CE Auto Mold Heater Water Type Mould Temperature Controller

TTW series water type mold temperature controllers havestandard type, high temperature type, dual temperature type, mainly control the mold temperature to be kept in a constant temperature state. It useswater as heating media to realize heat exchange by direct& indirect cooling. The standard type adopts direct cooling for the mold return water through cooler, then pump pressure via heater and then sent to the mold, to achieve the requirements of heating and constant temperature. Water type has its superiorities with high efficient heat transmission, less pollution, water resource easy to be attained with low cost.

1.To adopt microcomputer dual P.I.D. automatic calculation controller, can be two-way control (heating and cooling),rapid heating and cooling speed lead temperature to be kept precisely and stably with accuracy up to+0.1ºC.
2.Weekly timing automatic switch on and off, can save electricity and effective arrangement of work to improve efficiency. In addition, it also can support Chinese/English switch.
3.Unique heating designissuitable to different temperature control application with excellent & distinct power saving.
4.Electric control box and machine body are isolated to acquire good effects on heat insulation, can extend the service life of electric component.
5.Safety protection and fault indication system includes: main power non-fuse braker; pump reversal and overload protection, protection against water shortage and overheating protection, easy operation and maintenance.
6.Imported hi-class parts with long service life to save maintenance cost.
7.304 stainless steel integrated pipelines with less pipe resistance and even heating for long service life.
8.Equipped with low liquid level & water inlet low pressure protection, system high pressure protection, automatic water refilling and air exhausting function.
9.High efficiency high temperature pump to realize high efficiency heat exchange.
10.Forced cooling can quickly change mold to save time.
11.Fast heating and cooling time, stable temperature.
12.It useswater as heating media, standard type can heat up to120^oC; high temperature type can heat up to 160^oC.
13.Standard equipped with RS485 communication interface that can realize automatic centralized monitoring.

Mainly used in mold heating and constant temperature. In addition, it can also be applied to other fields of heating and constant temperature, such as die casting (high temperature type) & printing industry (big power of mold temperature controller) etc.

Tongyi originated from Taiwan, in order to meet the needs of mainland customers, in April 1999, the company set up an assembly plant in Dongguan of the Pearl River Delta, and began to sell some of its products to the Pearl River Delta market. Adhering to the purpose of "excellence, quality first", the company is committed to the research and development of intelligent automation equipment innovation, intelligent manufacturing and the whole plant planning, to provide intelligent factory overall solutions, is a professional engaged in intelligent automation equipment, design, research and development, production, sales and service in one of the intelligent manufacturing high-tech enterprises.

In order to meet the needs of customers in the YangtzeRiver Delta, in August 2011, we established an assembly plant in Suzhou of Yangtze River Delta. With abundant manufacturing experience and high-quality service, we provide customers with intelligent manufacturing automation equipment for the whole plant. With the rising costs in mainland China and the relocation of some manufacturing plants, adhering to the concept of always serving customers, we established a company in Hanoi, Vietnam, Southeast Asia, in May 2017, to provide overseas customers with the whole plant planning, technical support, talent training and plant construction and production needs.

Tongyi has always been customer-centric, with talent and technical advantages to assist customers from stand-alone automation system, system automation to intelligent automation production development needs. In addition, it has 6 production bases at domestic and abroad, including 2 in South China, 1 in Central China, 2 in East China, and overseas Vietnam, and has set up a number of holding companies in the country, many service bases to provide customers at domestic and abroad with better and more immediate service, fast processing to meet customer needs, and create value for customers.


Q: Are you a manufacturer?
A: Yes, we have seventeen years experience in equipment manufacturing.

Q: Do you support OEM?
A: Yes, we have our own brand, and also support ODM, OEM.

Q: How about your warranty?
A: All of our products for one years warranty.

Q: How about your average lead time?
A: Peak Season Lead Time: within 15 workdays. Off Season Lead Time: within 15 workdays.

Q: What's your payment term?
A: The payment term is 70% prepayment, 30% balance before delivery.
