Automated Filter Press System for Advanced Sludge Dewatering
Piece
Negotiable
Product information
High-quality Automated Filter Press System for Advanced Sludge Dewatering supplied by Jining Yalong Chemical Equipment Co., Ltd. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Specification:
1500 membrane filter press
Power:
2.2-15 Kw
Lead Time:
30 days (1 - 1 Pieces)To be negotiated ( > 1 Pieces)
Package Gross Weight:
3500.000kg
Package Size:
370.00cm * 190.00cm * 160.00cm
Production Capacity:
4000 Units /Year
HS Code:
8421291090
Cake Discharging:
Automatic
Specifications
Specification:
1500 membrane filter press
Power:
2.2-15 Kw
Lead Time:
30 days (1 - 1 Pieces)To be negotiated ( > 1 Pieces)
Package Gross Weight:
3500.000kg
Package Size:
370.00cm * 190.00cm * 160.00cm
Production Capacity:
4000 Units /Year
HS Code:
8421291090
Cake Discharging:
Automatic
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Liquid Discharging 2:
Closed Flow Membrane Filter Press
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Type:
Diaphragm Filter Press
Trade Term:
FOB, EXW, CFR, CIF, DDP, FCA, DAT, FAS, DAP, CIP, CPT
Pressure:
Hydraulic Pressure
Payment Term:
LC, T/T, D/P, Western Union, Small-amount payment, Money Gram, PayPal
Liquid Discharging 1:
Open Flow Membrane Filter Press
Port Of Loading:
Qingdao, Tianjin, Rizhao
Payment Methods:
Support payments in USD
Transport Package:
Wooden Case
Model NO.:
XMGZ 500/1500
Trademark:
jingjin
Filtering Pressure:
≤0.8 MPa
Squeezing Pressure:
≤1.2 MPa
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2025-11-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, Western Union, Small-amount payment, Money Gram, PayPal
Preferred Trade Term:
FOB, EXW, CFR, CIF, DDP, FCA, DAT, FAS, DAP, CIP, CPT
Port Of Loading:
Qingdao, Tianjin, Rizhao
Product descriptions from the supplier
SONA2024 2.2.1
Competitive pricing & bulk discounts
Fast shipping & customs clearance support
Turnkey project solutions
Dryer
Reactor
Centrifuge
Product Description of Filter Press
A diaphragm filter press is a type of filter press equipped with elastic diaphragms installed between the filter plates and the filter cloths. During operation, once the feeding process is completed, high-pressure fluid or gas can be injected into the diaphragm plates. This causes the entire diaphragm to expand and compress the filter cake, thereby achieving further dewatering—a process commonly referred to as squeeze filtration.
Description
A diaphragm filter press is a solid-liquid separation device that utilizes an elastic diaphragm to perform secondary squeezing of the filter cake, primarily used in industries such as chemical, environmental protection, pharmaceutical, and food processing. By incorporating diaphragm technology into the filter plates, it significantly enhances the solid dryness. Compared to traditional filtration processes, it achieves the lowest residual moisture content in the filter cake, making it one of the most robust and widely applied systems. Special materials such as PVDF are also available for specific requirements.
The working principle involves adding an elastic membrane between the filter plates and the filter cloth of a standard filter press. After the filter chamber completes feeding, high-pressure fluid or gas is injected into the diaphragm, causing it to expand and compress the filter cake. This further squeezes liquid out of the filter cake, significantly reducing its moisture content.
right elevation
left elevation
front elevation
Technical Specifications
Model | XMGY 30/870 | XMGZ 100/1000 | XAGZ 250/1250 | XMGZ 300/1500 |
Plate QTY (PCS) | 23 | 50 | 91 | 73 |
Filtering Area (m2) | 30 | 100 | 250 | 300 |
Filtering Volume (L) | 427 | 1378 | 4186 | 4932 |
Cake Discharging | Manual | Automatic | Automatic | Automatic |
Plate Size (mm) | 870 | 1000 | 1250 | 1500 |
Hydraulic Power (kw) | 4 | 4 | 5.5 | 7.5 |
Advantages of diaphragm filter press
1.High Solid-Liquid Separation Efficiency: Through secondary pressing, the moisture content of the filter cake is significantly reduced, resulting in improved separation effectiveness.
2.High Level of Automation: Many units are equipped with programmable control systems, enabling fully automated operations including feeding, filtration, pressing, and cake discharge.
3.Flexible Operation: The degree of compression can be adjusted by controlling the pressure and duration of diaphragm inflation to suit different material requirements.
4.Wide Range of Applications: Widely utilized in industries requiring efficient solid-liquid separation and low filter cake moisture, such as chemical processing, metallurgy, mining, food processing, and wastewater treatment.
5.Customization options are available to tailor the filter press to meet specific process requirements.
After Sales Service
Standard Warranty:12 months or 2,000 operating hours (whichever comes first).
Extended Warranty:Optional coverage up to 36 months.
Global Support:24/7 technical assistance and spare parts supply.
Training:On-site or remote operation/maintenance training.
Extended Warranty:Optional coverage up to 36 months.
Global Support:24/7 technical assistance and spare parts supply.
Training:On-site or remote operation/maintenance training.
Company Profile
Yalong chemical equipment co., ltd
Yalong Chemical Equipment Co., Ltd. is a globally operating comprehensive service provider for chemical equipment, dedicated to delivering full-range solutions to clients worldwide across the chemical, pharmaceutical, food, environmental protection, and new materials industries. We not only supply high-quality equipment but also place strong emphasis on providing end-to-end knowledge-based services and technical support—from preliminary design and process customization to installation, commissioning, and technical training.
Our main products include reactors, centrifuges, dryers, filter presses, food and pharmaceutical packaging machines, water filtration and purification equipment, and other related chemical machinery. Leveraging China's mature manufacturing ecosystem and our deep cooperative partnerships with factories, we are able to offer flexible, customizable product configurations and highly competitive pricing tailored to each client's raw material characteristics, process requirements, and production capacity planning.
We deeply understand that chemical equipment is not merely standalone units but integral components of an entire production system. Therefore, we focus on building a value system centered on "technology export and service empowerment," delivering comprehensive services to clients across regions including Southeast Asia, the Middle East, Africa, and South America.
To date, our products and services have successfully entered multiple markets including Southeast Asia, the Middle East, Europe, South America, and Africa. Through helping clients improve production efficiency and achieve industrial upgrading, we have accumulated extensive experience in international projects.
Yalong Chemical consistently adheres to the business philosophy of "Integrity as the Foundation, Customer First, and Win-Win Cooperation." We are committed to moving beyond mere equipment trading by exporting technology and knowledge-based services, striving to become a trusted strategic partner and engineering service provider for clients in the chemical and related industries.
Why Choose Us?
Other Products
OEM/ODM capabilities
Competitive pricing & bulk discounts
Fast shipping & customs clearance support
Turnkey project solutions
Water treatment equipment
Dryer
Reactor
Centrifuge
FAQ
Q: What’s the lead time for orders?
A: Standard models ship in 15–30 days; customized units require 30–45 days.
A: Standard models ship in 15–30 days; customized units require 30–45 days.
Q: Do you provide after-sales service overseas?
A: Yes, we have partnered service centers in key regions.
A: Yes, we have partnered service centers in key regions.
Q: Can I request a customized bucket size?
A: Absolutely! We offer tailored attachments.
A: Absolutely! We offer tailored attachments.
Q: What documents do you provide for export?
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).
Q: How do I place an order?
A: Contact us via email/phone for a quote, then confirm with a PO.
A: Contact us via email/phone for a quote, then confirm with a PO.
