Class T Sm Sh Fs Sucker Rod Coupling
1 Piece
$500Product information
High-quality Class T Sm Sh Fs Sucker Rod Coupling supplied by Dongying Zhaoxin Industry and Trade Co, Ltd.. Bulk wholesale pricing is $500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Size:
3/4" 7/8" 1"
Model NO.:
3/4\" 7/8\" 1\"
Specification:
5/8", 3/4", 7/8", 1", 1-1/8"
Material:
Alloy
Manufacturing Process:
CNC Milling
Origin:
China
Trade Term:
FOB, CIF, CFR
Surface Treatment:
Galvanized
Specifications
Size:
3/4" 7/8" 1"
Model NO.:
3/4\" 7/8\" 1\"
Specification:
5/8", 3/4", 7/8", 1", 1-1/8"
Material:
Alloy
Manufacturing Process:
CNC Milling
Origin:
China
Trade Term:
FOB, CIF, CFR
Surface Treatment:
Galvanized
Payment Term:
LC, T/T
Port Of Loading:
Qingdao Port
Product Name:
Sucker Rod Coupling
Transport Package:
Wooden Case
Trademark:
ZX
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2001-04-16
Annual Revenue Amount:
Not specified
Numbers Of Employees:
61
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Qingdao Port
Certificates:
Others
Product descriptions from the supplier
Class T and Class SM coupling for sucker rods are manufactured as per Specification 11B. For the thread cutting, we are using cold form rolled by displacing rather than by removing of material for making the coupling thread. The thread rolling cutting results in a compressive stress at the root of the thread, giving maximum strength to the traditional weak point of cut-thread couplings.
Class T coupling is using AISI 5140 to manufacture.The coupling is coated using phosphate chemical treatment or black oxide on customer's request.For Class SM coupling, the spray metal is a specification hardening process and is applied on the base metal.
The couplings are available in full size, slim hole and over size.Also, combination couplings are available for different diameters (sub-coupling) for both Class T and Class SM couplings.
| Size(in) | Coupling O.D W(mm) (+0.13,-0.25) |
Length L(mm) (+1.57,-0.00) |
Thread D.(in) | Length of Wrench Square (mm) |
Hardness(HRA) |
| 5/8" | 38.10 | 101.6 | 15/16" | 31.8 | 56-62 |
| 3/4" | 41.28 | 1-1/16" | |||
| 7/8" | 46.00 | 1-3/16" | |||
| 1" | 55.60 | 1-3/8" | 38.1 | ||
| 1-1/8" | 60.33 | 114.3 | 1-9/16" |
| Size(in) | Coupling O.D W(mm) (+0.13,-0.25) |
Length L(mm) (+1.57,-0.00) |
Thread D.(in) | Length of Wrench Square (mm) |
Hardness(HRA) |
| 5/8" | 31.75 | 15/16" | 31.8 | 56-62 |
|
| 3/4" | 38.10 | 1-1/16" | |||
| 7/8" | 41.30 | 101.6 | 1-3/16" | ||
| 1" | 50.80 | 1-3/8" | |||
| 15/16" | 38.1 |
|
Chemical Properties, %: Class T Coupling |
|
|
Steel |
AISI 5140 |
|
C |
0.37~0.44 |
|
Si |
0.17~0.37 |
|
Mn |
0.50~0.80 |
|
P |
≤0.040 |
|
S |
≤0.040 |
|
Spray Metal Coating Chemical Properties, %: Class SM Coupling |
|
|
Carbon |
0.50~1.00 |
|
Silicon |
3.50~5.50 |
|
Phosphorus |
0.00~0.02 |
|
Sulfur |
0.00~0.02 |
|
Chromium |
12.00~18.00 |
|
Boron |
2.50~4.50 |
|
Iron |
3.00~5.50 |
|
Cobalt |
0.00~0.10 |
|
Titanium |
0.00~0.05 |
|
Aluminum |
0.00~0.05 |
|
Zirconium |
0.00~0.05 |
|
Nickel |
Balance |
* Other sizes and connections available on request
