API Oilfield Rotaflex Type Belt Hydraulic Pumping Units Model NO. 1100 Weight 21500kg Belt Motor Belt Trademark SEACO HS Code

Name: API Oilfield Rotaflex Type Belt Hydraulic Pumping Units Model NO. 1100 Weight 21500kg Belt Motor Belt Trademark SEACO HS Code
Brand: Shandong Seaco Machinery Equipment Co., Ltd.
SKU: FD-PRODUCT-API-Oilfield-Rotaflex-Type-Belt-Hydraulic-Pumping-Units
Price: 92000 USD
Availability: InStock

1 Piece

$92,000

1 Piece

$72,000

Product information

High-quality API Oilfield Rotaflex Type Belt Hydraulic Pumping Units Model NO. 1100 Weight 21500kg Belt Motor Belt Trademark SEACO HS Code supplied by Shandong Seaco Machinery Equipment Co., Ltd.. Bulk wholesale pricing ranges from $72,000 to $92,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.

Model NO.:

1100

Weight:

21500kg

Package Gross Weight:

500.000kg

Package Size:

500.00cm * 180.00cm * 150.00cm

HS Code:

84314310

Spare Parts:

Bearings

Model:

C22 C320 C456

Specification:

C456D-305-144

Specifications

Model NO.:

1100

Weight:

21500kg

Package Gross Weight:

500.000kg

Package Size:

500.00cm * 180.00cm * 150.00cm

HS Code:

84314310

Spare Parts:

Bearings

Model:

C22 C320 C456

Specification:

C456D-305-144

Material:

Carbon Steel

Refund Policy:

Claim a refund if your order doesn't ship, is missing, or arrives with product issues.

Shipping Cost:

Contact the supplier about freight and estimated delivery time.

Type:

Conventional Beam

Motor:

Electric Motor

Trade Term:

FOB, EXW, CIF, DDP, CIP, FCA

Payment Term:

LC, T/T, PayPal, Western Union, Money Gram

Transmission:

Mechanical

Belt:

Motor Belt

Accessories:

Polished Rod Clamps

Port Of Loading:

Qingdao, Tianjin, shanghai

Trademark:

SEACO

Origin:

Shandong China

Gear Box:

Standard

Transport Package:

Standard Export Packing

Payment Methods:

Support payments in USD

Pumping Way:

With Rod

Brake:

with Brake Assy

Business Details

Country:

China

Business Types:

Not specified

Main Markets:

Not specified

Main Products:

Drilling Machines & Tools; Oil Field Equipments; Oil Pumps; Steel Tubes; Drill Bits

Year Established:

2013-01-01

Annual Revenue Amount:

Not specified

Numbers Of Employees:

Not specified

Preferred Payment Term:

LC, T/T, PayPal, Western Union, Money Gram

Preferred Trade Term:

FOB, EXW, CIF, DDP, CIP, FCA

Port Of Loading:

Qingdao, Tianjin, shanghai

Certificates:

Certificate

Product descriptions from the supplier

Oilfield Rotaflex Type Belt Pump Unit Jack
1150 Model Weatherford Bellt Rotaflex type Pump Unit Jack
11E Walking Beam Pumping Unit Jack oil Pump Jack

The ROTAFLEX type pumping units is the patented product of

Weatherford of American. It has mixed together major features and advantages of all kind of pumping units through years of research and development. As a unique engineering breakthrough, the 100%

mechanical ROTAFLEX is especially suitable for producing high volume fluid in deep wells with rod pump and heavy oil recovery. We had developed up to seven types. Lots of products had been

exported to America, Canada, Cuba, Argentina, Kazakhstan, Uzbekistan, Middle East and other countries in addition to be using in Shengli, Dagang, Liaohe oilfield and almost every big oilfield in China. It has proved that the pump unit with the international advanced level combines the advantages of high efficiency, reliability and energy saving.

Main Advantages:

1. Slow, Long Strokes: Long stroke make high coefficient of fullness, less fluid pounding;Slow period means less wear on downhole equipments and little cost.

2. Belt Transmission: A long life heavy duty belt transmission can absorb the shock during stroke reverse, thus effectively reduce the stress on downhole components to make rod strings run smoothly.

3. Low Torque Demand: The torque demand is greatly reduced due to the short torque arm which is only 0.46m. Thereby, smaller prime mover and gear box may be possible which can cut down energy costs by 10% to 40% comparing to other manual lift system.

4. Optimum Structure Design, Safety and Convenience: Two sets of brake systems with the automatic braking device ensure the units safety absolutely; enclosed unit design makes the units folded up and convenient during shipping, moving safely.

5. High Reliability and Low Maintenance: High reliability by using antifriction bearings, heavy duty belt, heavy load sleeve roller chains, mechanical balance, perfectly lubricating system and self-protection and enclosed unit design ensure to carry load evenly and perfect rigidity through optimum design.

6. Auxiliary system is fairly complete, not only for high volume production, but also for deep wells low volume production.

Model		C320D-256-144
Rating horsehead load (lbs)		25600
Basic Parameters	Stroke lengths (in)	144 124 106
	stroke frequency (r/min)	6 8 10
	Balanced type	crank balance
Gear Reducer	Model	320D
	Rated torque (in. lbs)	320000
	Gear type	Double Reduction Herring bone(double helical)
	Gear ratio	28.81
	Reducer pulley diameter (in)	44"
	Pulley groove type	5C
Balance Assembly	(×4) Weight of counterweight (lbs)	2750×4
Balance Assembly	(×2) weight of crank (lbs)	3064×2
Structural Unbalance (lbs)		214
ECB (lbs)		18010
Make place type of horsehead while workover		hanging
(××) Overall Dimensions Length×Width×Height (in)		402×122×279
Total weight (Kg)		20500

Oilfield Rotaflex Type Belt Hydraulic Pumping Units

Bracket	External dimensions m (L×W×H)	Weight(Kg)	Quantity	Remarks
Bracket1	750022002080	8821	1
Bracket2	330020501370	7482	1
Bracket3	10005501200	2067	2
Total weight KG	21437

5,Product types List and specifications:

No.	Designation	Structure Capacity (kN)	Stroke (m)	Strokes per minute (min-1)	Motor Type	Reducer torque (kN.m)	Total mass (t)	Unit size L W H (m)
1	CYJW5-2.5-13HF	50	2.5, 2.1, 1.7	5,7,9	Y200L-8	13	11.1	7.0×1.9×6.6
2	CYJW5-2.5-18HF	50	2.5, 2.1, 1.7	5,7,9	Y200L-8	18	12.1	7.0×2.0×6.6
3	CYJW6-3-18F	60	3,2.5,2.1	5,7,9	YMJ180L-6	18	13.2	7.9×2.0×6.9
4	CYJW8-3-18F	80	3,2.5,2.1	6,8,10	Y225S-8	18	15.5	8.1×2.0×6.9
5	CYJW8-2.5-26F	80	2.5,2.1,1.6	6,8,10	Y225S-8	26	14.9	8.1×2.2×6.7
6	CYJW8-3-26HF	80	3,2.5,2	6,8,10	Y200L1-6	26	14.9	7.6×2.1×6.9
7	CYJW8-3-26F	80	3,2.5,2.1	6,8,10	Y225S-8	26	16.2	8.1×2.2×6.9
8	CYJW10-1.8-18F	18	1.88,1.54,1.20	6,9,12	Y225M-8	18	14.7	8.1×2.2×6.7
9	CYJW10-2.5-26F	100	2.5,2.1,1.6	6,8,10	Y250M-8	26	20.1	8.1×2.1×6.7
10	CYJW10-4.8-48HF	100	4.8,4.2,3.6	4,6,8	Y250M-8	48	25	10.5×2.52×9.5
11	CYJW10-4.8-53HF	100	4.8,4.2,3.6	4,6,8	Y250M-8	53	25.8	11×2.52×9.5
12	CYJW12-2.5-26F	120	2.5,2.1,1.6	6,8,10	Y250M-8	26	20.6	8.1×2.1×6.7
13	CYJW12-3.6-37F	120	3.6,3,2.4	5,7,9	Y280S-8	37	23.3	8.9×2.3×7.8
14	CYJW12-3.6-53F	120	3.6,3,2.5	5,7,9	Y280S-8	53	25.5	8.9×2.3×7.8
15	CYJW12-4.8-53HF	120	4.8,4.2,3.6	4,6,8	Y250M-8	53	26.3	11×2.52×9.5
16	CYJW12-4.8-73HF	120	4.8,4.2,3.6	4,6,8	Y280M-8	73	29.2	10.9×2.52×9.8
17	CYJW14-3.0-37F	140	3.0,2.5,2.0	6,8,10	Y280S-8	37	23.6	8.7×2.3×7.5
18	CYJW14-3.6-53F	140	3.6,3,2.5	6,8,10	Y280M-8	53	26.9	10×2.6×9.1
19	CYJW14-4.2-53F	140	4.2,3.6,3	5,7,9	Y280M-8	53	29.7	10.5×2.9×9.6
20	CYJW14-4.2-73F	140	4.2,3.6,3	5,7,9	Y280M-8	73	32.6	10.8×2.9×9.1
21	CYJW14-4.2-105F	140	4.2,3.6,3	5,7,9	Y315S-8	105	37.2	10.7×2.9×9.1
22	CYJW14-4.8-73HF	140	4.8,4.2,3.6	5,7,9	Y280M-8	73	34.7	11.8×2.9×9.5
23	CYJW14-4.8-89HF	140	4.8,4.2,3.6	4,6,8	Y280M-8	89	33.5	10.8×2.9×9.5
24	CYJW16-4.8-73F	160	4.88,4.2,3.6	4,6,8	Y315S-8	73	34.9	11.3×2.9×9.6
25	CYJW16-4.8-89HF	160	4.88,4.2,3.6	4,6,8	Y315S-8	89	33.8	11.5×2.9×9.6
26	CYJW16-4.8-105F	160	4.88,4.2,3.6	4,6,8	Y315S-8	105	39	12.0×2.9×10.4
27	CYJW16-5.5-105HF	160	5.5,4.7,4	4,6,8	YMJ280S-8	105	39.4	12.0×3.1×10.8

Oilfield Rotaflex Type Belt Hydraulic Pumping Units

NO.	Designation	Structure Capacity (lbf×10²)	Stroke (in)	Strokes per minute	Motor Type	Reducer torque (10³lb.in)	Total mass(t)	Unit size L W H (m)
1	CW114-109-100HF	109	100,86,67	5,7,9	Y200L-8	114	11.1	7.0×1.9×6.6
2	CW160-109-100HF	109	100,86,67	5,7,9	Y200L-8	160	12.1	7.0×2.0×6.6
3	CW160-133-120F	133	120,100,86	5,7,9	YMJ180L-6	160	13.2	7.9×2.0×6.9
4	CW160-173-120F	173	120,100,86	6,8,10	Y225S-8	160	15.5	8.1×2.0×6.9
5	CW228-173-100F	173	100,86,64	6,8,10	Y225S-8	228	14.9	8.1×2.2×6.7
6	CW228-173-120HF	173	120,100,86	6,8,10	Y200L1-6	228	14.9	7.6×2.1×6.9
7	CW228-173-120F	173	120,100,86	6,8,10	Y225S-8	228	16.2	8.1×2.2×6.9
8	CW160-200-74F	200	74,64,48	6,9,12	Y225M-8	160	14.7	8.1×2.2×6.7
9	CW160-213-74F	213	74,64,48	6,9,12	GAS ENG.	160	14.7	8.1×2.2×6.7
10	CW228-213-100F	213	100,86,74	6,8,10	Y250M-8	228	20.1	8.1×2.1×6.7
11	CW456-213-192HF	213	192,168,144	4,6,8	Y250M-8	456	25.8	11×2.52×9.5
12	CW228-256-100F	256	100,86,74	6,8,10	Y250M-8	228	20.6	8.1×2.1×6.7
13	CW228-256-100F	256	100,86,74	6,8,10	GAS ENG.	228	20.6	8.1×2.1×6.7
14	CW320-256-144F	256	144,120,100	5,7,9	Y280S-8	320	23.3	8.9×2.3×7.8
15	CW456-256-144F	256	144,120,100	5,7,9	Y280S-8	456	25.5	8.9×2.3×7.8
16	CW456-256-192HF	256	192,168,144	4,6,8	Y250M-8	456	26.3	11×2.52×9.5
17	CW640-256-192HF	256	192,168,144	4,6,8	Y280M-8	640	29.2	10.9×2.52×9.8
18	CW320-305-120F	305	120,100,86	6,8,10	Y280S-8	320	23.6	8.7×2.3×7.5
19	CW320-305-120F	305	120,100,86	6,8,10	GAS ENG.	320	23.6	8.7×2.3×7.5
20	CW456-305-144F	305	144,120,100	6,8,10	Y280M-8	456	26.9	10×2.6×9.1
21	CW456-305-168HF	305	168,144,120	5,7,9	Y280M-8	456	29.7	10.5×2.9×9.6
22	CW640-305-168F	305	168,144,120	5,7,9	Y280M-8	640	32.6	10.8×2.9×9.1
23	CW912-305-168F	305	168,144,120	5,7,9	Y315S-8	912	37.2	10.7×2.9×9.1
24	CW640-305-192HF	305	192,168,144	5,7,9	Y280M-8	640	34.7	11.8×2.9×9.5
25	CW640-365-192F	365	192,168,144	4,6,8	Y315S-8	640	34.9	11.3×2.9×9.6
26	CW912-365-192F	365	192,168,144	4,6,8	Y315S-8	912	39	12.0×2.9×10.4
27	CW912-365-216HF	365	216,192,157	4,6,8	YMJ280S-8	912	39.4	12.0×3.1×10.8

Oilfield Rotaflex Type Belt Hydraulic Pumping Units
