Advanced Plastic Extruder for PP HDPE and UPVC Tubing
Piece
Negotiable
Product information
High-quality Advanced Plastic Extruder for PP HDPE and UPVC Tubing supplied by Zhangjiagang Deling Machinery Co, Ltd. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Line Speed:
1-6m/Min
Extrusion Capacity:
1000-2500kg/H
Motor Power:
18.5-90
Production Capacity:
2 Set/Month
Package Size:
2000.00cm * 220.00cm * 250.00cm
Package Gross Weight:
3000.000kg
Installed Power:
50-130kw
Output:
50-1500kg/H
Specifications
Production Line Speed:
1-6m/Min
Extrusion Capacity:
1000-2500kg/H
Motor Power:
18.5-90
Production Capacity:
2 Set/Month
Package Size:
2000.00cm * 220.00cm * 250.00cm
Package Gross Weight:
3000.000kg
Installed Power:
50-130kw
Output:
50-1500kg/H
Max Width:
600mm
HS Code:
8477109000
Automation:
Automatic
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Computerized:
Computerized
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Paired With Auxiliary Equipment:
Customized
Product:
Customized
Trademark:
DELING
Screw Channel Structure:
Deep Screw
Exhaust:
Exhaust
Product Type:
Extrusion Molding Machine
Trade Term:
FOB, EXW, CIF
Small Commodities:
Foam Picture Frame Profile
Engagement System:
Full Intermeshing
Energy Supplies:
Gas Supply Pipe
Characteristic:
High Automation
Assembly Structure:
Integral Type Extruder
Origin:
Jiangsu, China
Transport Package:
Land and Sea
Feeding Mode:
Multiple Feed
Plastic Processed:
PVC
Home Supplies:
PVC Imitation Marble
Payment Term:
PayPal, Small-amount payment, T/T, D/P, Western Union
Type:
Pipe Extruder
Port Of Loading:
Shanghai Port
Extruder Model:
Sj51/105
Payment Methods:
Support payments in USD
Screw:
Twin-Screw
Industrial Supplies:
Water Supply Pipe
Home Decoration:
Wood-Plastic
Specification:
stainless steel
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-04-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
13
Preferred Payment Term:
PayPal, Small-amount payment, T/T, D/P, Western Union
Preferred Trade Term:
FOB, EXW, CIF
Port Of Loading:
Shanghai Port
Certificates:
CE, Certificate, Certificates
Product descriptions from the supplier
UPVC/CPVC PIPE EXTRUSION LINE
| MODEL | PIPE DIAMETER (MM) | HOST MODEL | MIAN MOTOR POWER (KW) | MAX SPEED (RPM) | MAX CAPACITY (KGH) |
| DLGC40-2 | φ16-φ40 | SJZ51/105 | 18.5 AC | 10 | 120 |
| DLGC63-2 | φ20-φ63 | SJZ65/132 | 37 AC | 15 | 250 |
| DLGC63 | φ20-φ63 | SJZ51/105 | 18.5 AC | 15 | 120 |
| DLGC160 | φ50-φ160 | SJZ65/132 | 37 AC | 8 | 250 |
| DLGC200 | φ63-φ200 | SJZ65/132 | 37 AC | 3.5 | 250 |
| DLGC315 | φ160-φ315 | SJZ80/156 | 55 AC | 2 | 350 |
| DLGC630 | φ315-φ630 | SJZ92/188 | 110 DC | 1.2 | 800 |
| DLGC800 | φ560-φ800 | SJZ105/216 | 160DC | 1.3 | 1100 |
LARGE DIAMETER HDPE WATER SUPPLY AND GAS SUPPLY PIPE EXTRUSION LINE
| MODEL | PIPE DIAMETER (MM) | HOST MODEL | CAPACITY (KGH) | TOTAL INSTALLED POWER (KW) |
| DLDKJ-800 | φ450-φ800 | SJ120/33 SJ150/33 | 1000-1300 | 600 |
| DLDKJ-1000 | φ630-φ1000 | SJ120/33 | 1000-1300 | 650 |
| DLDKJ-1200 | φ800-φ1200 | SJ90/33 SJ120/33 SJ150/33 | 1000-1500 | 960 |
| DLDKJ-1600 | φ1000-φ1600 | SJ120/33 SJ150/33 | 1000-1700 | 1300 |
| DLDKJ-2500 | φ1400-φ2500 | SJ120/33 SJ150/33 | 1500-2000 | 1400 |
| DLDKJ-3000 | φ2000-3000 | SJ120/33 SJ150/33 | 2000-2500 | 1550 |
PVC TWO & FOUR CAVITY PRODUCTION LINE
| MODEL | PIPE DIAMETER (MM) | HOST MODEL | TOTAL POWER (KW) | MAX CAPACITY (KGH) |
| DLGC25-D | 16-25 | SJZ51/105 | 108 | 120 |
| DLGC63-D | 20-63 | SJZ65/132 | 123 | 250 |
| DLGC32-F | 16-32 | SJZ65/1320 | 122 | 250 |
PVC WOOD-PLASTIC PROFILE AND EXTRUSION LINE
| MODEL | MAX PRODUCT WIDTH (MM) | HOST MODEL | MAX MOTOR POWER (KW) | MAX CAPACITY (KGH) |
| DLMS-108 | 108 | SJZ51/105 | 18.5 | 100 |
| DLMS-180 | 180 | SJZ51/105 OR SJZ51/110 | 22 | 100 |
| DLMS-240 | 240 | SJZ65/132 | 37 | 150-200 |
| DLMS-300 | 300 | SJZ65/132 | 37 | 150-200 |
| DLMS-400 | 400 | SJZ80/156 | 55 | 250-300 |
| DLMS-500 | 500 | SJZ80/156 | 55 | 250-300 |
| DLMS-600 | 600 | SJZ80/156 | 75 | 300-350 |
PVC DECORATIVE MARBLE SHEET PRODUCTION LINE
| MODEL | PLATE WIDTH (MM) | PLATE THICKNESS (MM) | MAX CAPACITY (KGH) | PRODUCTION SPEED (M/MIN) |
| SJSZ-80/156 | 1220 | 2-6 | 200-600 | 0.9 |
PVC WPC DOOR BOARD PRODUCTION LINE
| MODEL | MAX PLATE WIDTH (MM) | HOST MODEL | MAX CAPACITY (KGH) |
| DLMSM-600 | 600 | SJSZ80/156 | 400 |
| DLMSM-900 | 900 | SJSZ92/188 | 600 |
| DLMSM-1200 | 1200 | SJSZ92/188 | 600 |
PVC+ASA/PMMA GLAZED ROOF TILE PRODUCTION LINE
PLASTIC FOAM PICTURE FRAME PROFILE PRODUCTION LINE
| MODEL | RODUCTION SPEED (M/MIN) | INSTALLED POWER (KW) | APPEARANCE SIZE (M) |
| DLJK-65 | 2-6 | 50 | 26*1*2 |
| DLJK-90 | 1-5 | 90 | 32*1*2 |
| DLJK-100 | 1-4 | 100 | 33*1*2 |
| DLJK-120 | 1-3 | 130 | 34*1*2 |
FULLY AUTOMATIC MIXING LINE
SJ SERIES SINGLE SCREW PLASTIC EXTRUDER
| MODEL | L/D | CAPACITY (PE) (KGH) | SCREW SPEED (R/MIN) | DRIVE POWER (KW) | CENTER HEIGHT (MM) |
| SJ-25 | 25/1 | 5 | 20-120 | 1.5-2.2 | 1000 |
| SJ-30 | 25/1 | 10 | 20-150 | 3-5.5 | 1000 |
| SJ-45 | 25-33/1 | 50-150 | 20-150 | 7.5-37 | 1000 |
| SJ-65 | 25-33/1 | 60-250 | 20-150 | 22-90 | 1000 |
| SJ-75 | 25-33/1 | 200-350 | 20-150 | 55-110 | 1100 |
| SJ-90 | 25-33/1 | 180-550 | 20-150 | 37-185 | 1100 |
| SJ-120 | 25-33/1 | 320-800 | 20-150 | 75-280 | 1250 |
| SJ-150 | 25-33/1 | 400-1200 | 20-150 | 90-355 | 1300 |
SJSZ SERIES CONICAL TWIN-SCREW PLASTICS EXTRUDER
| MODEL | SJSZ-45 | SJSZ-51 | SJSZ-55 | SJSZ-65 | SJSZ-80 | SJSZ-92 |
| SCREW DIAMETER (MM) | 45/90 | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
| SCREW NUMBER (PCS) | 2 | |||||
| SCREWS DIRECTION | SCREW ROTATION DIRECTION | |||||
| SCREW ROTATION SPEED (RPM) | 1-45 | 1-45 | 40 | 1-35 | 1-37 | 1-33 |
| SCREW EFFECTIVE LENGTH (MM) | 985 | 1070 | 1200 | 1440 | 1800 | 2500 |
| MAIN POWER (KW) | 15 | 18.5 | 22/30 | 37 | 55 | 90 |
| BARREL HEATING POWER (KW) | 12 | 18 | 18 | 24 | 36 | 86.8 |
| PRODUCTION CAPACITY (KGH) | 120 | 80-150 | 150-180 | 250-300 | 320-400 | 600-800 |
| CENTER HEIGHT (MM) | 1000 | 1000 | 1000 | 1000 | 1000 | 1200 |
| WEIGHT (KG) | 2800 | 3200 | 3500 | 4000 | 5000 | 8000 |
| DIMENSIONS (CM) (L*W*H) | 330*120*210 | 360*110*210 | 360*110*210 | 423.5*152*245 | 475*155*246 | 672.5*155*284.1 |
SHJ SERIES PARALLEL TWIN SCREW EXTRUDER
| MODEL | DARREL DIAMETER (MM) | L/D | MOTOR POWER (KW) | SCREW SPEED (RPM) | PRODUCTION CAPACITY (KGH) |
| SJSL-20(A,B) | 22 | 32-44 | 4-5.5 | 400-600 | 2-10 |
| SJSL-36(A,B,C,D) | 36 | 32-48 | 11-22 | 400-600 | 10-150 |
| SJSL-51(A,B,C,D) | 54 | 32-52 | 45-90 | 500-600 | 100-300 |
| SJSL-63(A,B,C,D) | 63 | 32-64 | 75-160 | 500-600 | 150-700 |
| SJSL-75(A,B,C,D) | 72 | 32-64 | 110-315 | 500-600 | 300-1200 |
| SJSL-95(A,B,C,D) | 94 | 32-64 | 250-550 | 500-600 | 700-2000 |
BRP SERIES PARALLEL TWIN SCREW EXTRUDER
| MODEL | SCREW DIAMETER (MM) | MOTOR POWER (KW) | MAX ROTATING SPEED (RPM) | L/D | PRODUCTION CAPACITY (KGH) |
| BRP-75 | 75 | 37 | 45 | 26:1 | 350 |
| BRP-90 | 90 | 55 | 45 | 26:1 | 450 |
| BRP-93 | 93 | 67 | 42 | 28:1 | 600 |
| BRP-107 | 107 | 75 | 38 | 26:1 | 800 |
| BRP-110 | 110 | 90 | 38 | 28:1 | 850 |
| BRP-120 | 120 | 110 | 32 | 26:1 | 1100 |
| BRP-130 | 130 | 132 | 30 | 26:1 | 1200 |
Q: What is the price of a plastic recycling line?A: Costs are customized based on the customer's specified purity standards for the end product and their desired output volume. We carefully design the optimal recycling system configuration to match their financial constraints.
Q: Is it necessary to have a label removal machine?
A: If the bottles for recycling are free from labels and caps, or if removal is unnecessary, a label removal machine is not needed.
Q: What percentage of labels can the label removal machine eliminate?
A: The label removal machine is highly efficient-removing over 96% of labels and caps from compressed bottles and over 98% from uncompressed bottles.
Q: How frequently should the crusher's blade be sharpened?
A: The blade should be sharpened at least weekly to maintain optimal performance.
Q: How is dirt and sewage disposed of in the high-speed friction cleaning machine?
A: Dirt and sewage are efficiently discharged through the outlet at the machine's base.
Q: What is the optimal temperature for hot cleaning a steamer?
A: The ideal temperature for this process is approximately 80°C.
Q: How can remaining labels and bottle caps be removed after using the label removal machine?
A: Rinsing tanks and vertical label and cap removal machines are effective for removing any residual labels and caps.
Q: What purposes does a rinse tank serve?
A: A rinse tank thoroughly cleans crushed materials, allowing labels and bottle caps to float and be prevented from moving to subsequent machines.
Q: What is the moisture content of material post-dehydration?
A: The moisture content is minimized to ≤3%, ensuring optimal dryness.
Q: Can a plastic granulator be attached to the end of the plastic recycling line?
A: Absolutely, a plastic granulator can seamlessly integrate with the recycling line.
