Automation Integrated Design and Concentration Continuous Production Extractor & Evaporator Process Machine

 Equipment overview

The extraction and concentration machine is a high-efficiency equipment that integrates traditional extraction (such as leaching and percolation) and concentration (such as evaporation and distillation) processes. It is suitable for the simultaneous extraction and concentration of effective ingredients in materials and is widely used in pharmaceutical, food, chemical, environmental protection and other industries. Its core advantage is to shorten the process flow, improve efficiency, reduce energy consumption, and reduce material loss and pollution risks.

1. Pharmaceutical industry
o Extraction of traditional Chinese medicine: such as extraction and concentration of ginsenosides and flavonoids.
o Western medicine raw materials: purification and pre-drying treatment of antibiotics and vitamins.
2. Food industry
o Plant extracts: tea polyphenols, fruit and vegetable juice concentrates, natural pigments (such as chlorophyll).
o Seasonings: extraction and concentration of flavors and spices.
3. Chemical industry
o Solvent recovery: recycling and reuse of organic solvents such as ethanol and acetone.
o Polymer materials: concentration and purification of resin solutions.
4. Environmental protection field
o Wastewater treatment: reduction and resource utilization of high-concentration organic waste liquid.
5. Bioengineering
o Enzyme preparations/fermentation broth: bacterial separation, extraction and concentration of intracellular products.

1. Integrated design
o Extraction and concentration processes are integrated, no transfer container is required, reducing floor space and operation steps.
o Suitable for continuous production and improving the degree of automation.
2. High-efficiency concentration technology
o Adopt vacuum negative pressure, thin film evaporation, multi-effect evaporation and other technologies to quickly remove solvents (such as water, ethanol), and the concentration efficiency is increased by 30%-50%.
o Low-temperature concentration (40-80℃) protects the activity of heat-sensitive ingredients (such as plant extracts and enzyme preparations).
3. Intelligent control
o PLC or touch screen control system, which can set parameters such as temperature, pressure, time, etc., and monitor the operating status in real time.
o Automatic alarm function to prevent abnormal conditions such as dry burning and overpressure.
4. Energy saving and environmental protection
o Heat recovery system (such as secondary steam reuse) reduces energy consumption by 30%-50%.
o Closed design reduces solvent volatilization and meets environmental emission standards.
5. Multifunctional adaptability
o Can handle a variety of solvent systems such as water extraction, alcohol extraction, and oil extraction.
oSupports multiple modes such as dynamic extraction (stirring) and static extraction (immersion).
6. Safe and reliable
oMade of 304/316L stainless steel, corrosion-resistant and explosion-proof design, in line with GMP/FDA certification requirements.
oEquipped with CIP online cleaning system to reduce cross contamination.

1. Extraction function
o Solvent permeation extraction: accelerate the dissolution of active ingredients through heating and stirring.
o Countercurrent extraction: multi-stage countercurrent process improves the extraction rate.
2. Concentration function
o Vacuum decompression concentration: reduce boiling point and reduce thermal damage.
o Thin film evaporation: suitable for high viscosity or easy coking materials.
3. Auxiliary functions
o Filtration: built-in or external filtration device to separate drug residues and extracts.
o Solvent recovery: condensation system recovers organic solvents such as ethanol to reduce costs.
o Data recording: supports process parameter storage and export for easy quality traceability.
