All in One Industrial Tablet PC 10.1 Inch Type IPC OS Linux Warranty 1 Year Memory 1GB DDR3 Frequency 1.4GHz Trademark
1-49 Piece
$17950-98 Piece
$16499 Piece
$155Product information
High-quality All in One Industrial Tablet PC 10.1 Inch Type IPC OS Linux Warranty 1 Year Memory 1GB DDR3 Frequency 1.4GHz Trademark supplied by Guangzhou Weiqian Computer Technology Co.,ltd. Bulk wholesale pricing ranges from $155 to $179 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Warranty:
1 Year
Frequency:
1.4GHz
Production Capacity:
100000PCS/Year
Resolution:
1280X800
Memory:
1GB DDR3
Transport Package:
1PC/ OPP Bag/ Carton Box
Specification:
33*22*7.5CM
Screen Size:
6-10''
Specifications
Warranty:
1 Year
Frequency:
1.4GHz
Production Capacity:
100000PCS/Year
Resolution:
1280X800
Memory:
1GB DDR3
Transport Package:
1PC/ OPP Bag/ Carton Box
Specification:
33*22*7.5CM
Screen Size:
6-10''
HS Code:
8473309000
Flash:
8GB Nandflash
Certification:
CE
Power Supply Type:
DC 12V~24V
Installation:
Embedded
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Guangdong Province, China
Port Of Loading:
Guangzhou Port
Type:
IPC
Payment Term:
LC, T/T, Western Union, Small-amount payment
OS:
Linux
Support Custom:
OEM/ODM
CPU:
Quad-Core Cortex A9 Architecture
Touch Screen:
Touch Screen
Model NO.:
WLX-101R-SP10
Trademark:
WQ/OEM
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2005-12-19
Annual Revenue Amount:
Not specified
Numbers Of Employees:
77
Preferred Payment Term:
LC, T/T, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Guangzhou Port
Certificates:
CE
Product descriptions from the supplier
All in One Industrial Tablet PC 10.1 Inch
All in One Industrial Tablet PC 10.1 Inch
1.Parameter
|
Product model |
WLX-101R-SP10 |
|
Basic parameters |
CPU:Quad-core Cortex®-A9 , frequency 1.4GHz Memory:1GB DDR3 Flash:8GB NandFlash |
|
Display screen |
Size:10.1 inch Resolution:1280×800 Wide-temperature type,16000k colors or 24 true colors LED backlight:lifetime > 25000 hours |
|
Touch screen |
Capacitance/Resistance touch screen |
|
Hardware interface |
4 channel 3-wire RS-232 serial port(COM1,COM2,COM3,COM4).( isolated as optional) 2 channel RS-485(COM1,COM2),multiplex as RS-232 (COM1,COM2).( isolated as optional) 1 channel isolatedCAN bus.(optional).
1 channel USB device interface, support ADB connect to PC to exchange date and debug application .
2 channel USB Host interface,support usual USB device such as mouse, keyboard, U disk ,etc. 1 channel 100M Ethernet interface. 1 channel SD/MMC slot,support MMC /mini SD card. 1 channel 3.5mm earphone output interface. 1 channel WIFI interface.(optional) 1 channel Bluetooth interface.(optional) 1 channel DC 12V~24V,industrial power solution,higher reliability. |
| Attention | When the serial port is connected, The GND wire of the two devices must be connected to avoid burning the serial chip and affecting communication. |
|
OS |
Linux |
|
Defend degree |
IP65 (front panel) |
|
Working environment |
power:DC 12V-24V ( 24V as recommendation) working temperature:-20~60ºC storage temperature:-20~80ºC working humidity:10~90%RH |
|
Size |
shell structure:plastic panel size:275.00×181.00 (mm) trepanning size:266.00×171 .00 (mm) |
|
Application area |
industrial control,detection device,instruments and meters,security monitoring,medical apparatus and instruments, intelligent terminals embedded high-end application. Support CAN bus network deployment. |
|
Software support |
Support Eclipse, QT Creator, Arm linux gcc/g++ compiler, shell programming, STL library, Python2.7
development, support JAVA/C/C++/C# ,etc . Easy change the user-defined splash screen. Support display screen rotation (degree: 0/90/180/270). |
2.Interface definiton
|
1. CANL |
2. CANH |
|
3. GND |
4. COM3-RX of RS-232 |
|
5. COM3-TX of RS-232 |
6. COM4-RX of RS-232 |
|
7. COM4-TX of RS-232 |
8. COM2-485B |
|
9. COM2-485A |
10. GND |
|
11. COM1-485B |
12. COM1-485A |
|
1. USB Slave interface (USB Device) |
2. USB Host interface(USB host) |
|
3. Stereo audio interface |
4.DB9-RS-232 interface (COM1) |
|
5.DB9-RS-232 interface (COM2) |
6.100m Ethernet interface |
2.1 RS-232 interface
4 channel serial port,support the highest-level baudrate 115200bps. The corresponding interface inLinux system is COM1 ~ COM4. Specially COM1 and COM2 have 2 output type as RS-232 and RS-485.
2.2 RS-485 interface
The corresponding port in Linux system is COM1,COM2, and COM1/COM2 is a multiplexing of RS-232 interface ( COM1/COM2 ). Also, without terminal resistance inside ,pls specify once in need.
2.3 CAN Bus interface
The function of Can-bus interface is optional . Also, without terminal resistance inside ,pls specify once in need.
2.4 Power interface
3. Exterior size
Exterior size:275x181x42 (mm) Trepanning size:266 x171 (mm)
Transport and Packing process
Express (UPS,DHL,Fedex,EMS,etc) is available.
Sea and Air delivery is available.
Delivery Time
Samples: 1-5 working days
100PCS or More orders: 10-20 working days
Our service:
1. We guarantee that all products have been checked and packaged in good condition before dispatch. We strive for 100% customer satisfaction on every sale we complete.
2. Our products are direct from own factory, there is no middle man, no high markup, so we can provide quality items for a very competitive price.
3. Whether you are not satisfied with our products and services or you have any otherquestions, Please contact us at first time. We will respond you at 24 hours.
Warranty conditions
1.All products have 1 year warranty, no artificially damaged.
2.If there are some problems with the goods, the buyer needs to supply related documents (Photos, video etc) or damage to the original spare parts to old change new. Please contact the seller before you disassemble machines. please note, we will be not responsible for the goods you disassemble any goods without the seller's permit.
FAQ
Q: whether your industrial panel pc support the OEM / ODM?
A: Yes, our industrial panel PC support the customization with size, function, appearance, resolution, high brightness and etc.
Q: Where is your panel pc / Tablet pc apply?
A: Restaruant, Advertisement, Gaming, Medical Equipment, kiosk, ATM, Industrial autamation, Supermarket chain stores,industrial control,detection device,instruments and meters,security monitoring,intelligent terminals embedded high-end application,etc .
Q: What is the main size for your panel pc and industrial monitor?
A: 7",8", 10.1", 10.4",11.6", 12", 13.3" 15", 15.6", 17" 19" 21.5" 22" and wide screen the same zise. We also support the customized.
Q: Can we printing our logo on the housing? What is MOQ?
A: Except the opening logo, we can do the silk-printing LOGO in the case. MOQ is 200pcs .
Q: What kind of inspection you can provide?
A: Weiqian has multiple tests from material purchasing to finished products by different departments, like QA, QC, sales representative, to guarantee all signage players are in perfect condition before shipment.
Q: What is your guarantee period?
A: 1 Years Quality Quarantee !
