705c Db Duplex Bearing for Mini Linear Module
Pieces
Negotiable
Product information
High-quality 705c Db Duplex Bearing for Mini Linear Module supplied by Wuxi Yw Precision Bearing Factory. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
100000 PCS/Year
Model NO.:
705C
Product Name:
705c
HS Code:
8482103000
Ball:
AISI 52100/ 100cr6 /Gcr15
Keywords:
Angular Contact Ball Bearing
Material:
Bearing Steel
Load Direction:
Combined Axial and Radical
Specifications
Production Capacity:
100000 PCS/Year
Model NO.:
705C
Product Name:
705c
HS Code:
8482103000
Ball:
AISI 52100/ 100cr6 /Gcr15
Keywords:
Angular Contact Ball Bearing
Material:
Bearing Steel
Load Direction:
Combined Axial and Radical
Precision Class:
DIN P0( ABEC-1) P6(ABEC-3) P5(ABEC-5) P4(ABEC-7)
Pairing Type:
Db Df Dt
Trade Term:
FOB, CIF
Lubrication:
Grease or Oil
Certification:
IATF 16949
Related Standards:
ISO 492,582 and 1132
Origin:
Jiangsu, Wuxi, China
Payment Term:
LC, T/T
Preload Grade:
Light Medium Heavy
Seal Type:
Open
Cage:
PA66-GF25
Port Of Loading:
Shanghai Port
Rows Number:
Single
Transport Package:
Standard Packaging or Customized
Specification:
Standard Specifications or Customized
Separated:
Unseparated
Trademark:
YW
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
1997-12-05
Annual Revenue Amount:
Not specified
Numbers Of Employees:
168
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF
Port Of Loading:
Shanghai Port
Certificates:
Others
Product descriptions from the supplier
The 705C/DB Duplex Bearing Set for Mini Linear Modules uses matched C-series angular contact bearings in a DB (back-to-back) arrangement to provide high rigidity and stable guidance in compact linear stages. The duplex configuration supports combined radial loads and bi-directional axial loads, while controlled preload helps minimize axial play, vibration, and noise-improving positioning accuracy, repeatability, and running smoothness during high-speed reciprocating motion and frequent start/stop cycles. Ideal for space-constrained precision automation such as mini positioning modules, small assembly stations, inspection fixtures, and micro-motion platforms where consistent performance and service life are critical.
Bearing / Set Configuration
- Bearing type: Angular Contact Ball Bearing (C-series)
- Set arrangement: DB (Back-to-Back) duplex
- Preload: Light / Medium / Heavy (specified by code or value)
- Matching: Matched pair (duplex set)
| Parameter | Single Row | Duplex Pair (DB/DF) | Specification Details |
| Model | 705 AC | 705AC DB / 705AC DF | DB: Back-to-Back / DF: Face-to-Face |
| Contact Angle | 25° | 25° | Optimized for combined radial and axial loads |
| Material | Chrome Steel (GCr15 / 100Cr6) | Chrome Steel (GCr15 / 100Cr6) | High carbon chromium steel |
| Hardness | 60-64 HRC | 60-64 HRC | Through-hardened for wear resistance |
| Cage | Polyamide (PA66) / Brass | Polyamide (PA66) / Brass | PA66: High speed, low friction / Brass: High temp, heavy load |
| Dimensions | 5 x 14 x 5 mm | 5 x 14 x 10 mm | Compact design for space-limited equipment |
| Precision | P5 (ABEC-7) or P4 (ABEC-5) | P5 (ABEC-7) or P4 (ABEC-5) | Ultra-precise for high-speed rotation |
| Dynamic Load (Cr) | 5,000 N | 8,000 N | Higher load capacity in duplex mode |
| Static Load (Cor) | 3,000 N | 6,000 N | Superior static load performance |
| Application | Dental Handpieces | Micro Turbines | Single: General purpose / Duplex: High rigidity |
PRIMARY FUNCTION & CAPABILITY
Angular Contact Ball Bearings are designed to manage both radial and axial stresses simultaneously. Compared to deep groove ball bearings, they excel in withstanding strong axial loads, rendering them perfect for setups requiring precise shaft alignment and very little axial movement.
MAIN APPLICATIONS
These bearings are critical components in high-precision and high-speed machinery across numerous industries:
Machine Tool Spindles:
CNC machining centers, lathes, and grinders where high rigidity, speed, and accuracy are paramount.
Power Transmission:
Gearboxes, pumps, and compressors.
Automotive:
High-performance wheel hubs, transmissions, and electric vehicle motors.
Aerospace:
Helicopter transmissions, jet engine components, and landing gear systems.
Robotics & Automation:
High-precision joints, rotary tables, and servo motors.
Agricultural & Construction Machinery:
Heavy-duty applications require robust performance.
A: We are a manufacturer integrating industry and trade. Welcome to visit our company.
Q2: Can I add my LOGO to the product?
A: We support on-demand customization, including LOGO customization, color customization, appearance size customization, etc.
Q3: What payment methods do you support?
A: We support T/T, Western Union, PayPal, cash, etc. The details can be negotiated.
Q4: What are your modes of transportation?
A: Typically, we select the right transport method—whether sea, air, or land—based on the nature of the cargo, or we’ll align the shipping option with your specific needs.
Q5: How can I get an accurate quotation?
Begin by sharing your detailed requirements and product images, and we’ll tailor a personalized offer based on your specifications, followed by the exact cost.
