CNC Lathe Ck6130
UNIT
Negotiable
Product information
High-quality CNC Lathe Ck6130 supplied by Shanghai Shenji International Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Processing Precision:
0.01~0.02(mm)
Production Capacity:
50 Units / Month
HS Code:
8459409000
Certification:
CE, ISO 9001
Model NO.:
CK6130
Numerical Control:
CNC/MNC
Origin:
China
Performance Classification:
Economical CNC Machine Tools
Specifications
Processing Precision:
0.01~0.02(mm)
Production Capacity:
50 Units / Month
HS Code:
8459409000
Certification:
CE, ISO 9001
Model NO.:
CK6130
Numerical Control:
CNC/MNC
Origin:
China
Performance Classification:
Economical CNC Machine Tools
Trade Term:
FOB, CFR, CIF
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Movement Method:
Linear Control
Process Usage:
Metal-Cutting CNC Machine Tools
Condition:
New
Trademark:
SJMC
Control Method:
Semi-Closed Loop Control
Transport Package:
Wooden Case
Port Of Loading:
shanghai
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-11-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, CFR, CIF
Port Of Loading:
shanghai
Certificates:
BV120 BV90 BV60 BV60S CE, CE BM200, VG100 VG100A CE
Product descriptions from the supplier
heavy duty lower cost cnc lathe machine Main feature:
1. The machine can process precisely internal or external diameter, face, taper, arc and threading with high efficiency
2. Standard toolpost is 4 stations
3. Spindle speed changed by frequency
4. Induction harden bed way, bed saddle with plastic sticker can improve the accuracy and service life of the machine
5. The spindle is supported by imported precision bearing.
6. Normally machine is provide with 3 jaw chuck. According to customer's optional selection, hydraulic chuck or pneumatic chuck also can be supplied
| Model | CK6125 | CK6130 | CK6136 | CK6136B | ||
| Capacity | Мах. swing over bed | Ф250mm | Ф250mm | Ф360mm | Ф360mm | |
| Мах. swing over toolpost | Ф90mm | Ф110mm | Ф150mm | Ф180mm | ||
| Distance between centers | 500/750/1000mm | 765mm | ||||
| Мах. machining length | 280mm | 400mm | 500/750/1000mm | 650mm | ||
| Spindle and | Chuck size | Ф60mm | Ф60mm | Ф160mm | Ф200mm | |
| Chuck | Spindle nose and taper style | Inner taper/A2-5 | Inner taper/A2-5 | A2-5 | D-6 | |
| Spindle speed range | 60-3000r.p.m | 60-3000r.p.m | 60-2500r.p.m | 60-2600r.p.m | ||
| Spindle bore dia. | Ф48mm | Ф48mm | Ф51mm | Ф57mm | ||
| Spindle power | 3.0kw | 3.0kw | 3.0kw | 5.5Kw | ||
| Max. bar feeding dia. | Ф38mm | Ф38mm | Ф45mm | Ф46mm | ||
| Feed | Rapid traverse speed (X/Z) | 4/6m/min | 4/6m/min | 6/8m/min | 6/8m/min | |
| Turret | Stations № | 4 | 4 | 4 or 6 | 4 or 6 | |
| Accuracy | XiZ Accuracy of positioning repeatability | 0.01/0.012mm | 0.01/0.012mm | 0.01/0.012mm | 0.01/0.012mm | |
| Tailstock | Quill diameter | Ф50mm | Ф60mm | |||
| Quill travel | 120mm | 120mm | ||||
| Taper of quil | M.T.4 | M.T.4 | ||||
| Others | Guideway wiclth | 230mm | 300mm | 206mm | 320mm | |
| Overall size and Weight | Overall size (L*W*H)mm | 1600x1400x1500mm | 1900x1600x1700mm | 500 | 1850x1100x1650mm | 2100x1500x1600mm |
| 750 | 1900x1100x1650mm | |||||
| 1000 | 2300x1100x1650mm | |||||
| Net weight | 1200mm | 1600mm | 500 | 1450 | 1700mm | |
| 750 | 1500 | |||||
| 1000 | 1600 | |||||
