Anti-Static Homogeneous PVC ESD Floor/Flooring Origin China Trademark ECW Condition New Model NO. M-PVC Material Rubber HS Code
Meters
Negotiable
Product information
High-quality Anti-Static Homogeneous PVC ESD Floor/Flooring Origin China Trademark ECW Condition New Model NO. M-PVC Material Rubber HS Code supplied by ESD CONDUCTIVE CO., LTD. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
1000000PC
HS Code:
4016910000
Specification:
600*600, 900*900mm
Origin:
China
Trademark:
ECW
Trade Term:
FOB, CFR, CIF, DDP, FCA, EXW
Model NO.:
M-PVC
Condition:
New
Specifications
Production Capacity:
1000000PC
HS Code:
4016910000
Specification:
600*600, 900*900mm
Origin:
China
Trademark:
ECW
Trade Term:
FOB, CFR, CIF, DDP, FCA, EXW
Model NO.:
M-PVC
Condition:
New
Material:
Rubber
Usage:
SMT Production Line, Printing Workshop, Computer Room, Electronic Component Maintenance Room, Combustible & Explosive Area
Port Of Loading:
Shenzhen
Payment Term:
T/T, D/P, PayPal, Western Union
Waterproof:
Waterproof
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-08-22
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, D/P, PayPal, Western Union
Preferred Trade Term:
FOB, CFR, CIF, DDP, FCA, EXW
Port Of Loading:
Shenzhen
Certificates:
CE Certificate, DC-001 CE, ESD Mat ROHS 10, esd shoe test report, Ionizer ROHS, ISO9001, PSE Certificate
Product descriptions from the supplier
Electronics Factory Anti-static ESD Flooring Mat
Product introduction
The anti-static plastic floor uses theAnti-staticnetwork to make it have anti-static function and has good decorative effect. The product is mainly used in electronic computer room, clean room, program-controlled switch room and electronic equipment manufacturing. The production facilities of the microelectronics industry, such as production plants, sterile rooms, central control rooms, etc., require purification and anti-static floor decoration. It is widely used in banking, post and telecommunications, railway, transportation, medicine, microelectronics industry, electronic instrument industry and other fields.
Specification
Construction process:
1,base treatment: use sanding machine to remove sand, oil, remnants, etc. from the surface of the base layer;
2,Interface agent: After the ground is thoroughly cleaned, evenly roll the interfaceonce;
3,Self-leveling:Pour self-leveling cement onto the construction ground in sequence, and scraped with a squeegee scraper, and the thickness is about 2~4mm;
4,Positioning of the line: According to the design pattern, PVC anti-static floor specifications, room size, division, and line positioning;
5,Conductive Adhesive: Use PVC anti-static floor special conductive adhesive, evenly scrape with a squeegee scraper:
6,Fix copper foil:Laya copper foil strip on the ground according to the specified size to form a network;
7, Laying theAnti-staticfloor: starting from the center position, spread out from block to block, the gap between each floor is 2-3 mm;
8, Floor slotting: U-shaped diameter 2.0-2.5 mm;
9, Floor welding rod: Φ3.5-4.0 mm PVC special welding rod;
10, Floor welding: use 800-1000W welding torch to weld along the gap between the floors, and the welding rod should be shoveled to the same level as the surface plate;
11, Floor waxing: The surface must be cleaned for polishing and waxing.
10 Construction completed: It can be used normally after 12 hours (25°C, the low temperature opening time should be moderately extended).
Maintenance
1. It is strictly forbidden to wear nailed shoes on the floor.
2. It is strictly forbidden to sculpt hard objects and hardware on the floor, especially the equipment transportation route and the surrounding of the installation equipment should be lined with plywood to prevent floor scratches and oil stains.
3. Do not drag the machine on the floor when handling the equipment.
4. It is strictly forbidden to scrub the floor surface with corrosive solvents.
5. The production work area should wear special shoes or foot covers to enter the work area, and dust is strictly prohibited from entering the work place.
6. It is strictly forbidden to infiltrate the surface of the floor with strong penetrating ink and mechanical oil.
7. The tires used in the production site trolleys should avoid the easily decolorized black rubber tires. It is recommended to use nylon tires.
8. The surface of the floor is indeed polluted. Clean the floor surface with gasoline, wash and decontamination powder, and then apply anti-static wax on the surface.
9. The floor is generally cleaned once a year, and then treated with anti-static wax.
Product introduction
The anti-static plastic floor uses theAnti-staticnetwork to make it have anti-static function and has good decorative effect. The product is mainly used in electronic computer room, clean room, program-controlled switch room and electronic equipment manufacturing. The production facilities of the microelectronics industry, such as production plants, sterile rooms, central control rooms, etc., require purification and anti-static floor decoration. It is widely used in banking, post and telecommunications, railway, transportation, medicine, microelectronics industry, electronic instrument industry and other fields.
Specification
| Item | Parameter | |
| THICKNESS | 2.0mm 2.5mm 3.0mm | |
| SIZE | 600mm*600mm 610mm*610mm 900mm*900mm |
|
| Surface resistance | CONDUCTIVE TILE | DISSIPATIVE TILE |
| 2.5*10^4~10^6ohm | 10^6~10^8ohm | |
| DECAY TIME(±1000V±100V≤2s) | Average0.4S | |
| Friction voltage (-100V |
Average70 | |
| FIRE RESISTANCE GRADE | B1 | |
| COMBUSTION PERFORMANCE(<10S,FV-0) | Average0.35s FV-0 | |
| AMOUNT OF ANTI-WEAR | Average0.014 | |
| ANTI-WEAR PROPERTIES | ITEN-T<2.0mm3 | |
| WHEEL PRESSURE | No influence | |
| RESIDUAL CONCAVITY |
0.03mm(2.0mm) 0.035mm(2.5mm) 0.04mm(3.0mm) |
|
| DIMENSIONAL STABILITY | ≥0.10% | |
| COLOR FASTNESS | At least 6 | |
| RESISTANCE TO CHENMICALS | Weakly alkaline,weak acid | |
| IMPACT SOUND ABSORPTION | Approx 2dB | |
| STANDARD FOR HEALTH CARE F | Confirms to the requirement of NFPA99 in effect at the tine of installation | |
1,base treatment: use sanding machine to remove sand, oil, remnants, etc. from the surface of the base layer;
2,Interface agent: After the ground is thoroughly cleaned, evenly roll the interfaceonce;
3,Self-leveling:Pour self-leveling cement onto the construction ground in sequence, and scraped with a squeegee scraper, and the thickness is about 2~4mm;
4,Positioning of the line: According to the design pattern, PVC anti-static floor specifications, room size, division, and line positioning;
5,Conductive Adhesive: Use PVC anti-static floor special conductive adhesive, evenly scrape with a squeegee scraper:
6,Fix copper foil:Laya copper foil strip on the ground according to the specified size to form a network;
7, Laying theAnti-staticfloor: starting from the center position, spread out from block to block, the gap between each floor is 2-3 mm;
8, Floor slotting: U-shaped diameter 2.0-2.5 mm;
9, Floor welding rod: Φ3.5-4.0 mm PVC special welding rod;
10, Floor welding: use 800-1000W welding torch to weld along the gap between the floors, and the welding rod should be shoveled to the same level as the surface plate;
11, Floor waxing: The surface must be cleaned for polishing and waxing.
10 Construction completed: It can be used normally after 12 hours (25°C, the low temperature opening time should be moderately extended).
Maintenance
1. It is strictly forbidden to wear nailed shoes on the floor.
2. It is strictly forbidden to sculpt hard objects and hardware on the floor, especially the equipment transportation route and the surrounding of the installation equipment should be lined with plywood to prevent floor scratches and oil stains.
3. Do not drag the machine on the floor when handling the equipment.
4. It is strictly forbidden to scrub the floor surface with corrosive solvents.
5. The production work area should wear special shoes or foot covers to enter the work area, and dust is strictly prohibited from entering the work place.
6. It is strictly forbidden to infiltrate the surface of the floor with strong penetrating ink and mechanical oil.
7. The tires used in the production site trolleys should avoid the easily decolorized black rubber tires. It is recommended to use nylon tires.
8. The surface of the floor is indeed polluted. Clean the floor surface with gasoline, wash and decontamination powder, and then apply anti-static wax on the surface.
9. The floor is generally cleaned once a year, and then treated with anti-static wax.
