Automatic Paper Box Stripping Machine
1 Set
$50,0001 Set
$20,000Product information
High-quality Automatic Paper Box Stripping Machine supplied by Wenzhou Qianding Machinery technology Co., Ltd.. Bulk wholesale pricing ranges from $20,000 to $50,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Depth Of The Machine:
1480
Fasterst Take Off The Paper:
15-22
Machine Width:
1910
Power Consumption:
20
Max Take Off The Paper:
230*230
Min Take Off The Paper:
30*30
Compressed Aif:
4-7
Max Paper Pile Height:
40
Specifications
Depth Of The Machine:
1480
Fasterst Take Off The Paper:
15-22
Machine Width:
1910
Power Consumption:
20
Max Take Off The Paper:
230*230
Min Take Off The Paper:
30*30
Compressed Aif:
4-7
Max Paper Pile Height:
40
Production Capacity:
50sets/Month
Specification:
680*460*100
Max Force:
70
HS Code:
8441809000
Bench Height:
850
Automatic Grade:
Automatic
Packaging:
Cartons
Trade Term:
FOB, CIF, CFR, EXW
Driven Type:
Hydraulic and Pneumatic
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Port Of Loading:
Ningbo Port, Shanghai Port
Structure:
Pressure Strapping
Trademark:
Qianding
Strapping Mode:
Welding Type
Origin:
Wenzhou
Transport Package:
by Strong Seaworthy Wooden Cases
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2017-06-16
Annual Revenue Amount:
Not specified
Numbers Of Employees:
45
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port, Shanghai Port
Certificates:
SGS CE, Utility patents, etc
Product descriptions from the supplier
Automatic Label/Tags/Hangtags/Cosmetic/Medicine Box/Paper Cup Stripping Machine
This automatic label dismantle machine is mainly used for taking off the material after die cutting, like hangtags, label, etc. For the clothes, glass industry. With much higher efficiency, and higher production than that by hand.
It replaces manual labor, and improves product quality and enterprise benefit.
It adopts servo motor, Taiwan double guide rail and bail screw which makes accuracy less than 0.02mm.
The latest hydraulic system with inserted motor abd oil temperature cooling fan (power 3.75kw). So it has constant and big working pressure.
The complete machine is eqiupped with PLC, and with a touch screen interface in operation.The operation is safe and easy.
Finished Samples For Spain Client.
| Technical Parameters | |||
| Model | HTQF-680 | HTQF-920 | HTQF-1080 |
| Max sheeet size(x) | 680 | 920 | 1080 |
| Max sheet size(z) | 460 | 680 | 780 |
| Max paper pile height | 100 | 100 | 100 |
| Max paper pile height | 40 | 40 | 40 |
Min sheet size(x) |
400 | 550 | 650 |
| Min sheet size(z) | 300 | 400 | 450 |
| Bench height | 850 | 850 | 850 |
| Max Take off the paper | 230x230 | 320x320 | 360x360 |
| Min Take off the paper | 30x30 | 30x30 | 30x30 |
| Fasterst Take off the paper | 15-22 | 15-22 | 15-22 |
| Max force | 70 | 70 | 70 |
| Main technical parameters | |||
| Machine Model | HTQF-680 | HTQF-920 | HTQF-1080 |
| Machine Width(a) | 1910 | 2400 | 2760 |
| Depth Of The Machine(b) | 1480 | 1800 | 2070 |
| Machine Height(C) | 1940 | 1940 | 1960 |
| Machine Net Weight | 1200 | 1600 | 2000 |
| Compressed Aif | 4-7 | 4-7 | 4-7 |
| Gas | 2 | 2 | 2 |
| Power Supply Voltage | 360V-420V,50/60HZ | 360V-420V,50/60HZ | 360V-420V,50/60HZ |
| Power Consumption(maximum)A | 20 | ||
| lnsurance Maximum Current A | 10 | ||
| lnput Power | 3hPE | 3hPE | 3hPE |
This series of products suitable for the strip process after die cutting,Save lots of labor lmprove the quality of products,increase the efficiency of company
Main Technical Parameters
| Model | QF-680 | QF-920 | QF-1080 |
| Max sheeet size(X) | 680 | 920 | 1080 |
| Max sheet size(2) | 460 | 680 | 780 |
| Max paper pile height | 110 | 110 | 110 |
| Min paper pile height | 40 | 40 | 40 |
| Min sheet size(x) | 400 | 550 | 650 |
| Min sheet size(z) | 300 | 400 | 450 |
| Bench height | 850 | 850 | 850 |
| Max Take off the paper | 230x230 | 320x320 | 360x360 |
| Min Take off the paper | 30x30 | 30x30 | 30x30 |
| Fasterst Take off the paper | 25 | 25 | 25 |
| Max force | 70 | 70 | 70 |
Main technical parameters
| Machine Model | QF-680 | QF-920 | QF-1080 |
| Machine Width (a) | 1910 | 2400 | 2760 |
| Depth Of The Machine(b) | 1480 | 1800 | 2070 |
| Machine Height(C) | 1940 | 1940 | 1960 |
| Machine Net Weight | 1100 | 1400 | 1650 |
| Compressed Air | 4-7 | 4-7 | 4-7 |
| Gas | 2 | 2 | 2 |
| Power Supply Voltage | 360V-420V,50/60HZ | 360V-420V,50/60HZ | 360V-420V,50/60HZ |
| Power Consumption( maximun)A | 2.0 | 2.0 | 2.0 |
| nsurance Maximum Current A | 10 | 10 | 10 |
| Input Power | 3hPE | 3hPE | 3hPE |
Pre-sales Service
Inquiry and consulting support.
Sample testing support.
View our factory.
After-sales service
Training how to install the machine, training how to use the machine.
Engineers available to service machinery overseas.
Warranty
Machines are new(or unused) and the gurantee period will be given thireteen months from shipment date. During this period, the seller will provide free maintenance and free spare parts that caused by the machine's quality, but the buyer must pay the courier cost. Parts damaged because of mishanding and consumable parts are not covered by any warranty.
All our machines have CE certificates and passed ISO9001-2008
Welcome you visit our factory to test machine by yourself!
