Advanced Automatic Filter Press for Fast Filtration Solutions
Set
Negotiable
Product information
High-quality Advanced Automatic Filter Press for Fast Filtration Solutions supplied by Hebei Shuangcheng Environmental Protection Equipment Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Package Size:
1400.00cm * 220.00cm * 200.00cm
Package Gross Weight:
27000.000kg
Production Capacity:
390 Pieces/Year
HS Code:
8421291000
Type:
Chamber Filter Press
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specification:
Customized
Specifications
Package Size:
1400.00cm * 220.00cm * 200.00cm
Package Gross Weight:
27000.000kg
Production Capacity:
390 Pieces/Year
HS Code:
8421291000
Type:
Chamber Filter Press
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specification:
Customized
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Hebei China
Pressure:
Hydraulic Pressure
Trademark:
JINGWANG (or as customized)
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Purpose Four:
Marble Cutting Wastewater Treatment
Purpose Three:
Metallurgical Industry
Purpose One:
Mining Industry
Model NO.:
Quick Opening Filter Press
Purpose Two:
Sand and Gravel Factory
Payment Methods:
Support payments in USD
Port Of Loading:
Tianjin Port
Transport Package:
Wooden Box
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2020-06-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
45
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port
Certificates:
Certificates
Product descriptions from the supplier
A filter press stands as a highly effective tool in industrial processes involving solid-liquid separation, and its capability for remote operation significantly enhances efficiency in today's industrial environments.
This advanced, low-power rapid-access pressure filter builds upon the automatic plate extraction system by integrating a mechanical arm, a longer stroke hydraulic cylinder, and a greater spacing setup, enabling simultaneous removal of several filter plates during discharge. Designed for easily dewatered substances and frequent operation, it excels in space-saving design, consistent operation, superior performance, and minimal running expenses. The plate extraction speed improves by 3 to 6 times, offering clear benefits for systems featuring many plates and intensive usage cycles.
This filter press features a box-like frame made up of several filter plates, creating enclosed filtration spaces between them, with a combined surface area reaching up to 500 square meters—ideal for extensive solid-liquid separation operations. Its transparent flow configuration ensures the filtrate travels through a visible channel, enabling operators to monitor key parameters like flow speed and transparency, thus assessing filtration advancement and performance in real time. An automated plate retraction system boosts operational speed; after each filtration phase, it sequentially pulls the plates apart, efficiently removing the accumulated filter residue from the chambers, greatly reducing manual effort and downtime, and enabling rapid transition into the next cycle. The system finds broad application across sectors including chemicals, textiles, oil and gas, pharmaceuticals, food processing, mining, metallurgy, environmental management, and various wastewater streams such as chemical, metal, electroplating, leather, dyeing, pharmaceutical, aquaculture, slaughter, sand washing, pile driving, and stone cutting effluents—earning strong user satisfaction and acceptance.
We manufacture a range of box filter presses, hydraulic models, diaphragm types, fully automated systems, and associated components, ensuring robust performance and comprehensive product offerings.
Product Accessories
Product Application
Product Effect
This advanced, low-power rapid-access pressure filter builds upon the automatic plate extraction system by integrating a mechanical arm, a longer stroke hydraulic cylinder, and a greater spacing setup, enabling simultaneous removal of several filter plates during discharge. Designed for easily dewatered substances and frequent operation, it excels in space-saving design, consistent operation, superior performance, and minimal running expenses. The plate extraction speed improves by 3 to 6 times, offering clear benefits for systems featuring many plates and intensive usage cycles.
This filter press features a box-like frame made up of several filter plates, creating enclosed filtration spaces between them, with a combined surface area reaching up to 500 square meters—ideal for extensive solid-liquid separation operations. Its transparent flow configuration ensures the filtrate travels through a visible channel, enabling operators to monitor key parameters like flow speed and transparency, thus assessing filtration advancement and performance in real time. An automated plate retraction system boosts operational speed; after each filtration phase, it sequentially pulls the plates apart, efficiently removing the accumulated filter residue from the chambers, greatly reducing manual effort and downtime, and enabling rapid transition into the next cycle. The system finds broad application across sectors including chemicals, textiles, oil and gas, pharmaceuticals, food processing, mining, metallurgy, environmental management, and various wastewater streams such as chemical, metal, electroplating, leather, dyeing, pharmaceutical, aquaculture, slaughter, sand washing, pile driving, and stone cutting effluents—earning strong user satisfaction and acceptance.
We manufacture a range of box filter presses, hydraulic models, diaphragm types, fully automated systems, and associated components, ensuring robust performance and comprehensive product offerings.
- Specifications include: 630 type, 800 type, 1000 type, 1250 type 1500 type, 1600 type, 2000 type.
- The maximum filtration area is up to 1000sqm.
- Filter plate materials are divided into cast iron, reinforced polypropylene, glass fiber polypropylene, etc.
- There are various forms fluid flow: open flow, closed flow, washable, non-washable, central feed, corner feed, etc.
| Technical Date:Work Journey 750,Maximum Journey 1000. | |||||||||
| U-Plastic plate & frame(Thickness70,Filter Cloth Thickness 1mm/plate) | |||||||||
| Filtration area | Number of Plate | Cake thickness(mm) | Chamber volume | Unit weight(kg) | Anchor center(mm) | Length | Width | Heigth | |
| 220 | 57 | 35 | 3.92 | 16883 | 6110 | 7615 | 2470 | 1830 | |
| 250 | 65 | 4.47 | 17996 | 6680 | 8185 | 2470 | 1830 | ||
| 300 | 77 | 5.27 | 19637 | 7550 | 9055 | 2470 | 1830 | ||
| 350 | 91 | 6.21 | 21516 | 8550 | 10055 | 2470 | 1830 | ||
| 400 | 103 | 7.04 | 23786 | 9420 | 10925 | 2470 | 1830 | ||
| 450 | 117 | 7.98 | 25102 | 10430 | 11935 | 2470 | 1830 | ||
| 500 | 129 | 8.80 | 26745 | 11290 | 12795 | 2470 | 1830 | ||
| U-Plastic plate & frame(Thickness75,Filter Cloth Thickness 1mm/plate) | |||||||||
| 220 | 57 | 40 | 4.48 | 17148 | 6400 | 7905 | 2470 | 1830 | |
| 250 | 65 | 5.11 | 18321 | 7020 | 8525 | 2470 | 1830 | ||
| 300 | 77 | 6.03 | 20022 | 7940 | 9445 | 2470 | 1830 | ||
| 350 | 91 | 7.11 | 22010 | 9020 | 10525 | 2470 | 1830 | ||
| 400 | 103 | 8.04 | 23701 | 9940 | 11445 | 2470 | 1830 | ||
| 450 | 117 | 9.12 | 25687 | 11020 | 12525 | 2470 | 1830 | ||
| 500 | 129 | 10.05 | 27390 | 11945 | 13450 | 2470 | 1830 | ||
| U-Plastic plate & frame(Thickness80,Filter Cloth Thickness 1mm/plate) | |||||||||
| 220 | 57 | 40 | 4.48 | 17339 | 6700 | 8205 | 2470 | 1830 | |
| 250 | 65 | 5.11 | 18616 | 7350 | 8855 | 2470 | 1830 | ||
| 300 | 77 | 6.03 | 20539 | 8340 | 9845 | 2470 | 1830 | ||
| 350 | 91 | 7.11 | 22775 | 9480 | 10985 | 2470 | 1830 | ||
| 400 | 103 | 8.04 | 26148 | 10470 | 11975 | 2470 | 1830 | ||
| 450 | 117 | 9.12 | 28388 | 11620 | 13125 | 2470 | 1830 | ||
| 500 | 129 | 10.05 | 30306 | 12600 | 14105 | 2470 | 1830 | ||
