Authentic Special Promotion Welding Fixture Table 3D Welding Table
1-9 Piece
$1,00010 Piece
$600Product information
High-quality Authentic Special Promotion Welding Fixture Table 3D Welding Table supplied by Botou Tianjian Measuring Tool Co., Ltd.. Bulk wholesale pricing ranges from $600 to $1,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Tilting Angle:
0
Rotaion Speed:
0
Max Eccentricity Distance:
0
Warranty Period:
1 Year
Package Size:
100.00cm * 200.00cm * 30.00cm
Voltage:
110V/220V
Hole Diameter:
16mm or 28mm
Package Gross Weight:
400.000kg
Specifications
Tilting Angle:
0
Rotaion Speed:
0
Max Eccentricity Distance:
0
Warranty Period:
1 Year
Package Size:
100.00cm * 200.00cm * 30.00cm
Voltage:
110V/220V
Hole Diameter:
16mm or 28mm
Package Gross Weight:
400.000kg
Precision Machined Working Surfaces:
5 or 1
Hole Pattern:
50*50mm and 100*100mm
HS Code:
8515900090
Welding Turning Rolls Type:
Adjustable
Accessories:
Available
Material:
Cast Iron/Steel/DIN St52-3
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, EXW, CFR, CIF, DAT, DDP, DAP, CIP, CPT, FCA
Welding Tilter Type:
Flexible Combination
Surface Treatment:
Heat Treatment, Nitrogen Treatment
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Money Gram, Small-amount payment
Supporting:
Legs or Steel Frame
Condition:
New
Transport Package:
Plywood Box
Payment Methods:
Support payments in USD
Trademark:
TJ
Port Of Loading:
Tianjin Port
Purpose:
Welding
Model NO.:
complete
Specification:
customized
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2011-11-17
Annual Revenue Amount:
Not specified
Numbers Of Employees:
12
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Money Gram, Small-amount payment
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAT, DDP, DAP, CIP, CPT, FCA
Port Of Loading:
Tianjin Port
Certificates:
CE
Product descriptions from the supplier
| No | Product name | Size(mm) | Item number | |
| 1 | 3D Steel /Cast iron Welding table | 1000x1000x200 | TJ2810001 | |
| 2 | 1200x1200x200 | TJ2810002 | ||
| 3 | 1500x1000x200 | TJ2810003 | ||
| 4 | 1500x1500x200 | TJ2810004 | ||
| 5 | 2000x1000x200 | TJ2810005 | ||
| 6 | 2400x1200x200 | TJ2810006 | ||
| 7 | 3000x1500x200 | TJ2810007 | ||
| 8 | 4000x2000x200 | TJ2810008 | ||
| 9 | 2D Steel / Cast iron Welding Table | 1000×1000x150 | TJ2810009 | |
| 10 | 1200×1200x150 | TJ28100010 | ||
| 11 | 1500×1500x150 | TJ28100011 |
Welding Table:
1.The welding table is divided into two series according to the hole system: Φ28 and Φ16.
2.It is divided into two-dimensional flexible combination tooling and three-dimensional flexible combination tooling according to the structure.
3.The tooling platform is divided into steel piece platform and cast iron platform according to materials.
4.The grid is engraved with corresponding grid lines.
5.According to customer requirements, the measuring scales can be drawn on the four sides of the platform
6.The Nitride finish protects the welding table against rust and weld spatter to make sure that the welding tables surface is kept extremely clean and accurate for fixturing.
Optional components:
| 5-Sided 3D welding table | 1- Sided 2D welding table |
| This welding workbench has five work surfaces, namely its front and four sides. The positioning piece can be installed on any of its five working surfaces. Additionally, the welding table can be expanded via any of its five work surfaces. | 2D Welding Table is a typically flat and stationary welding table which used for the purpose of welding various metal components together in workshops, factories and other industrial environments |
| Plasma nitriding three-dimensional flexible welding platform (material steel Q355/cast iron HT300) | Plasma nitriding three-dimensional flexible welding platform (material steel Q355/cast iron HT300) |
-D28 system:
Hole diameter: 28mm (Drilled and milled hole)
Table thickness: 24-27mm
grid spacing: 100±0.05mm
2 ton weight loading capacity.
Hole diameter: 28mm (Drilled and milled hole)
Table thickness: 24-27mm
grid spacing: 100±0.05mm
2 ton weight loading capacity.
-D16 system:
Hole diameter: 16mm (Drilled and milled hole)
Table thickness: 14-17mm
grid spacing: 50±0.05mm
2 ton weight loading capacity.
Hole diameter: 16mm (Drilled and milled hole)
Table thickness: 14-17mm
grid spacing: 50±0.05mm
2 ton weight loading capacity.
1. Tools for supporting: U-Shaped cube case, L-shaped cube case, Angle supporting, and Angle gauge.
2. Spare parts for Locating: positioning square, positioning ruler, flat square, V-shaped positioning piece.
3. Tools for clamping: fixed quick clamping piece (screw clamping), retractable clamping piece (screw clamping), 45 degree clamping piece (screw clamping), etc.
4. Tools for fixing: quick locking pin, countersunk locking pin, countersunk quick locking pin.
5. Accessories and auxiliary parts: height adjuster, lifting ring, tool cart, grounding device, adjusting gasket, hexagon wrench, nylon brush, oil stone, oil can.
5. Accessories and auxiliary parts: height adjuster, lifting ring, tool cart, grounding device, adjusting gasket, hexagon wrench, nylon brush, oil stone, oil can.
1.Flexible
The three-dimensional welding platform is strong and can withstand high loads. All five sides are processed with regular holes and engraved with network cables.
2.Repeatable
The accessories are assembled quickly and easily, and the work surface can be combined according to the shape and size of the workpiece and can be reused.
3.Precise
The accuracy meets most welding and assembly work, and the center tolerance of the positioning hole on the work platform is small.
4.Economical
Products with multiple parts can be quickly assembled and then welded, thereby improving the welding accuracy and efficiency of the workpiece.
It is a company that produces and processes casting tools, measuring tools and other products. It has a complete and scientific quality management system. The integrity, strength and product quality of Botou Tianjian Measuring Tools Co., Ltd. have been recognized by the industry. Friends from all walks of life are welcome to visit, provide guidance and negotiate business.
Our company's main products include: cast iron platforms, marking platforms, 3D /2D welding tables, T-slot assembly platforms, boring and milling machine tool tables, three-coordinate platforms, test platforms, magnesium-aluminum lightweight flat rulers, cast iron flat flat rulers, Bridge-type flat ruler, square ruler, right-angle ruler, special angle ruler for machine tools, inspection square box, scribing square box, magnetic square box, magnetic V-shaped frame, deflection checker, gear runout checker, high-precision deflection checker, New deflection checker, machine tool inspection rod, machine tool adjustment pad, machine tool anti-vibration pad, step pad, contour pad, cast iron shaped iron, steel V-shaped frame, cast iron bent plate, chrome-plated jack, granite flat plate , flat ruler, square ruler, square box, parallel gauge, granite machine tool guide rail, T-slot workbench, three coordinate measuring machine components, granite adjustable pillar, profile block, profile frame, granite watch base, etc. Measuring tools, and various non-standard measuring tools can also be customized (the user needs to attach drawings).
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging sevices will be provided.
Q1. Are you manufacturer or trade company ?
A:We are professional manufacturer in China , and have in this line almost 10 years .
Q2. Would it be possible for us to visit your factory ?
A:Sure, welcome you at any time !
Q3. How can we get the quotation ?
A:Please let us know the specifications of theplatforms, such as the Material, Size,Hole spacing, ect
Q4. How can I start the order?
A:You could place the order directly or we can send you the proforma invoice with our bank details. After we received the down payment, we will start the production.
Q5. Lead time:
A:The order lead time is need 15-25 days after receiving deposit.
Q6. Do you have after sales support?
A: Yes, we have rich experience in handling after-sales issues via video or email. Meanwhile the engineers are available to service overseas. We have agents in different countries too if you want local service or sample testing.
