6W-EV-Motor-Controller CP Blue/Grey Silicone 200x400mm UL94 1Y MOQ100
100 Piece
$0.06100 Piece
$2.36Product information
High-quality 6W-EV-Motor-Controller CP Blue/Grey Silicone 200x400mm UL94 1Y MOQ100 supplied by ShenZhen DuBang Technology Co., Ltd.. Bulk wholesale pricing ranges from $0.06 to $2.36 per Piece with a minimum order of 100 Piece. Inquiry for latest prices.
Single Gross Weight:
0.230kg
Production Capacity::
100000000 PCS/Year
Specification:
200mm*400mm, Customized Size Available
HS Code:
3824999900
Maximum Voltage:
<10KV
Color:
Blue/Grey/Customized Color
Model NO.:
CP
Trademark:
DoBon
Specifications
Single Gross Weight:
0.230kg
Production Capacity::
100000000 PCS/Year
Specification:
200mm*400mm, Customized Size Available
HS Code:
3824999900
Maximum Voltage:
<10KV
Color:
Blue/Grey/Customized Color
Model NO.:
CP
Trademark:
DoBon
Application:
Electrical Power System, Electronic Device, Laboratory Equipment, Medical Equipment, LED/CPU/GPU
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Guangdong, China
Certificate:
ISO9001, ISO14001, RoHS, IATF 16949, ISO 45001
Payment Terms::
L/C, T/T, D/P, Western Union, Paypal, Money Gram, xtransfer
Shape:
Pad/Sheet/Roll, Customized Shape Available
Port Of Loading:
Shenzhen Port
Port::
Shenzhen, China
Material:
Silicone
Payment Term:
T/T, PayPal, LC, D/P, Western Union, Small-amount payment
Thermal Rating:
UL 94
Shipment:
by Sea or by Air
Transport Package:
in Cartons
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2012-11-28
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, PayPal, LC, D/P, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port
Certificates:
certificate, certificate showing, company, CTI, Halogen-free, ISO14001, Plant, UL
Product descriptions from the supplier
Product Description
Product Description
Thermally Conductive Silicone Pads
Thermal silicone pads, commonly referred to as thermal silicone sheets, are advanced materials used to improve heat management. Constructed from silicone rubber blended with conductive additives, they bridge tiny irregularities between hot components like CPUs and GPUs and cooling systems, boosting heat flow and ensuring efficient thermal dissipation.Designed as a polymer blend using silicone rubber as the primary matrix and incorporating heat-conducting additives, this material serves to bridge the space between electronic devices and cooling systems, enhancing thermal transfer and maintaining reliable performance of electronic systems. The essential factor in the effectiveness of thermally conductive silicone gaskets is the type and proportion of components used, directly influencing both thermal performance and properties such as flexibility, electrical resistance, and long-term resilience.
Thermal silicone pads, commonly referred to as thermal silicone sheets, are advanced materials used to improve heat management. Constructed from silicone rubber blended with conductive additives, they bridge tiny irregularities between hot components like CPUs and GPUs and cooling systems, boosting heat flow and ensuring efficient thermal dissipation.Designed as a polymer blend using silicone rubber as the primary matrix and incorporating heat-conducting additives, this material serves to bridge the space between electronic devices and cooling systems, enhancing thermal transfer and maintaining reliable performance of electronic systems. The essential factor in the effectiveness of thermally conductive silicone gaskets is the type and proportion of components used, directly influencing both thermal performance and properties such as flexibility, electrical resistance, and long-term resilience.
Product Features
- High thermal conductivity:This thermal silicone film boasts superior heat transfer properties, enabling fast movement of heat from the source to the sink, thereby lowering the operating temperature of the heat-generating component.
- Soft and compressible:It has a flexible consistency and readily conforms to uneven shapes, establishing optimal contact between the heat emitter and heat absorber, thereby enhancing thermal conductivity.
- Electrical insulation:This material provides good electrical insulation, preventing electrical interference and short - circuits, making it suitable for use in electronic devices.
Typical Applications
Thermal Interface Material can be used in 36 electronics industry, here are some application examples.
- LED lighting, LED TV
- computers, laptops
- Backlight module, switching power supply
- Medical equipment, communication equipment
- Mobile device, 5G network products
- Video equipment, home appliances
- PC server/workstation, base station
- power supplies, automotive electronics
- elecommunications equipment
- Computers, Laptops, Mobile Phones
Technical Data Sheet
Technical Data Sheet
| Test Item | Unit | CP100 | CP200 | CP300 | CP400 | CP500 | CP600 | Test Method |
| Color | / | Light Gray | Gray, Blue | Grey, Blue | Green/Dark Gray/Blue | Pink,dark gray | dark gray | Visual |
| Thickness | mm | 0.15~18mm | 0.2~20mm | 0.3~18mm | 0.3~18mm | 0.3~18mm | 0.3~18mm | / |
| Specific gravity | g/cm3 | 1.9±0.1 | 2.4±0.1 | 2.8±0.1 | 3.2±0.1 | 3.3±0.1 | 3.3±0.1 | ASTM D792 |
| Hardness | Shore C | 15~50 | 20~50 | 15~20 | 30~50 | 30~50 | 30~50 | ASTM D2240 |
| Tensile Strength | MPa | ≥0.20 | ≥0.2 | ≥0.20 | ≥0.15 | ≥0.10 | ≥0.10 | ASTM D412 |
| Compression rate | % | 15~40 | 15-30 | 10~30 | 20~35 | 20~35 | 20~30 | ASTM D412 |
| Temperature resistance range | ºC | -40~+150 | -40~150 | -40~+150 | -40~+150 | -40~+150 | -40~+150 | EN 344 |
| Volume resistance | Ω·m | ≥1.0*10^13 | ≥1.0*1013 | ≥1.1*10^13 | ≥1.0*1013 | ≥1.0*1013 | ≥1.0*1013 | ASTM D257 |
| Withstand voltage | KV/mm | ≥8 | ≥5.0 | ≥9 | ≥9 | ≥9 | ≥6 | ASTM D149 |
| Flame retardant rating | / | V-0 | ≥10 | V-0 | V-0 | V-0 | V-0 | UL 94 |
| Thermal conductivity | w/m.k | 1.0±0.1 | V0 | 3.15 | 4.0±0.4 | 5.0±0.5 | 6.0±0.6 | ASTM D5470 |
| Oil penetration rate | % | ≤1.0 | 2.0±0.2 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ASTM G120 |
| Test Item | Unit | CP700 | CP800 | CP900 | CP1000 | CP1200 | CP1500 | Test Method |
| Color | / | Dark Gray | Dark Gray | Dark Gray | Dark Gray | Dark Gray | Dark Gray | Visual |
| Thickness | mm | 0.3~18mm | 0.3~18mm | 0.5~5mm | 0.5~5mm | 0.5~5mm | 0.5~5mm | / |
| Specific gravity | g/cm3 | 3.3±0.1 | 3.4±0.1 | 3.4±0.1 | 3.4±0.1 | 3.4±0.1 | 3.5±0.1 | ASTM D792 |
| Hardness | Shore C | 35~50 | 35~50 | 35~50 | 35~50 | 35~50 | 35~50 | ASTM D2240 |
| Tensile Strength | MPa | ≥0.10 | ≥0.10 | ≥0.10 | ≥0.10 | ≥0.10 | ≥0.10 | ASTM D412 |
| Compression rate | % | 5~20 | 5~15 | 5~15 | 5~15 | 5~20 | 5~15 | ASTM D412 |
| Temperature resistance range | ºC | -40~+150 | -40~+150 | -40~+150 | -40~+150 | -40~+150 | -40~+150 | EN 344 |
| Volume resistance | Ω·m | ≥1.0*10^13 | ≥1.0*10^13 | ≥1.0*10^13 | ≥1.0*10^13 | ≥1.0*10^13 | ≥1.0*10^13 | ASTM D257 |
| Withstand voltage | KV/mm | ≥6 | ≥6 | ≥9 | ≥7 | ≥6 | ≥6 | ASTM D149 |
| Flame retardant rating | / | V-0 | V-0 | V-0 | V-0 | V-0 | V-0 | UL 94 |
| Thermal conductivity | w/m.k | 7.0±0.7 | 8.0±0.8 | 9.0±0.9 | 10±1.0 | 12±1.2 | 15±1.5 | ASTM D5470 |
| Oil penetration rate | % | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ASTM G120 |
Company Introduction
- ShenZhen DuBang Technology Co., LTD produce thermal conductive and heat dissipation materials. We are a thermal solution provider integrating production, design, R&D and sales.
- We own 10,000 square meter production base, more than 100 employees, and serves 3,000 customers
- We have 20 sets of production equipment and 4 sets of fully automated production lines
Exhibitions
FAQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer, our factory in Dongguan city, China. Welcome to visit us.
Q: How long is your delivery time?
A: Each 100,000 pieces, we need about 3 days to produce.
Q: Do you provide samples ? is it free or extra ?
A: Sample is available, please you need to pay for it.
Q: How to customize a sample?
A: Please send us design of your products, such as size, shape, etc. We can customize your products.
