Bba Adhesive Epoxy Dispensing System, Robotic Ab Glue Dispensing Equipment, Liquid Dispenser Robot UV Light Automatic Industrial Glueing Robot Manufacturing
1-2 Piece
$3,5003 Piece
$3,100Product information
High-quality Bba Adhesive Epoxy Dispensing System, Robotic Ab Glue Dispensing Equipment, Liquid Dispenser Robot UV Light Automatic Industrial Glueing Robot Manufacturing supplied by Dongguan City Bobang Intelligent Technology Co., Ltd. Bulk wholesale pricing ranges from $3,100 to $3,500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Repeat Accuracy(Mm):
+/-0.02mm/Axis
Minimum Glue Amount:
0.01ml
Air Pressure:
0.5-0.7MPa
Production Capacity:
2000sets/Month
Warranty:
24 Months
Specification:
300*300*100 (X*Y*Z)@Can be customized
Machine Size:
700*630*700mm
Package Size:
75.00cm * 70.00cm * 85.00cm
Specifications
Repeat Accuracy(Mm):
+/-0.02mm/Axis
Minimum Glue Amount:
0.01ml
Air Pressure:
0.5-0.7MPa
Production Capacity:
2000sets/Month
Warranty:
24 Months
Specification:
300*300*100 (X*Y*Z)@Can be customized
Machine Size:
700*630*700mm
Package Size:
75.00cm * 70.00cm * 85.00cm
Moving Speed:
800mm/S
Machine Weight:
80kg
HS Code:
8479899990
Package Gross Weight:
85.000kg
Maximum Load Weight:
8kg (for Work Platfrom)
Program Capacity:
999 Groups/1000 Points Per Group
Voltage:
AC 110/220V 50/60Hz
Glue Type:
Ab, Hot Melt,Epoxy Resin Adhesive,Silicon etc
Automatic Grade:
Automatic
Product Name:
Automatic Glue Dispensing Machine
Trademark:
BBA
Model NO.:
BBA-331DJ 20240428
Certification:
CE
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Installation:
Desktop
Trade Term:
FOB, CIF, CFR, EXW
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Motor System:
Micro Precision Stepping Motor
Condition:
New
Driven Type:
Pneumatic
Port Of Loading:
Shenzhen Port
Transport Package:
Standard Export Wooden Case Packing
Payment Methods:
Support payments in USD
Control Panel:
Teaching Pendant with Display Screen
Work Condition:
Temperature 0-40; Humidity 20-90%
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2020-02-27
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port
Certificates:
Others
Product descriptions from the supplier
Adhesive epoxy dispensing system, AB glue dispensing equipment, liquid dispenser robot (UV light optional)
Automatic glue dispenser machine is to spray or dispense the glue automatically for bonding, filling, coating, sealing, filling, dripping, linear/arc/round coating, etc. in the product process. BBA Dispensing Systems has the capability to integrate the gluing system with XYZ movements for precised glue dispensing. Adhesive epoxy dispensing system,AB glue dispensing equipment,liquid dispenser robot is for easy programming with teaching pendant, it is applicable for various glue types as Silicon,AB adhesive,epoxy resin adhesive, hot glue,transparent paint and for wide application of electronic products, home appliance etc. BBA can fabricate robotic glue dispenser machine to meet your product requirements.
Automatic glue dispenser machine is to spray or dispense the glue automatically for bonding, filling, coating, sealing, filling, dripping, linear/arc/round coating, etc. in the product process. BBA Dispensing Systems has the capability to integrate the gluing system with XYZ movements for precised glue dispensing. Adhesive epoxy dispensing system,AB glue dispensing equipment,liquid dispenser robot is for easy programming with teaching pendant, it is applicable for various glue types as Silicon,AB adhesive,epoxy resin adhesive, hot glue,transparent paint and for wide application of electronic products, home appliance etc. BBA can fabricate robotic glue dispenser machine to meet your product requirements.
Specification of BBA glue dispensing machine series
| Model | BBA-331DJ (Single Y platform) |
BBA-5331DJ (Double Y platform) |
CUSTOMIZED | ||
| Power supply | AC 220V 50/60HZ | ||||
| Stroke | X | 300mm | X | 500mm | To order |
| Y | 300mm | Y1/Y2 | 300mm | ||
| Z | 100mm | Z | 100mm | ||
| Maximum Load Weight | 8KG (for work platfrom) | To order | |||
| Running track | Dotted, line, arcs and irregular paths | ||||
| Moving speed | 10-800mm/s | ||||
| Air pressure | 0.5-0.7MPa | ||||
| Position accuracy | ±0.05mm/axis | ||||
| Program capacity | 999 groups/1000 points per group | ||||
| Motor system | Micro Precision Stepping Motor | ||||
| Transmission mode | Precision toothed belt+guide rail | ||||
| Minimum glue amount | 0.01ml | ||||
| Control panel | Teaching pendant with display screen | ||||
| Work environment | Temperature: 5-40ºC Humidity: 20-90% | ||||
| Weight | 60kg | 100kg | To order | ||
| External Machine Size(L*W*H) | 700*630*700mm | 820*730*700mm | To order | ||
