5000W Tvs Rectifier Diode 5kp30, 5kp48, 5kp110 Ifsm 600 Brand Sy Package SMD Trademark SY Origin China HS Code 85411000 Certification
Pieces
Negotiable
Product information
High-quality 5000W Tvs Rectifier Diode 5kp30, 5kp48, 5kp110 Ifsm 600 Brand Sy Package SMD Trademark SY Origin China HS Code 85411000 Certification supplied by Changzhou Shunye Electronics Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Package Gross Weight:
1.000kg
Package Size:
1.00cm * 1.00cm * 1.00cm
Production Capacity:
100kk
Peak Pulse Power:
5000W
Model NO.:
5kp30, 5KP48, 5KP110
Model:
5kp30, 5kp48, 5kp110
Stand Off Voltage:
6.8-440 V
Ifsm:
600
Specifications
Package Gross Weight:
1.000kg
Package Size:
1.00cm * 1.00cm * 1.00cm
Production Capacity:
100kk
Peak Pulse Power:
5000W
Model NO.:
5kp30, 5KP48, 5KP110
Model:
5kp30, 5kp48, 5kp110
Stand Off Voltage:
6.8-440 V
Ifsm:
600
HS Code:
85411000
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Do-201ad
Material:
Element Semiconductor
Trade Term:
FOB, CIF, CFR
Type:
Intrinsic Semiconductor
Payment Term:
LC, T/T
Manufacturing Technology:
Optoelectronic Semiconductor
Certification:
RoHS
Specification:
RoHS
Package:
SMD
Trademark:
SY
Port Of Loading:
Shanghai Port
Signal Processing:
Simulation
Payment Methods:
Support payments in USD
Brand:
Sy
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-01-27
Annual Revenue Amount:
Not specified
Numbers Of Employees:
94
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shanghai Port
Certificates:
Declaration of Lead Free, High Reliability Test List, ISO, ISO9001:9002, REACH, SGS, SGS of button, SGS of Button and Lead Button Diode, SGS of button diode, SGS REPORT
Product descriptions from the supplier
5000W TVS 5KP5.0A TO 5KP188CA
3.Package:
| TRANSIENT VOLTAGE SUPPRESSORS | ||||||||||
| TYPE | Breakdown Voltage | Stand-off Voltage |
Maximum Reverse Leakage @VRWM |
Maximum Peak Pulse Current |
Maximum Clamping Voltage@IPPM |
Maximum Temperature Coefficient of V(BR) |
Power Dissipation |
Package | ||
| VBR@IT | IT | VRWM | IR | IRSM | VRSM | Pd | ||||
| Min | Max | mA | V | μA | A | V | %/ºC | W | ||
| 5KP5.0 | 6.40 | 7.30 | 50 | 5.0 | 5000 | 520 | 9.6 | 0.057 | 5000 | R-6 |
| 5KP5.0A | 6.40 | 7.00 | 50 | 5.0 | 5000 | 543 | 9.2 | 0.057 | 5000 | |
| 5KP6.0 | 6.67 | 8.15 | 50 | 6.0 | 5000 | 439 | 11.4 | 0.061 | 5000 | |
| 5KP6.0A | 6.67 | 7.37 | 50 | 6.0 | 5000 | 485 | 10.3 | 0.061 | 5000 | |
| 5KP6.5 | 7.22 | 8.82 | 50 | 6.5 | 2000 | 407 | 12.3 | 0.065 | 5000 | |
| 5KP6.5A | 7.22 | 7.98 | 50 | 6.5 | 2000 | 447 | 11.2 | 0.065 | 5000 | |
| 5KP7.0 | 7.78 | 9.51 | 50 | 7.0 | 1000 | 378 | 13.3 | 0.068 | 5000 | |
| 5KP7.0A | 7.78 | 8.60 | 50 | 7.0 | 1000 | 417 | 12.0 | 0.068 | 5000 | |
| 5KP7.5 | 8.33 | 10.2 | 5.0 | 7.5 | 250 | 350 | 14.3 | 0.073 | 5000 | |
| 5KP7.5A | 8.33 | 9.21 | 5.0 | 7.5 | 250 | 388 | 12.9 | 0.073 | 5000 | |
| 5KP8.0 | 8.89 | 10.9 | 5.0 | 8.0 | 150 | 333 | 15.0 | 0.075 | 5000 | |
| 5KP8.0A | 8.89 | 9.83 | 5.0 | 8.0 | 150 | 367 | 13.6 | 0.075 | 5000 | |
| 5KP8.5 | 9.44 | 11.5 | 5.0 | 8.5 | 50 | 314 | 15.9 | 0.078 | 5000 | |
| 5KP8.5A | 9.44 | 10.4 | 5.0 | 8.5 | 50 | 347 | 14.4 | 0.078 | 5000 | |
| 5KP9.0 | 10.0 | 12.2 | 5.0 | 9.0 | 20 | 295 | 16.9 | 0.081 | 5000 | |
| 5KP9.0A | 10.0 | 11.1 | 5.0 | 9.0 | 20 | 325 | 15.4 | 0.081 | 5000 | |
| 5KP10 | 11.1 | 13.6 | 5.0 | 10.0 | 15 | 266 | 18.8 | 0.084 | 5000 | |
| 5KP10A | 11.1 | 12.3 | 5.0 | 10.0 | 15 | 294 | 17.0 | 0.084 | 5000 | |
| 5KP11 | 12.2 | 14.9 | 5.0 | 11.0 | 10 | 249 | 20.1 | 0.086 | 5000 | |
| 5KP11A | 12.2 | 13.5 | 5.0 | 11.0 | 10 | 274 | 18.2 | 0.086 | 5000 | |
| 5KP12 | 13.3 | 16.3 | 5.0 | 12.0 | 10 | 227 | 22.0 | 0.088 | 5000 | |
| 5KP12A | 13.3 | 14.7 | 5.0 | 12.0 | 10 | 251 | 19.9 | 0.088 | 5000 | |
| 5KP13 | 14.4 | 17.6 | 5.0 | 13.0 | 10 | 210 | 23.8 | 0.090 | 5000 | |
| 5KP13A | 14.4 | 15.9 | 5.0 | 13.0 | 10 | 232 | 21.5 | 0.090 | 5000 | |
| 5KP14 | 15.6 | 19.1 | 5.0 | 14.0 | 10 | 194 | 25.8 | 0.092 | 5000 | |
| 5KP14A | 15.6 | 17.2 | 5.0 | 14.0 | 10 | 215 | 23.2 | 0.092 | 5000 | |
| 5KP15 | 16.7 | 20.4 | 5.0 | 15.0 | 10 | 188 | 26.9 | 0.094 | 5000 | |
| 5KP15A | 16.7 | 18.5 | 5.0 | 15.0 | 10 | 206 | 24.4 | 0.094 | 5000 | |
| 5KP16 | 17.8 | 21.8 | 5.0 | 16.0 | 10 | 176 | 28.8 | 0.096 | 5000 | |
| 5KP16A | 17.8 | 19.7 | 5.0 | 16.0 | 10 | 192 | 26.0 | 0.096 | 5000 | |
| 5KP17 | 18.9 | 23.1 | 5.0 | 17.0 | 10 | 164 | 30.5 | 0.097 | 5000 | |
| 5KP17A | 18.9 | 20.9 | 5.0 | 17.0 | 10 | 181 | 27.6 | 0.097 | 5000 | |
| 5KP18 | 20.0 | 24.4 | 5.0 | 18.0 | 10 | 155 | 32.2 | 0.098 | 5000 | |
| 5KP18A | 20.0 | 22.1 | 5.0 | 18.0 | 10 | 172 | 29.2 | 0.098 | 5000 | |
| 5KP20 | 22.2 | 27.1 | 5.0 | 20.0 | 10 | 139 | 35.8 | 0.099 | 5000 | |
| 5KP20A | 22.2 | 24.5 | 5.0 | 20.0 | 10 | 154 | 32.4 | 0.099 | 5000 | |
| 5KP22 | 22.4 | 29.8 | 5.0 | 22.0 | 10 | 127 | 39.4 | 0.100 | 5000 | |
| 5KP22A | 22.4 | 26.9 | 5.0 | 22.0 | 10 | 141 | 35.5 | 0.100 | 5000 | |
| 5KP24 | 26.7 | 32.6 | 5.0 | 24.0 | 10 | 116 | 43.0 | 0.101 | 5000 | |
| 5KP24A | 26.7 | 29.5 | 5.0 | 24.0 | 10 | 128 | 38.9 | 0.101 | 5000 | |
| 5KP26 | 28.9 | 35.3 | 5.0 | 26.0 | 10 | 107 | 46.6 | 0.101 | 5000 | |
| 5KP26A | 28.9 | 31.9 | 5.0 | 26.0 | 10 | 119 | 42.1 | 0.101 | 5000 | |
| 5KP28 | 31.1 | 38.0 | 5.0 | 28.0 | 10 | 99 | 50.1 | 0.102 | 5000 | |
| 5KP28A | 31.1 | 34.4 | 5.0 | 28.0 | 10 | 110 | 45.4 | 0.102 | 5000 | |
| 5KP30 | 33.3 | 40.7 | 5.0 | 30.0 | 10 | 93 | 53.5 | 0.103 | 5000 | |
| 5KP30A | 33.3 | 36.8 | 5.0 | 30.0 | 10 | 103 | 48.4 | 0.103 | 5000 | |
| 5KP33 | 36.7 | 44.9 | 5.0 | 33.0 | 10 | 86 | 59.0 | 0.104 | 5000 | |
| 5KP33A | 36.7 | 40.6 | 5.0 | 33.0 | 10 | 94 | 53.3 | 0.104 | 5000 | |
| TYPE | Breakdown Voltage | Stand-off Voltage |
Maximum Reverse Leakage @VRWM |
Maximum Peak Pulse Current |
Maximum Clamping Voltage@IPPM |
Maximum Temperature Coefficient of V(BR) |
Power Dissipation |
Package | ||
| VBR@IT | IT | VRWM | IR | IRSM | VRSM | Pd | ||||
| Min | Max | mA | V | μA | A | V | %/ºC | W | ||
| 5KP36 | 40.0 | 48.9 | 5.0 | 36.0 | 10 | 78 | 64.3 | 0.104 | 5000 | R-6 |
| 5KP36A | 40.0 | 44.2 | 5.0 | 36.0 | 10 | 86 | 58.1 | 0.104 | 5000 | |
| 5KP40 | 44.4 | 54.3 | 5.0 | 40.0 | 10 | 70 | 71.4 | 0.105 | 5000 | |
| 5KP40A | 44.4 | 49.1 | 5.0 | 40.0 | 10 | 78 | 64.5 | 0.105 | 5000 | |
| 5KP43 | 47.8 | 58.4 | 5.0 | 43.0 | 10 | 65 | 76.7 | 0.105 | 5000 | |
| 5KP43A | 47.8 | 52.8 | 5.0 | 43.0 | 10 | 72 | 69.4 | 0.105 | 5000 | |
| 5KP45 | 50.0 | 61.1 | 5.0 | 45.0 | 10 | 62 | 80.3 | 0.106 | 5000 | |
| 5KP45A | 50.0 | 55.3 | 5.0 | 45.0 | 10 | 69 | 72.7 | 0.106 | 5000 | |
| 5KP48 | 53.3 | 65.2 | 5.0 | 48.0 | 10 | 58 | 85.5 | 0.106 | 5000 | |
| 5KP48A | 53.3 | 58.9 | 5.0 | 48.0 | 10 | 65 | 77.4 | 0.106 | 5000 | |
| 5KP51 | 56.7 | 69.3 | 5.0 | 51.0 | 10 | 55 | 91.1 | 0.107 | 5000 | |
| 5KP51A | 56.7 | 62.7 | 5.0 | 51.0 | 10 | 61 | 82.4 | 0.107 | 5000 | |
| 5KP54 | 60.0 | 73.3 | 5.0 | 54.0 | 10 | 52 | 96.3 | 0.107 | 5000 | |
| 5KP54A | 60.0 | 66.3 | 5.0 | 54.0 | 10 | 57 | 87.1 | 0.107 | 5000 | |
| 5KP58 | 64.4 | 78.7 | 5.0 | 58.0 | 10 | 49 | 103.0 | 0.107 | 5000 | |
| 5KP58A | 64.4 | 71.2 | 5.0 | 58.0 | 10 | 53 | 93.6 | 0.107 | 5000 | |
| 5KP60 | 66.7 | 81.5 | 5.0 | 60.0 | 10 | 47 | 107.0 | 0.108 | 5000 | |
| 5KP60A | 66.7 | 73.7 | 5.0 | 60.0 | 10 | 52 | 96.8 | 0.108 | 5000 | |
| 5KP64 | 71.1 | 86.9 | 5.0 | 64.0 | 10 | 44 | 114.0 | 0.108 | 5000 | |
| 5KP64A | 71.1 | 78.6 | 5.0 | 64.0 | 10 | 49 | 103.0 | 0.108 | 5000 | |
| 5KP70 | 77.8 | 95.1 | 5.0 | 70.0 | 10 | 40 | 125.0 | 0.108 | 5000 | |
| 5KP70A | 77.8 | 86.0 | 5.0 | 70.0 | 10 | 44 | 113.0 | 0.108 | 5000 | |
| 5KP75 | 83.3 | 102.0 | 5.0 | 75.0 | 10 | 37 | 134.0 | 0.108 | 5000 | |
| 5KP75A | 83.3 | 92.1 | 5.0 | 75.0 | 10 | 41 | 121.0 | 0.108 | 5000 | |
| 5KP78 | 86.7 | 106.0 | 5.0 | 78.0 | 10 | 36 | 139.0 | 0.108 | 5000 | |
| 5KP78A | 86.7 | 95.8 | 5.0 | 78.0 | 10 | 40 | 126.0 | 0.108 | 5000 | |
| 5KP85 | 94.4 | 115.0 | 5.0 | 85.0 | 10 | 33 | 151.0 | 0.108 | 5000 | |
| 5KP85A | 94.4 | 104.0 | 5.0 | 85.0 | 10 | 36 | 137.0 | 0.108 | 5000 | |
| 5KP90 | 100 | 122.0 | 5.0 | 90.0 | 10 | 31 | 160.0 | 0.110 | 5000 | |
| 5KP90A | 100 | 111.0 | 5.0 | 90.0 | 10 | 34 | 146.0 | 0.110 | 5000 | |
| 5KP100 | 111 | 136.0 | 5.0 | 100.0 | 10 | 28 | 179.0 | 0.110 | 5000 | |
| 5KP100A | 111 | 123.0 | 5.0 | 100.0 | 10 | 31 | 162.0 | 0.110 | 5000 | |
| 5KP110 | 122 | 149.0 | 5.0 | 110.0 | 10 | 26 | 196.0 | 0.112 | 5000 | |
| 5KP110A | 122 | 135.0 | 5.0 | 110.0 | 10 | 28 | 177.0 | 0.112 | 5000 | |
| 5KP120 | 133 | 163.0 | 5.0 | 120.0 | 10 | 23 | 215.0 | 0.112 | 5000 | |
| 5KP120A | 133 | 148.0 | 5.0 | 120.0 | 10 | 26 | 194.0 | 0.112 | 5000 | |
| 5KP150 | 166 | 204.0 | 5.0 | 150.0 | 10 | 19 | 269.0 | 0.112 | 5000 | |
| 5KP150A | 166 | 186.0 | 5.0 | 150.0 | 10 | 21 | 242.0 | 0.112 | 5000 | |
| 5KP160 | 178 | 217.0 | 5.0 | 160.0 | 10 | 17 | 285.0 | 0.112 | 5000 | |
| 5KP160A | 178 | 196.0 | 5.0 | 160.0 | 10 | 19 | 258.0 | 0.112 | 5000 | |
| 5KP170 | 189 | 230.0 | 5.0 | 170.0 | 10 | 17 | 302.0 | 0.112 | 5000 | |
| 5KP170A | 189 | 208.0 | 5.0 | 170.0 | 10 | 18 | 273.0 | 0.112 | 5000 | |
| 5KP180 | 200 | 245 | 5.0 | 180.0 | 10 | 16 | 322.0 | 0.112 | 5000 | |
| 5KP180A | 200 | 222 | 5.0 | 180.0 | 10 | 17 | 292.0 | 0.112 | 5000 | |
| Notes:suffix with "CA" means bi-directional(e.g,5KP5.0CA), electrical characteristics apply in both directions. | ||||||||||
1, Are you Manufacturer or trading company?
We are a manufacturer only in diode, bridge rectifier and automotive rectifier diode. We could supply competitive price and fast delivery and good quality with prompt service, we guarantee that we will reply to our customers within 1-12H once we receive the inquiry, we will do the utmost to help to reduce your cost.
2. May I have some samples for testing?
Yes, sure. We offer free samples for you and you only need to cover the international freight for samples. when you have 1st order with us, we will deduct the freight from your first order.
3. What about the delivery ?
Usually the lead time is about 1-2 weeks after receiving payment. For many normal parts, we have the quantity in stock and we have the system to ensure the delivery will be on time.
4. What about the payment terms ?
Order amount is less than $10000: 100% Advance.
Order amount is between $10000 and $20000: 50% Advance and 50% before shipment.
Order amount is more than $20000: 30% Advance and 70% before shipment.
Old customer with good reputation: NET 30days.
5. What about the shipment terms ?
FOB Shanghai by air;
CFR your city seaport by sea;
We also work with DHL, FEDEX, TNT and etc. For large quantity , it's up to you to choose the freight forwarder and if you need, we could assist you.
If you have any question or need techical support, please do not hesitate to contact us, we will try our best to serve you.
