Advanced Film Capacitor for Smart Energy Management Systems
100 Piece
$39.43100 Piece
$14.29Product information
High-quality Advanced Film Capacitor for Smart Energy Management Systems supplied by Hai'an Haiyan Electric Appliance Co., Ltd.. Bulk wholesale pricing ranges from $14.29 to $39.43 per Piece with a minimum order of 100 Piece. Inquiry for latest prices.
Temperature:
-25℃/50℃
Rated Voltage:
0.23-1kv
Rated Capacity:
1-60kvar
Specification:
450*240*210mm
Capacitance:
79~1529μf
HS Code:
85321000
Model NO.:
BSMJ04.5/0.25(367*144)
Trade Term:
FOB, CIF, CFR, EXW
Specifications
Temperature:
-25℃/50℃
Rated Voltage:
0.23-1kv
Rated Capacity:
1-60kvar
Specification:
450*240*210mm
Capacitance:
79~1529μf
HS Code:
85321000
Model NO.:
BSMJ04.5/0.25(367*144)
Trade Term:
FOB, CIF, CFR, EXW
Structure:
Fixed Capacitor
Standard:
GB/T12747, IEC60831
Application:
General Purpose, Power, Lighting
Origin:
Jiangsu, China
Usage:
Low Frequency Coupling, Low Frequency Bypass, Other
Tuning:
Metallized Polypropylene Film Capacitor
Electrolyte:
Other
Filter:
Other
Transport Package::
Paper Box
Manufacturing Material:
Polypropylene
Type:
Polypropylene Capacitor
Port Of Loading:
Shanghai Port, Nantong Port
Port::
Shanghai, China
Packaging Type:
Surface Mount
Payment Terms::
T/T
Payment Term:
T/T, PayPal, Western Union, Small-amount payment
Trademark:
TongTian
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
1992-11-03
Annual Revenue Amount:
Not specified
Numbers Of Employees:
48
Preferred Payment Term:
T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port, Nantong Port
Certificates:
CE, Others, RoHS, UL
Product descriptions from the supplier
Product Description
Product Description
Product Features
1. Compact Elegance: Small in size and incredibly light in weight
Revolutionary lightweight design, just one-fourth or even one-fifth the weight of traditional, outdated models.
2. Low Loss Efficiency
Boasting an exceptionally low active power loss of less than 1.2 W/kvar, ensuring high efficiency.
3. Exceptional Self-Healing: Offers outstanding self-healing capabilities. In the event of a dielectric breakdown due to over-voltage or over-current, it swiftly self-heals to resume optimal performance.
4. Superior Safety Assurance
Outfitted with cutting-edge built-in discharge resistors and advanced over-pressure protection mechanisms.
5. Leak-Free Reliability
1. Compact Elegance: Small in size and incredibly light in weight
Revolutionary lightweight design, just one-fourth or even one-fifth the weight of traditional, outdated models.
2. Low Loss Efficiency
Boasting an exceptionally low active power loss of less than 1.2 W/kvar, ensuring high efficiency.
3. Exceptional Self-Healing: Offers outstanding self-healing capabilities. In the event of a dielectric breakdown due to over-voltage or over-current, it swiftly self-heals to resume optimal performance.
4. Superior Safety Assurance
Outfitted with cutting-edge built-in discharge resistors and advanced over-pressure protection mechanisms.
5. Leak-Free Reliability
Product Parameters
| Product Name | Self-healing Low-voltage Shunt Capacitor (Intelligent Type) |
| Type | Electronic Component,Reactive power compensation capacitor,Harmonic-resistant self-healing capacitor |
| Characteristics | High-temperature resistant, low-loss, safe and environmentally friendly |
| Rated Capacity | 1~60kvar |
| Rated frequency | 50Hz/60Hz |
| Rated Voltage | 0.23~1kV |
| Capacitance deviation | -3~5% |
| Active power loss | ≤1.2W/kvar |
| Inter - electrode voltage strength | 2.15Un 10s |
| Withstand voltage between electrode and case | 3600V 10s |
| Maximum allowable over - voltage | 1.1Un |
| Maximum allowable over - current | 1.3Im |
| Self - discharge characteristics | The residual voltage drops from √2Un to below 50V within 3 minutes after the capacitor is de - energized |
| Temperature range | -25ºC/50ºC |
| Altitude | ≤2000m |
| Humidity range | 35ºC,≤85% |
| Precautions for the installation site | Free of harmful gases and vapors |
| Free of conductive or explosive dust | |
| Free of severe vibrations | |
| The spacing between more than two units should not be less than 30 mm | |
| Take effective heat dissipation measures in summer | |
| Related Standards | GB/T 12747,IEC 60831 |
| product certification | CQC,UL,VDE |
| Product Model | Rated Voltage | Rated Capacity | Rated Capacitance | Rated Current | Rated Frequency | Height | Shell Size |
(V) | (Kvar) | (μF) | (A) | (Hz) | (H)mm | (L*W)mm | |
| BSMJ0.45-2.5+2.5-3 | 450 | 5 | 79 | 3 3 | 50 | 130 | 360*65 |
| BSMJ0.45-2.5+5-3 | 450 | 7.5 | 118 | 3 6 | 50 | 130 | |
| BSMJ0.45-5+5-3 | 450 | 10 | 157 | 6 6 | 50 | 130 | |
| BSMJ0.45-5+10-3 | 450 | 15 | 236 | 6 13 | 50 | 170 | |
| BSMJ0.45-10+10-3 | 450 | 20 | 315 | 13 13 | 50 | 170 | |
| BSMJ0.45-10+20-3 | 450 | 30 | 472 | 13 26 | 50 | 230 | |
| BSMJ0.45-20+20-3 | 450 | 40 | 629 | 26 26 | 50 | 230 | |
| BSMJ0.45-10+20-3 | 450 | 30 | 472 | 13 26 | 50 | 220 | |
| BSMJ0.45-20+20-3 | 450 | 40 | 629 | 26 26 | 50 | 220 | |
| BSMJ0.25-2.5-YN | 250 | 2.5 | 127 | 3 | 50 | 130 | |
| BSMJ0.25-5-YN | 250 | 5 | 255 | 7 | 50 | 130 | |
| BSMJ0.25-7.5-YN | 250 | 7.5 | 382 | 10 | 50 | 130 | |
| BSMJ0.25-10-YN | 250 | 10 | 510 | 13 | 50 | 130 | |
| BSMJ0.25-15-YN | 250 | 15 | 764 | 20 | 50 | 170 | |
| BSMJ0.25-20-YN | 250 | 20 | 1019 | 27 | 50 | 170 | |
| BSMJ0.25-25-YN | 250 | 25 | 1274 | 33 | 50 | 230 | |
| BSMJ0.25-30-YN | 250 | 30 | 1529 | 40 | 50 | 230 | |
| BSMJ0.25-15-YN | 250 | 15 | 764 | 20 | 50 | 200 | |
| BSMJ0.25-20-YN | 250 | 20 | 1019 | 27 | 50 | 200 | |
| BSMJ0.25-25-YN | 250 | 25 | 1274 | 33 | 50 | 220 | |
| BSMJ0.25-30-YN | 250 | 30 | 1529 | 40 | 50 | 220 | |
| BSMJ0.45-2.5+2.5-3 | 450 | 5 | 79 | 3 3 | 50 | 115 | 340*70 |
| BSMJ0.45-2.5+5-3 | 450 | 7.5 | 118 | 3 6 | 50 | 115 | |
| BSMJ0.45-5+5-3 | 450 | 10 | 157 | 6 6 | 50 | 115 | |
| BSMJ0.45-5+10-3 | 450 | 15 | 236 | 6 13 | 50 | 115 | |
| BSMJ0.45-10+10-3 | 450 | 20 | 315 | 13 13 | 50 | 160 | |
| BSMJ0.45-10+20-3 | 450 | 30 | 472 | 13 26 | 50 | 200 | |
| BSMJ0.45-20+20-3 | 450 | 40 | 629 | 26 26 | 50 | 200 | |
| BSMJ0.25-2.5-YN | 250 | 2.5 | 127 | 3 | 50 | 115 | |
| BSMJ0.25-5-YN | 250 | 5 | 255 | 7 | 50 | 115 | |
| BSMJ0.25-7.5-YN | 250 | 7.5 | 382 | 10 | 50 | 115 | |
| BSMJ0.25-10-YN | 250 | 10 | 510 | 13 | 50 | 115 | |
| BSMJ0.25-15-YN | 250 | 15 | 764 | 20 | 50 | 160 | |
| BSMJ0.25-20-YN | 250 | 20 | 1019 | 27 | 50 | 160 | |
| BSMJ0.25-25-YN | 250 | 25 | 1274 | 33 | 50 | 200 | |
| BSMJ0.25-30-YN | 250 | 30 | 1529 | 40 | 50 | 200 | |
| BSMJ0.45-40+40-3 | 450 | 80 | 1258 | 51 51 | 50 | 280 | 348*95 |
| BSMJ0.45-40+30-3 | 450 | 70 | 1101 | 51 38 | 50 | 280 | |
| BSMJ0.45-35+35-3 | 450 | 70 | 1101 | 45 45 | 50 | 280 | |
| BSMJ0.45-40+20-3 | 450 | 60 | 944 | 51 26 | 50 | 220 | |
| BSMJ0.45-30+30-3 | 450 | 60 | 944 | 38 38 | 50 | 220 | |
| BSMJ0.45-20+30-3 | 450 | 50 | 786 | 26 38 | 50 | 220 | |
| BSMJ0.45-25+25-3 | 450 | 50 | 786 | 32 32 | 50 | 220 | |
| BSMJ0.45-20+20-3 | 450 | 40 | 629 | 26 26 | 50 | 160 | |
| BSMJ0.25-20+20-YN | 250 | 40 | 2038 | 27 27 | 50 | 280 | |
| BSMJ0.25-10+20-YN | 250 | 30 | 1529 | 13 27 | 50 | 220 | |
| BSMJ0.25-10+15-YN | 250 | 25 | 1274 | 13 20 | 50 | 220 | |
| BSMJ0.25-10+10-YN | 250 | 20 | 1019 | 13 13 | 50 | 160 | |
| BSMJ0.25-5+10-YN | 250 | 15 | 764 | 7 13 | 50 | 160 | |
| BSMJ0.25-20+0.45-40 | 250 450 | 20 40 | 1019 629 | 26 51 | 50 | 280 | |
| BSMJ0.25-10+0.45-40 | 250 450 | 10 40 | 510 629 | 13 51 | 50 | 220 | |
| BSMJ0.25-20+0.45-30 | 250 450 | 20 30 | 1019 472 | 27 38 | 50 | 240 | |
| BSMJ0.25-10+0.45-30 | 250 450 | 10 30 | 510 472 | 13 38 | 50 | 220 | |
| BSMJ0.25-20+0.45-20 | 250 450 | 20 20 | 1019 315 | 27 26 | 50 | 240 | |
| BSMJ0.25-10+0.45-20 | 250 450 | 10 20 | 510 315 | 13 26 | 50 | 220 | |
| BSMJ0.45-40+40-3 | 450 | 80 | 1258 | 51 51 | 50 | 200 | 367*144 |
| BSMJ0.45-40+30-3 | 450 | 70 | 1101 | 51 38 | 50 | 200 | |
| BSMJ0.45-35+35-3 | 450 | 70 | 1101 | 45 45 | 50 | 200 | |
| BSMJ0.45-40+20-3 | 450 | 60 | 944 | 51 26 | 50 | 200 | |
| BSMJ0.45-30+30-3 | 450 | 60 | 944 | 38 38 | 50 | 200 | |
| BSMJ0.45-20+30-3 | 450 | 50 | 786 | 26 38 | 50 | 200 | |
| BSMJ0.45-25+25-3 | 450 | 50 | 786 | 32 32 | 50 | 200 | |
| BSMJ0.45-20+20-3 | 450 | 40 | 629 | 26 26 | 50 | 200 | |
| BSMJ0.25-20+20-YN | 250 | 40 | 2038 | 27 27 | 50 | 200 | |
| BSMJ0.25-10+20-YN | 250 | 30 | 1529 | 13 27 | 50 | 200 | |
| BSMJ0.25-10+15-YN | 250 | 25 | 1274 | 13 20 | 50 | 200 | |
| BSMJ0.25-10+10-YN | 250 | 20 | 1019 | 13 13 | 50 | 200 | |
| BSMJ0.25-5+10-YN | 250 | 15 | 764 | 7 13 | 50 | 200 | |
| BSMJ0.25-20+0.45-40 | 250 450 | 20 40 | 1019 629 | 26 51 | 50 | 200 | |
| BSMJ0.25-10+0.45-40 | 250 450 | 10 40 | 510 629 | 13 51 | 50 | 200 | |
| BSMJ0.25-20+0.45-30 | 250 450 | 20 30 | 1019 472 | 27 38 | 50 | 200 | |
| BSMJ0.25-10+0.45-30 | 250 450 | 10 30 | 510 472 | 13 38 | 50 | 200 | |
| BSMJ0.25-20+0.45-20 | 250 450 | 20 20 | 1019 315 | 27 26 | 50 | 200 | |
| BSMJ0.25-10+0.45-20 | 250 450 | 10 20 | 510 315 | 13 26 | 50 | 200 | |
| We can customize products according to customers' requirements. | |||||||
