Auto Parking System/Rotary Parking /Car Lift Design 12 Post Trademark GAOLI Lift Mode Chain Capacity 2000 Kg HS Code
1 Piece
$1,0001 Piece
$50,000Product information
High-quality Auto Parking System/Rotary Parking /Car Lift Design 12 Post Trademark GAOLI Lift Mode Chain Capacity 2000 Kg HS Code supplied by GAOLI Equipments and Machinery Co., Ltd.. Bulk wholesale pricing ranges from $1,000 to $50,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Design:
12 Post
Capacity:
2000 Kg
Voltage:
380V/50Hz/3 Pahse
Production Capacity:
50 Sets/Month
HS Code:
84289020
Certification:
CE, ISO, CCC
The Vehicle Inlet And Outlet:
Center
Lift Mode:
Chain
Specifications
Design:
12 Post
Capacity:
2000 Kg
Voltage:
380V/50Hz/3 Pahse
Production Capacity:
50 Sets/Month
HS Code:
84289020
Certification:
CE, ISO, CCC
The Vehicle Inlet And Outlet:
Center
Lift Mode:
Chain
Origin:
China, Jiangsu
Trade Term:
FOB, CIF, CFR, EXW
Trademark:
GAOLI
Surface Treatment:
Galvanized
Driving Motor:
Gaoli
Payment Term:
LC, T/T, D/P, PayPal
Driving:
Moter and Reducer
Model NO.:
PCXLD-7
Parking Type:
Self Parking System
Falling Prevention Device:
Shaft
Port Of Loading:
Shanghai Port
Working Mode:
Unmanned
Transport Package:
as Required
Specification:
as required
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2003-08-14
Annual Revenue Amount:
Not specified
Numbers Of Employees:
188
Preferred Payment Term:
LC, T/T, D/P, PayPal
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
Certificates, Certificates2, ISO 9001
Product descriptions from the supplier
Auto Parking System/Rotary Parking /Car Lift
Nowadays, the number of vehicles is increasing rapidly with the development of economy, as the result of which, parking has become a prominent social problem. The traditional parking lot has been far from meeting the needs of both the Villa / residential / hotel / shopping mall, or school / hospital / business unit. Problems caused by parking have been a serious impact on our life and work.
Development and installing mechanical stereo garage is an effective way to solve this problem. More and more governments have issued special planning of urban parking, with the implementation of preferential policies; the economy of parking system will attain great-leap-forward development, making the golden age of the parking industry.
Vertical Circulation Series
1.Description
OPERATION:
Motor drives the transmission mechanism together with reducer; parking plates are installed with regular intervals on the traction chain. When the motor starts, parking plates circulates together with the traction chain, 50 as to realize the function of parking and retrieving vehicles
When parking, drive the car to the empty parking plate, leave and lock the car, then press the operation button. Another empty parking plate would automatically moves down to the entrance for the next vehicle.
When retrieving the vehicle, press the parking plate number or swipe the parking card, the system will automatically choose the shortest way to move the vehicle down to the entrance shortly, then the driver can entry to drive the vehicle out.
2. PRODUCT FEATURES
1. High land-utilizing efficiency. Each unit of system covers only 35 sq., providing up to 16 parking
spaces
2. Flexible configuration. It can be set independently or attached inside buildings in one number or many in a raw. For small vertical circulation system, it can be easily installed in empty spaces in
Residential neighborhoods or besides commercial buildings
3 ,Vertical circulation system is designed with the transmission mechanism that saves 1/2 power
and increases 200% efficiency
4 ,Central electronic control system is PLC programmable control, which realized highly automatic parking and parking reservation. It is designed with IC card and button boards for easy parking operation. The button board can choose the right transferring direction , show the parking plate and guide the driver to park and retrieve the vehicle
5, Safety settings. a), Emergency brake switch. b) Overrun device c)Over length and height
photoelectricity monitoring device. d)Car block device V. Photoelectricity monitoring device for
accidental entry of people and vehicle
6,Fast parking experience, the system is designed for fast parking in places where vehicles are
concentrated
7 ,The exterior wall can be used for advertisement to improve economic performance
8 ,Covering celling is available to protect the equipment and vehicles
3.Specification
Nowadays, the number of vehicles is increasing rapidly with the development of economy, as the result of which, parking has become a prominent social problem. The traditional parking lot has been far from meeting the needs of both the Villa / residential / hotel / shopping mall, or school / hospital / business unit. Problems caused by parking have been a serious impact on our life and work.
Development and installing mechanical stereo garage is an effective way to solve this problem. More and more governments have issued special planning of urban parking, with the implementation of preferential policies; the economy of parking system will attain great-leap-forward development, making the golden age of the parking industry.
Vertical Circulation Series
1.Description
OPERATION:
Motor drives the transmission mechanism together with reducer; parking plates are installed with regular intervals on the traction chain. When the motor starts, parking plates circulates together with the traction chain, 50 as to realize the function of parking and retrieving vehicles
When parking, drive the car to the empty parking plate, leave and lock the car, then press the operation button. Another empty parking plate would automatically moves down to the entrance for the next vehicle.
When retrieving the vehicle, press the parking plate number or swipe the parking card, the system will automatically choose the shortest way to move the vehicle down to the entrance shortly, then the driver can entry to drive the vehicle out.
2. PRODUCT FEATURES
1. High land-utilizing efficiency. Each unit of system covers only 35 sq., providing up to 16 parking
spaces
2. Flexible configuration. It can be set independently or attached inside buildings in one number or many in a raw. For small vertical circulation system, it can be easily installed in empty spaces in
Residential neighborhoods or besides commercial buildings
3 ,Vertical circulation system is designed with the transmission mechanism that saves 1/2 power
and increases 200% efficiency
4 ,Central electronic control system is PLC programmable control, which realized highly automatic parking and parking reservation. It is designed with IC card and button boards for easy parking operation. The button board can choose the right transferring direction , show the parking plate and guide the driver to park and retrieve the vehicle
5, Safety settings. a), Emergency brake switch. b) Overrun device c)Over length and height
photoelectricity monitoring device. d)Car block device V. Photoelectricity monitoring device for
accidental entry of people and vehicle
6,Fast parking experience, the system is designed for fast parking in places where vehicles are
concentrated
7 ,The exterior wall can be used for advertisement to improve economic performance
8 ,Covering celling is available to protect the equipment and vehicles
3.Specification
| Model | PCXLD-7 | |||
| Suitable Autos |
Qty. of parking lifts | 12 Normal Vehicle | 8 SUV | |
| Size | L | 5000mm | ||
| W | 1850mm | |||
| H | 1550mm | 2050mm | ||
| Weight | ≤2000kg | |||
| Drive Mode | Reducer & Motor | |||
| Lifting speed | 4.1m/min | |||
| Motor Power | 9.2kw | |||
| Operation | Card/Button | |||
| Power | 3 phase 380V 50HZ | |||
| Remark: Qty and board size can be customize | ||||
4.Company profile:
Established in August 2003, GAOLI Engineering Machinery Co., Ltd, is headquartered at Tongjing Town of Jiangning District, Nanjing, covering an area of 36,000 square meters, and a construction area of 20,000 square meters.
GAOLI will continue to adhere to the business philosophy of "Customer Supreme, Quality First and Pursuit of Excellence", form an interest community with customers and partners, and bring GAOLI brand, capital, technology and market strength into full play to further improve service quality and capability, providing customers with high quality and technologically advanced products and services. "To achieve your dreams, we will continue our efforts!"
5. FAQ
1 .Q: Are you factory?
A: Yes, we are a factory that located in Nanjing for over 10 years
- Q:what is the delivery time?
A: It is according to the machine you need.
- Q: How is the machine packed?
A: Each packed in carton, then put in wooden case, and then in container.
- Q:Why choose us?
A: We own high-quality, reasonable price. If purchase now,
we will supply you one set assembly auxiliary tools and one set wearing parts.
- Q:Can we visiting your factory?
A: We warmly welcome your visiting!
