Advanced Game Console Controller with Customizable Buttons and Ergonomic Design
1 Set
$5,0001 Set
$500Product information
High-quality Advanced Game Console Controller with Customizable Buttons and Ergonomic Design supplied by GSK CNC Equipment Co., Ltd.. Bulk wholesale pricing ranges from $500 to $5,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Displayer:
10.4-Inch Screen
Production Capacity:
100000set/Year
HS Code:
8537101901
Certification:
CE, ISO 9001
Type:
CNC Controller
Numerical Control:
CNC/MNC
Transport Package:
Carton or Plywood
Control Method:
Closed-Loop Control
Specifications
Displayer:
10.4-Inch Screen
Production Capacity:
100000set/Year
HS Code:
8537101901
Certification:
CE, ISO 9001
Type:
CNC Controller
Numerical Control:
CNC/MNC
Transport Package:
Carton or Plywood
Control Method:
Closed-Loop Control
Movement Method:
Contour Control
Trade Term:
FOB, CIF, CFR, EXW
Connection:
Full Bus
Trademark:
GSK
Port Of Loading:
Guangzhou Port
Origin:
Guangzhou, China
Performance Classification:
High-End CNC Machine Tools
Payment Term:
LC, T/T, D/P
Application:
Metal
Materia:
Metal
Process Usage:
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Condition:
New
PLC:
Online Editing
Interface:
RS232&USB&Network
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
1991-04-08
Annual Revenue Amount:
Not specified
Numbers Of Employees:
2146
Preferred Payment Term:
LC, T/T, D/P
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Guangzhou Port
Certificates:
Others
Product descriptions from the supplier
Introducing the GSK 980TDi-H: A High-performance CNC Controller for Your Turning Machine Needs
GSK980TDi TURNING MACHINE CNC PRODUCT BRIEF
Presenting the GSK980TDi, the newest advancement in the acclaimed GSK980TD lineup. Crafted by the same visionary team behind the GSK980TD, GSK980TDa, GSK980TDb, and GSK980TDc, this cutting-edge solution is engineered to lead the CNC turning machine and turning center industry.
Powered by the cutting-edge GSK-Link industrial bus system, the GSK980TDi combines a bus-integrated servo driver with a multi-core, 23-bit absolute encoder motor. This setup delivers precise 0.1μm positional control, enables real-time servo tuning, and supports instant mechanical zero restoration. Its refined, contemporary design is the result of expert craftsmanship, and in-depth development improves performance, smart functionality, intuitive controls, and supports custom software expansion.
The launch of the GSK980TDi heralds a new era of excellence in common CNC systems!
| Technical features |
| Based on GSK-Link industrial field bus. |
| Least command increment:0.1μm, maximum traverse rate: 100m/min. |
| Support turning and milling. |
| Support torque control . |
| Support servo parameter online configuration, servo status real-time monitoring. |
| Support display interface secondary development (User-defined). |
| Support non-stop mechanical zero return. |
| Standard bus servo drive unit and multi-turn 17-bit absolute encoder. |
High Speed & High Precision Control
By utilizing the GSK-Link industrial fieldbus, the system’s servo motors, combined with GR-L line servo drives and 25-bit or higher precision absolute encoders, achieve nano-scale positioning. This synchronization matches the output precision exactly with the encoder’s feedback resolution, enabling exceptional speed and accuracy in advanced machining operations.
By utilizing the GSK-Link industrial fieldbus, the system’s servo motors, combined with GR-L line servo drives and 25-bit or higher precision absolute encoders, achieve nano-scale positioning. This synchronization matches the output precision exactly with the encoder’s feedback resolution, enabling exceptional speed and accuracy in advanced machining operations.
Oscillating Chip Break
In rough machining, a targeted sine or cosine wave is superimposed on the feed motion, making the tool vibrate along the cutting path. This action fragments long chip streams into smaller, controlled segments, avoiding entanglement with the tool or workpiece, which in turn lowers the chances of tool fracture or workpiece shifting.
In rough machining, a targeted sine or cosine wave is superimposed on the feed motion, making the tool vibrate along the cutting path. This action fragments long chip streams into smaller, controlled segments, avoiding entanglement with the tool or workpiece, which in turn lowers the chances of tool fracture or workpiece shifting.
Support for Turning, Milling, and Drilling Complex Machining
The machine features five linear motion axes and two analog spindle drives, enabling spindle angle control, precise hole drilling, cylindrical path movement, and polar coordinate motion when used with a servo-driven spindle. These capabilities fulfill both advanced turning and milling tasks.
The machine features five linear motion axes and two analog spindle drives, enabling spindle angle control, precise hole drilling, cylindrical path movement, and polar coordinate motion when used with a servo-driven spindle. These capabilities fulfill both advanced turning and milling tasks.
Graphical Simulation
A 3D representation of the workpiece is used during programming to replicate actual machining conditions, enhancing tool path clarity and easing detection of coding mistakes.
A 3D representation of the workpiece is used during programming to replicate actual machining conditions, enhancing tool path clarity and easing detection of coding mistakes.
Thread Repair Function
The machine's thread recovery feature can fix compromised threads—such as big oil pipes or fasteners—no matter if it uses a servo or analog spindle.
The machine's thread recovery feature can fix compromised threads—such as big oil pipes or fasteners—no matter if it uses a servo or analog spindle.
Polygon Turning
| For traditional polygon processing, power milling tools are usually used for processing. For occasions where high precision is not required the polygon turning function can be used to accelerate the processing of various polygons by the offset angle before synchronizing the workpiece axis with the main control axis and changing the speed ratio of the workpiece axis and the tool axis. |
Machine Tool Fault Diagnosis
The machine tool's diagnostic function visually presents input and output signals within the machine's structural layout, enabling a simpler and more straightforward approach to identifying faults.
The machine tool's diagnostic function visually presents input and output signals within the machine's structural layout, enabling a simpler and more straightforward approach to identifying faults.
Application Case
GSK980TDi Applied in Brake Pad Machining
GSK980TDi Applied in Brake Pad Machining
| Special type: Brake pad processing machine |
| Application effect |
| Driving linear and rotary axes with a general servo drive; |
| The grinding wheel is machined with end faces instead of the side of the common grinding wheel; |
| Complete tasks with dedicated instructions |
Technical Specification
| Item | Specification | |
| Controlled axis number | Max. controlled axis number: 5 axes | |
| Max. linkage axis number: 5 axes (linear interpolation), 2 axes (circular interpolation) | ||
| PLC controlled axis number: 5 axes | ||
| Coordinate value(system) and dimensions |
Work piece coordinate system (G50), local coordinate system, work piece coordinate (G54-G59 | |
| Coordinate plane selection | ||
| Position command range: 99999999 x least input increment | ||
| Absolute/incremental proaramming, diameter/radius proqramming, inch/metric conversion, linear axis/rotation axis | ||
| preparatory function | 9 G commands, including quick positioning. linear interpolation, circular interpolation. cylindrical interpolation, thread cutting, polar coordinate interpolation, polygon turning, rigid tapping, dwell, driling, tool compensation, macro call, jump, cycle, tilt axis and thread repair, etc. |
|
| Feed function | Rapid traverse rate: 0 mm/min -100000 mm/min | |
| Rapid override: FO, 25%, 50%, 100%, a total of 4 levels of real-time adjustment | ||
| Cutting feedrate: 0 mm/min ~15000 mm/min | ||
| Feedrate override: 0~150%, a total of 16 levels of real-time adjustment | ||
| Rapid traverse/cutting feedrate acceleration/deceleration: linear type, S type. the starting and termination rate ot acceleration/deceleration and acceleration/deceleration time set by the parameters |
||
| Bus function | Servo motor with multi-turn absolute position encoder | |
| The absolute coordinate system is automatically restored after machine is powered off | ||
| Machine tool mechanical return without block | ||
| Servo parameters online modification | ||
| Servo status online diagnosis | ||
| Operation log, running log, processing log | ||
| Remote monitor.GSKLINK function | ||
| Thread cutting | Thread type: equal pitch straight thread / taper thread / end thread / arc thread, variable pitch straight thread / taper thread / end thread / equal tip width variable lead thread |
|
| Number of threads:1-99 | ||
| Thread pitch: 0.01mm~500mm (metric thread) or 0.06 teeth/inch-2540 teeth/inch (inch thread) | ||
| Thread cutting acceleration and deceleration: Linear type, index type, S type optional | ||
| Thread run-out: The run-out length, angle and rate characteristic can be set. | ||
| Spindle function | Spindle revolution speed: Set by S code or PLC signal, the range: 0 rpm ~9999 rpm | |
| Spindle override: 50% ~ 120%, a total of 8 levels of real-time adjustment | ||
| 2 route 0V~10V analog voltage output, support flexible tapping/rigid tapping | ||
| 2 route spindle encoder feedback, the spindle encoder resolution can be set. | ||
| Tool function | Tool length compensation (tool offset): 32 groups | |
| Tool wearing compensation: 32 groups | ||
| Tool lifetime management:32 groups (8 pieces/group) | ||
| Tool nose radius compensation (C type) | ||
| Tool seting mode: Fixed point tool setting, trial cutting tol setting, reference point matching tool setting, automatic tool seting,coordinate recording function |
||
| Tool offset execution mode: modify coordinate mode, tool movement mode | ||
| M.S.T function | Special M code (M00,M01, M02,M30,M98 and M99 ) , other M codes are defined by PLC | |
| PLC function | Two levels of PLC program, maximum5000 steps, the 1st level refresh period 8ms ,13 basic commands, 44 function commands |
|
| PLC program on-line display, real-time monitor; support PLC warning and PLC alarm | ||
| Support many PLC programs, the current running PLC program optional | ||
| Basic I/O: 48 inputs/38 outputs | ||
| Extendable serial I/O unit (optional): IOR-21F: 24 inputs, 16 outputs, 2 analog voltage output IOR-21T: 24 inputs, 16 outputs, 2 analog voltage output IOR-04T: 48 inputs, 32 outputs IOR-44T: 48inputs, 32 outputs, 4 analog voltage output, 1 RS485/232 serial interface |
||
| Program memory and edit | Program memory: 64M, 10000 programs (include subprogram and macro) | |
| Edit mode: full-screen edit | ||
| Edit function: program/block/character search, rewrite, delete, copy, paste | ||
| MDI input, 10 blocks operation | ||
| Support macro/subprogram call, allow 4-layer subprogram nesting | ||
| The calculator | ||
| Miscellaneous programming | ||
| Program check function | Path preview, graphic simulation, dry run, machine tool lock, M.S.T lock , single block operation, stored stroke check | |
| Simplified programming function | Canned cycle, multiple canned cycle, rigid tapping, direct input of drawing size, automatic chamfering, statement macro programming |
|
| Compensation function | Back ash compensation : 0 mm-2 mm or 0 inch-0.2 inch. backlash compensation mode and the freauency set by the parameters |
|
| Memory pitch error compensation: Total 1024 compensation points, each axis compensation point number set by the parameters |
||
| HMI | 8.4" LCD true color | |
| Support Chinese, English and other languages display | ||
| The process path shows that the process path can be zoomed in and out; the font of the program content can also be zoomed in and out. |
||
| Position, Program, Tool Compensation, Alarm, Parameter, Set, Graph, Diagnosis, Ladder diagram, Help | ||
| Operation management | Operation mode: Edit, Auto, MDl, Mechanical zero return, MPG/Single step, Manual, Program zero return, MPG trial cutting/Retraction |
|
| 6 level operation authority management | ||
| 32 times for power off in the limited time | ||
| Program switch,Parameter switch | ||
| MPG interruption, Teach | ||
| The machine function debugging, the machine default diagnosis | ||
| Reqular maintenance function | ||
| Communication function | USB flash disk: USB flash disk fle operation, USB flash disk fle direct processing, support PLC program, system software upgrade with USB flash disk upgrade |
|
| RS232: Bidirectional transmission of parts programs, parameters, etc., screw-in parameter import and export, support PLC program update |
||
| LAN: Remote file transfer | ||
| Safety function | Emergency stop, hardware travel limit, software travel check, data backup and recovery | |
| Electrical interface | 48/38 digital input and output interface, 2-way encoder interface, 2-way hand wheel interface, 2-way spindle analog interface, Rj45 network port, GSK-LINK network port |
|
| Overall dimension | GSK980TDi(W*H*D) | 420 x260 x 150mm |
| GSK980TDi-V(W*H*D) | 292 x 422 x 150mm | |
| GSK980TDi-H(W*H*D) | 400x400x150mm | |
