China Xe35u Mini Excavator 3 5 Ton Crawler Excavator for Sale
1-4 Piece
$18,0005 Piece
$16,000Product information
High-quality China Xe35u Mini Excavator 3 5 Ton Crawler Excavator for Sale supplied by Komatco Industrial Equipment (Zhengzhou) Co., Ltd.. Bulk wholesale pricing ranges from $16,000 to $18,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Bucket Capacity:
0.1~0.5m³
Power:
21.4/2400 Kw/Rpm
Bucket Digging Force:
27.6kN
Rated Speed:
3.6/2.2km/H
Width Of Bucket:
300mm
Specification:
4.96*1.74*2.55m
Machine Weight:
4200 Kg
Package Gross Weight:
4200.000kg
Specifications
Bucket Capacity:
0.1~0.5m³
Power:
21.4/2400 Kw/Rpm
Bucket Digging Force:
27.6kN
Rated Speed:
3.6/2.2km/H
Width Of Bucket:
300mm
Specification:
4.96*1.74*2.55m
Machine Weight:
4200 Kg
Package Gross Weight:
4200.000kg
Package Size:
9999.00cm * 9999.00cm * 9999.00cm
Certification:
CE, ISO9001: 2000
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Type:
Crawler Excavator
Drive Type:
Electric Drive
Trade Term:
FOB, CIF, CFR, EXW
Bucket:
Grab Shovel
Transmission:
Hydraulic Transmission
Payment Term:
LC, T/T, D/P
Condition:
New
Transport Package:
Nude
Port Of Loading:
Shanghai Port
Size:
Small-Scale
Usage:
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Payment Methods:
Support payments in USD
Trademark:
Top Brand
Model NO.:
XE35U
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
2022-12-22
Annual Revenue Amount:
Not specified
Numbers Of Employees:
19
Preferred Payment Term:
LC, T/T, D/P
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE Certificate, China Compulsory Certification (CCC) Certificate, Electromagnetic Compatibility Certificate, ISO9001 Certificate, TUV Certificate
Product descriptions from the supplier
Company Profile
Product Description
New XE35U Excavator 4Ton Hydraulic Mini Crawel Excavator with YAN MAR Engine!
The XE35U hydraulic excavator integrates various versatile attachments to perform operations including digging, hauling, grading, digging trenches, breaking, drilling, gripping, and lifting. It is extensively applied in hydropower development, transportation infrastructure, urban projects, landscaping, agricultural land redevelopment, and oil pipeline construction, among other fields.
Advantageand highlights:
Advantageand highlights:
* More energy-conservation and environmental protection
Yanmar engines complying with China's Stage III emission norms feature a mechanically driven fuel pump offering durable operation. Its compact design simplifies servicing. Sufficient low-end torque capability delivers robust performance. Enhanced dependability directly lowers long-term upkeep expenses.
* More efficient return
The rear swing arc features a tailless structure, preventing the rear end from hitting obstacles in tight spaces. The adjustable attachment can swing left and right by 75° and 50° respectively, enabling coordinated movement with the main frame. By synchronizing the swinging motion with the upper structure, precise digging along wall surfaces becomes possible, allowing efficient adaptation to diverse operational environments.
* More reliable and durable
Reinforce key components subjected to high load in the boom and arm, and modify the frame design to spread out the pressure, thereby extending overall durability. Using the newly designed standard bucket, the bucket's depth is shortened, allowing for quicker and smoother material discharge.
Yanmar engines complying with China's Stage III emission norms feature a mechanically driven fuel pump offering durable operation. Its compact design simplifies servicing. Sufficient low-end torque capability delivers robust performance. Enhanced dependability directly lowers long-term upkeep expenses.
* More efficient return
The rear swing arc features a tailless structure, preventing the rear end from hitting obstacles in tight spaces. The adjustable attachment can swing left and right by 75° and 50° respectively, enabling coordinated movement with the main frame. By synchronizing the swinging motion with the upper structure, precise digging along wall surfaces becomes possible, allowing efficient adaptation to diverse operational environments.
* More reliable and durable
Reinforce key components subjected to high load in the boom and arm, and modify the frame design to spread out the pressure, thereby extending overall durability. Using the newly designed standard bucket, the bucket's depth is shortened, allowing for quicker and smoother material discharge.
Specification
Model | Metric unit | XE35U | ||
Operating weight | kg | 4200 | ||
Bucket capacity | m3 | 0.12 | ||
Engine | Model | 3TNV88F | ||
Displacement Standard | Tier IIIA | |||
Style | Direct injection | --- | √ | |
Four strokes | --- | √ | ||
Water cooling | --- | √ | ||
No. of cylinders | --- | 3 | ||
Output power | kW/ r/min | 30.7/2200 | ||
torque/speed | N.m | 85.3-94.2/1320 | ||
Displacement | L | 1.642 | ||
Main performance | Travel speed(H/L) | km/h | 3.6/2.2 | |
Gradeability | % | 58 | ||
Rotating speed | r/min | 8.5 | ||
Ground pressure | kPa | 36.6 | ||
Bucket digging force | kN | 28.6 | ||
Arm crowd force | kN | 20.3 | ||
Appearance size | A | Overall length | mm | 4960 |
B | Overall width | mm | 1740 | |
C | Overall height | mm | 2535 | |
D | Width of platform | mm | 1585 | |
E | Length of crawler | mm | 2220 | |
F | Overall width of chassis | mm | 1740 | |
G | Width of crawler | mm | 300 | |
H | Track length on ground | mm | 1440 | |
I | Crawler gauge | mm | 1721 | |
J | Clearance under counterweight | mm | 587 | |
K | Min. ground clearance | mm | 297 | |
L | Min. tail swing radius | mm | 870 | |
Working scope | A | Max. digging height | mm | 5215 |
B | Max. dumping height | mm | 3760 | |
C | Max. digging depth | mm | 3060 | |
D | Max. vertical wall digging depth | mm | 2260 | |
E | Max. digging reach | mm | 5415 | |
F | Min. swing radius | mm | 2170 | |
