixels (height). This size and resolution are very common in small display devices, as they strike a good balance between size, clarity, and power consumption.
Application Areas:
1. Industrial Control & Instrumentation
Displaying parameters, readings, status indicators, and simple menus. Its wide temperature range ensures stable operation in factories and on outdoor equipment. Examples: Digital oscilloscopes, multimeters, sensor gauges, portable measurement devices.
Displaying parameters, readings, status indicators, and simple menus. Its wide temperature range ensures stable operation in factories and on outdoor equipment. Examples: Digital oscilloscopes, multimeters, sensor gauges, portable measurement devices.
2. Automotive Electronics
Used as a display for small automotive components, such as Tire Pressure Monitoring Systems (TPMS), motorcycle dashboards, climate control units, and rearview mirror status displays.
Used as a display for small automotive components, such as Tire Pressure Monitoring Systems (TPMS), motorcycle dashboards, climate control units, and rearview mirror status displays.
3. Consumer Electronics
Portable Medical Devices: Pulse oximeters, glucose meters, digital thermometers, etc. The high contrast ensures readings are clear and legible.
Home Appliances: Control panels for high-end coffee makers, air purifiers, and water heaters.
Audio Equipment: Small screens for MP3 players, portable headphone amplifiers, and audio mixers.
Smart Home Controllers: Displays for smart thermostats and security system panels.
4. PC Peripherals & Accessories
Small screens on keyboards (especially custom mechanical keyboards) for displaying system stats, custom animations, etc.
Display Type: | 5.5 inch |
Resolution: | 256x64 |
Active Area(mm): | 135.65x33.89 |
Panel Size(mm): | 146.0x45.0x2.0 |
Pixel Pitch(mm): | 0.53x0.53 |
Pixel Size(mm): | 0.5x0.5 |
Interface: | SPI |
Color: | White/Blue/Yellow/Green |
Drive IC: | SSD1322 |
Operating Temperature: | -40--80 ºC |
PIN: | 30 Pin |
View Angle: | Full IPS |
Drawings & Dimensions
Shenzhen Ansilon Technology Co., LTD
Shenzhen Ansilon Technology Co., LTD. is a state-level high-tech enterprise specializing in the R&D, Design, Production, Sales and Technical services of OLED/LCD displays. Up to this day, our products, including OLED, TFT, LCM, Micro LED, HMI, etc., have been widely used in many fields, such as Consumer Products, Portable Equipment, Financial Equipment, Electric Energy Meter Equipment, Mobile Terminals, Wearable Devices, Security Cameras, Smart Home Application Scenarios, Medical Equipment and Industrial Equipment. Our mission is to provide you one-stop solution. During last 10 years, based on LCD display as our center, we gradually expand to capacitive touch panel, driving board, software & hardware design and complete industrial computer solution. Our factory is with strong R&D team and strict quality management system of ISO9001, ISO14001 and IATF16949 certificates.
Why Choose Us?
Why Choose This PMOLED?
1. Standard and Customized Display Solutions.
2. Advanced Facilities and Processes.
3. High Precision Machines.
4. Class 100 Clean Rooms.
5. Sophisticated Manufacturing Methods.
6. Stringent Quality Control.
2. Advanced Facilities and Processes.
3. High Precision Machines.
4. Class 100 Clean Rooms.
5. Sophisticated Manufacturing Methods.
6. Stringent Quality Control.
1. Cost-Effective – Lower price than AMOLED, ideal for mass production.
2. Customizable – Adjustable resolution/color/interface per request.
3. Durability – Long lifespan (>30,000 hours).
2. Customizable – Adjustable resolution/color/interface per request.
3. Durability – Long lifespan (>30,000 hours).
FAQ
Q: How can i find the right product?
A: Please send us your requirements, we will recommend our standard products, if it's not fit, we will do the necessary adjustment& customization.
A: Please send us your requirements, we will recommend our standard products, if it's not fit, we will do the necessary adjustment& customization.
Q: How to customize the product?
A: Customized procedures goes like this: Project scope clarification → Fill Ansilon Requirement Form → Engineering analysis → Cost→
Evaluation → Customer confirmation → Providing drawing → Customer confirmation → Sampling → Customer approval → Mass production
A: Customized procedures goes like this: Project scope clarification → Fill Ansilon Requirement Form → Engineering analysis → Cost→
Evaluation → Customer confirmation → Providing drawing → Customer confirmation → Sampling → Customer approval → Mass production
Q: Do you accept sample order or small quantity order?
A: Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)
A: Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)
Q: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
A: We usually accept T/T, Paypal, other terms to be negotiated.
Q: What's the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and
product)
A: Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and
product)
