Advanced Oil Purifier for Superior Water Control Efficiency
1 Piece
$60,0001 Piece
$1,500Product information
High-quality Advanced Oil Purifier for Superior Water Control Efficiency supplied by JIANGSU VIKING HYDRAULIC & PURIFICATION TECHNOLOGY CO., LTD.. Bulk wholesale pricing ranges from $1,500 to $60,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Inlet Pressure:
-0.4bar~1bar
Standard Working Vacuum:
-0.6bar~-0.9bar
Specification:
1600*1450*2200 mm
Package Size:
1800.00cm * 1100.00cm * 2500.00cm
Production Capacity:
20sets/Month
Package Gross Weight:
600.000kg
Origin:
Changzhou, Jiangsu, P. R. China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Inlet Pressure:
-0.4bar~1bar
Standard Working Vacuum:
-0.6bar~-0.9bar
Specification:
1600*1450*2200 mm
Package Size:
1800.00cm * 1100.00cm * 2500.00cm
Production Capacity:
20sets/Month
Package Gross Weight:
600.000kg
Origin:
Changzhou, Jiangsu, P. R. China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, CIF, CFR, EXW
Application:
Industrial
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Inlet Dimension:
M60X2
Temperature Of Media:
Normal Temperature
Media:
Oil
Transport Package:
Sea Packing
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Trademark:
VIKING
Model NO.:
VKCP
Outlet Pressure:
≤8bar
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2011-02-28
Annual Revenue Amount:
Not specified
Numbers Of Employees:
64
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
ISO14001, ISO9001:2015
Product descriptions from the supplier
This oil purifeir is a filtration and dehydration system designed for lubricating oil. It integrates precision filtration and high-efficiency dehydration of oil, which can effectively remove particles, emulsified water and free water in the oil. After the treatment, the cleanliness of the oil can reach NAS1638-6, and the free water content can be lower than 50PPM.
When unpacking the packing box, be careful and check the received parts according to the delivery note.
This oil purifier has been tested and quality inspected according to the company's standard procedures, and necessary tests have also been carried out in accordance with the requirements of the contract before factory delivery. After the test, in order to facilitate transportation, the equipment may have been opened or disassembled, vented and cleaned. Prior to use, the customer should check and ensure that the nuts, bolts, hoses, joints or any other parts are not loose during transportation, and tighten them if necessary.
Check whether the wiring of the electrical components of the equipment is loose, and tighten if necessary.
Before installation, check whether the purification equipment is suitable for the predetermined system, such as pressure, sealing material, etc. Before this oil purifier is connected to the system, check whether the connecting pipeline is clean. This oil purifier is recommended to be connected to the system fuel tank bypass, not directly connected to the system for online use.
Function:
Filtration Cycle:It can be used separately as particle filtration equipment.
Dehydration Cycle:It can remove emulsified water and free water from steam turbine oil.
Characteristics
Due to gravity, big water droplets settle to the lower part of the coalescence tank. Part of the smaller water droplets move up with the oil to the separation filter element under the action of inertia.
The separation filter element is made of special hydrophobic materials. When the oil passes through, the water droplets are blocked outside the filter element. After gathering with each other, the size gradually increases, and finally settles to the water storage tank at the lower part of the coalescence tank due to gravity.
The oil enters the filter element and is discharged from the liquid outlet.
we are located in Address:No. 3, Xiaming Road, Hengshanqiao Town, Changzhou Economic Development Zone ,Changzhou city,Jiangsu Province,China.
we will deliver the goods to meet your deadline.
If any question, feel free to contact me.
Look forward for future cooperation.
When unpacking the packing box, be careful and check the received parts according to the delivery note.
This oil purifier has been tested and quality inspected according to the company's standard procedures, and necessary tests have also been carried out in accordance with the requirements of the contract before factory delivery. After the test, in order to facilitate transportation, the equipment may have been opened or disassembled, vented and cleaned. Prior to use, the customer should check and ensure that the nuts, bolts, hoses, joints or any other parts are not loose during transportation, and tighten them if necessary.
Check whether the wiring of the electrical components of the equipment is loose, and tighten if necessary.
Before installation, check whether the purification equipment is suitable for the predetermined system, such as pressure, sealing material, etc. Before this oil purifier is connected to the system, check whether the connecting pipeline is clean. This oil purifier is recommended to be connected to the system fuel tank bypass, not directly connected to the system for online use.
Function:
Filtration Cycle:It can be used separately as particle filtration equipment.
Dehydration Cycle:It can remove emulsified water and free water from steam turbine oil.
Characteristics
- Unattended Operation:No need to be on duty after passing the debugging and entering normal operation.
- Automatic Fault Alarm:Automatic alarm when operation is abnormal and needs maintenance.
- Automatic Stop When Accident:When a critical situation occurs during operation, the system can be automatically shut down .
- System Status Display:The operation panel of the equipment can display the running status.
- Filtration Principle
- Dehydration Principle
Due to gravity, big water droplets settle to the lower part of the coalescence tank. Part of the smaller water droplets move up with the oil to the separation filter element under the action of inertia.
The separation filter element is made of special hydrophobic materials. When the oil passes through, the water droplets are blocked outside the filter element. After gathering with each other, the size gradually increases, and finally settles to the water storage tank at the lower part of the coalescence tank due to gravity.
The oil enters the filter element and is discharged from the liquid outlet.
| Feel free to contact us and we have best sevvice for 24 hours |
we are located in Address:No. 3, Xiaming Road, Hengshanqiao Town, Changzhou Economic Development Zone ,Changzhou city,Jiangsu Province,China.
we will deliver the goods to meet your deadline.If any question, feel free to contact me.
Look forward for future cooperation.
