650mm Type Lock Bottom Folding Gluing Machine Max Force 70 Origin Wenzhou HS Code 84439119 Bench Height 850 Trademark
1 Set
$8,0001 Set
$3,800Product information
High-quality 650mm Type Lock Bottom Folding Gluing Machine Max Force 70 Origin Wenzhou HS Code 84439119 Bench Height 850 Trademark supplied by Wenzhou Qianding Machinery technology Co., Ltd.. Bulk wholesale pricing ranges from $3,800 to $8,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Max Paper Pile Height:
100
Depth Of The Machine(B):
1480
Fasterst Take Off The Paper:
15-22
Machine Width(A):
1910
Machine Height(C):
1940
Max Take Off The Paper:
230*230
Min Take Off The Paper:
30*30
Min Sheet Size(Z):
300
Specifications
Max Paper Pile Height:
100
Depth Of The Machine(B):
1480
Fasterst Take Off The Paper:
15-22
Machine Width(A):
1910
Machine Height(C):
1940
Max Take Off The Paper:
230*230
Min Take Off The Paper:
30*30
Min Sheet Size(Z):
300
Production Capacity:
300set/Month
Min Sheet Size(X):
400
Max Force:
70
HS Code:
84439119
Bench Height:
850
Trade Term:
FOB, CIF, CFR, EXW
Specification:
From 750mm to 2800mm
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Port Of Loading:
Ningbo Port, Shanghai Port
Trademark:
Qianding
Transport Package:
Strong Export Wooden Case.
Origin:
Wenzhou
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2017-06-16
Annual Revenue Amount:
Not specified
Numbers Of Employees:
45
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port, Shanghai Port
Certificates:
SGS CE, Utility patents, etc
Product descriptions from the supplier
Introduction.
The die cutting and creasing machine is an equipment especially designed for die cutting the ordinary cardboard, corrugated board, plastic and leather products. It is widely used in the printing, packing decorating and plastic industries. The machine has features such as compact structure, fine workmanship, big pressure, high precision and easy and reliable operation etc.
Feature:
1. High strength due to one piece casting by using top quality materials for the machine body.
2. Smooth running, big pressure and low noise are obviously remarked as herringbone gear input and helical gear output mechanism is adopted.
3. Single plate electromagnetic clutch is sensitive and reliable.
4. Operational altitude is reasonably arranged, moveable platen opens to its optimum.
5. The electrical system is designed with IEC standard.
6. With functions as single, continuous operation and opening well, and the dwell time is adjustable.
7. The safely system is reliable.
8. With concentrated lubricating system.
Main Specifications.
Qianding Machines Loaded Into Container At the Ningbo Port.
The die cutting and creasing machine is an equipment especially designed for die cutting the ordinary cardboard, corrugated board, plastic and leather products. It is widely used in the printing, packing decorating and plastic industries. The machine has features such as compact structure, fine workmanship, big pressure, high precision and easy and reliable operation etc.
Feature:
1. High strength due to one piece casting by using top quality materials for the machine body.
2. Smooth running, big pressure and low noise are obviously remarked as herringbone gear input and helical gear output mechanism is adopted.
3. Single plate electromagnetic clutch is sensitive and reliable.
4. Operational altitude is reasonably arranged, moveable platen opens to its optimum.
5. The electrical system is designed with IEC standard.
6. With functions as single, continuous operation and opening well, and the dwell time is adjustable.
7. The safely system is reliable.
8. With concentrated lubricating system.
Main Specifications.
| ModeI | Inner Chase size | Speed | Max.pule length | Motor Power | Weight | Overall Dimensions |
| ML-750 | 750x520mm | 25±2(sprokes/min) | <14m | 2.2kw | 1800kg | 1360x1400x1300mm |
| ML-930 | 930x670mm | 23±2(sprokes/min) | <25m | 4kw | 3000kg | 1680x1680x1640mm |
| ML-1040 | 1040x720mm | 23±2(sprokes/min) | <30m | 4kw | 4000kg | 1850x1780x1700mm |
| ML-1100 | 1100x800mm | 20±2(sprokes/min) | <26.5m | 4kw | 4500kg | 1900x1780x1700mm |
| ML-1200 | 1200X820mm | 20±2(sprokes/min) | <26.5m | 4kw | 4500kg | 1900x1900x1750mm |
| ML-1300 | 1300x920mm | 18±2(sprokes/min) | <38m | 5.5kw | 5600kg | 1920x2140x1800mm |
| ML-1400 | 1400x1000mm | 17±2(sprokes/min) | <38m | 5.5kw | 6200kg | 2010x2400x1930mm |
| ML-1500 | 1500x1050mm | 17±2(sprokes/min) | <40m | 7.5kw | 6800kg | 20100x2480x1960mm |
| ML-1600 | 1600x1250mm | 13±2sprokes/min | <50m | 11kw | 11000kg | 2500×2200×2000mm |
| ML-1800 | 1800×1250mm | 13±2sprokes/min | <60m | 11.5kw | 13500kg | 2510×2300×2000m |
| ML2000 | 2000×1400mm | 13±2strokes/min | <60m | 15kw | 16000kg | 2270×3100×2150mm |
| ML2500 | 2500×1500mm | 13±2strokes/min | <75m | 18.5kw | 20000kg | 2300×3600×2150mm |
Qianding Machines Loaded Into Container At the Ningbo Port.
