Advanced Stainless Steel Water Purifier for Rural Areas
1-9 sets
$18,80010-99 sets
$10,000100 sets
$5,600Product information
High-quality Advanced Stainless Steel Water Purifier for Rural Areas supplied by New Yuda Environmental Protection Technology Co., Ltd.. Bulk wholesale pricing ranges from $5,600 to $18,800 per sets with a minimum order of 1 sets. Inquiry for latest prices.
Warranty Of Core Components:
1 Year
Production Capacity:
100 Sets Per Month
Capacity:
10t/H-250t/H
Productivity:
10t/H~ 200t/H
Size:
1200*210*230cm/Customized
Package Size:
2000.00cm * 500.00cm * 400.00cm
Package Gross Weight:
3000.000kg
Weight:
5000kg
Specifications
Warranty Of Core Components:
1 Year
Production Capacity:
100 Sets Per Month
Capacity:
10t/H-250t/H
Productivity:
10t/H~ 200t/H
Size:
1200*210*230cm/Customized
Package Size:
2000.00cm * 500.00cm * 400.00cm
Package Gross Weight:
3000.000kg
Weight:
5000kg
Power:
5kw
HS Code:
8521511251
Desalination Rate:
97%
Organic Removal Rate:
98%
Heat Removal Rate:
98%
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Material:
Container, FRP+SS304
Trade Term:
FOB, CIF, EXW, CFR
Origin:
Guangxi, China
Application:
Household, Industrial
Trademark:
NEW YUDA
After Warranty Service:
Online Support
Core Components:
Pressure Vessel, Pump, Motor, PLC
Machinery Test Report:
Provided
Port Of Loading:
Shanghai Port, Qinzhou Port
Payment Term:
Small-amount payment, Western Union, LC, T/T, PayPal, D/P
Specification:
Stainless Steel
Payment Methods:
Support payments in USD
Showroom Location:
Viet Nam, Indonesia, Thailand, Sri Lanka, Malaysia
Transport Package:
Wooden Box+ Container
Model NO.:
XYD-SS-002
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-03-04
Annual Revenue Amount:
Not specified
Numbers Of Employees:
44
Preferred Payment Term:
Small-amount payment, Western Union, LC, T/T, PayPal, D/P
Preferred Trade Term:
FOB, CIF, EXW, CFR
Port Of Loading:
Shanghai Port, Qinzhou Port
Certificates:
ISO14001, ISO9001:2015, ISO45001:2018
Product descriptions from the supplier
|
Product name
|
Seawater Desalination System
|
|
Materials
|
Container, FRP+SS304
|
|
Color
|
Customized
|
|
Size
|
1200*220*230CM
|
|
MOQ
|
1SET
|
XYD series stainless steel water purifier is a domestically designed water treatment solution specifically crafted for rural safe drinking water needs. Equipped with one invention patent and fifty utility patents, it guarantees an advanced filtration method and superior product performance.
The XYD range of stainless steel water purifiers is a domestically developed and manufactured drinking water treatment solution, built around the patented inner and outer spiral grid coil reactor technology, fully tailored to meet user needs. It offers a compact design, intuitive operation, consistent performance, effective filtration, and broad usability.
Product Parameters
Raw water turbidity may reach as high as 1500 NTU; all other raw water types comply with Class I, Class II, and Class III drinking water source quality criteria outlined in CJ3020-93 "Water Quality Standards for Drinking Water Sources"
2. Effluent water quality: Effluent turbidity ≤ 0.5NTU, and other effluent water quality meets the newly established GB5749-2022 "Hygienic Standards for Drinking Water Quality";
3. Flocculation reaction time: 12-20 minutes;
4. Velocity of steady flow area: 1.38~1.67mm/s;/Liquid surface load in sedimentation area: 5~6m3/m2-h
5. Filtration speed: 6-7 m/h, 7-10 m/h for double-layer combined filter media;
6. Filter pool filter layer height: ≥0.8 meters;
7. Flushing strength: 14~17L/s-m2 (adjustable) with siphon automatic backwashing and manual forced backwashing system;
8. Rinse time: 4~8min (adjustable);
9. Minimum inlet head: 8 meters
Process Flow
The XYD range of water purifiers utilizes food-safe SUS304 stainless steel, integrating a refined sequence of purification steps including dosing, blending, coagulation, settling, sludge conditioning, filtration, self-regulating rinsing, and sterilization. This system effectively transforms surface sources like reservoirs, mountain runoff, ravines, and rivers into safe, potable water compliant with the "Hygienic Standard for Drinking Water for Daily Use" (GB5749-2006).
The core technology of the water purifier---reaction precipitator
Our advanced flocculation system leverages a patented inner and outer spiral coil reactor design. When coagulant-laden source water flows through the dual spiral channels, it generates a bidirectional rotational cross-flow between the inner and outer layers. As the fluid moves downward through the spiral structure, centrifugal force and gravitational pull create multiple vortex zones, significantly enhancing particle collisions. This promotes rapid formation of consistent, compact, and easily settleable alum flocs. Relative to conventional flocculation units, this technology boosts reaction performance by up to 100%, reduces coagulant usage by 20–30% compared to standard flat grid systems, and demonstrates superior resilience to fluctuating flow demands. It also eliminates layout constraints in circular water treatment setups, making it ideal for large-scale industrial applications.
The reaction precipitator's sedimentation system integrates the flocculation and sedimentation zones vertically, employing a proprietary V-shaped flow directing plate. This design enables the upward water velocity to progressively decrease due to the combined effect of water column pressure and the downward movement of alum within the sedimentation zone. As a result, a stable floc layer approximately 300mm thick develops between the two sections. This layer effectively traps suspended colloids, flocs, microorganisms, and other contaminants, significantly enhancing alum's settling performance. This optimized floc layer ensures that even when raw water turbidity reaches up to 3000NTU, the treated water exits at less than 10NTU, substantially easing the burden on downstream filtration units and boosting the overall performance of the water treatment system.
A) How could I get a sample?
Sample are available, but please afford sample costs and express fee.
B) Sample lead time?
Existing items: Within 7-10 days.
C) Do you offer OEM service and marked our logo on the products?
Yes, We offer OEM services.
D) What is the delivery time?
Normally, delivery time is 20-30days after order.
E) How to guarantee the quality of your products?
1) We have strict quality control system, every product has been strictly inspect and stamped QC psssed before shipping out.
2) Strictsampling inspection on products before shipment and intact product packaging ensured.
