Computerized Flat Wire Diving, Cutting & Stripping Machine Trademark BOZWANG HS Code 8479899090 Warranty 12 Months Demoulding
1 SET
$300,0001 SET
$700Product information
High-quality Computerized Flat Wire Diving, Cutting & Stripping Machine Trademark BOZWANG HS Code 8479899090 Warranty 12 Months Demoulding supplied by Jiangsu Bozhiwang Automation Equipment Co., Ltd.. Bulk wholesale pricing ranges from $700 to $300,000 per SET with a minimum order of 1 SET. Inquiry for latest prices.
Warranty:
12 Months
Terminal Crimping Productivity:
2500-8000 PCS/H
Dimension Of Terminal Crimping Machine:
420 X 297 X 345mm
Production Capacity:
500 Sets /Year
HS Code:
8479899090
Mould Life:
>1,000,000 Shots
Function:
Abrasion Resistance
Specification:
According to customer's requirements
Specifications
Warranty:
12 Months
Terminal Crimping Productivity:
2500-8000 PCS/H
Dimension Of Terminal Crimping Machine:
420 X 297 X 345mm
Production Capacity:
500 Sets /Year
HS Code:
8479899090
Mould Life:
>1,000,000 Shots
Function:
Abrasion Resistance
Specification:
According to customer's requirements
Demoulding:
Automatic
Automatic Grade:
Automatic
Trademark:
BOZWANG
Model NO.:
BZW-882D+F
Origin:
Changzhou, China
Customized:
Customized
Heating System:
Electric
Trade Term:
FOB, CIF, CFR, EXW
Precision:
High Precision
Certification:
ISO, CE
Payment Term:
LC, T/T
Port Of Loading:
Shanghai Port
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-10-15
Annual Revenue Amount:
Not specified
Numbers Of Employees:
351
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE, ISO14001, ISO45001:2018
Product descriptions from the supplier
|
TECHNICAL PARAMETER
| Wire range | within 20pin, AWG28#:1-20pin; AWG26#:1-15pin; AWG24#:1-12pin |
| Cutting length | 30-99999mm |
| Dividing length | 1-200mm |
| Cutting precision | ±(0.2%*L+1)mm |
| Stripping length | wire head 0.1-30mm , wire end 0.1-30mm |
| Capacity | 1000-3000 pcs/h |
| Tool materials | Imported tungsten steel and high speed steel |
| Drive | 4 wheels driven |
| Feeding speed | 0.7m/s |
| Power | 220V 50HZ |
| Motor | 0.3KW |
| Air supply | 0.3Mpa-0.5Mpa |
| Air supply | 0.3Mpa-0.5Mpa |
| Weight | 31kg |
| Dimension | 460×297×345m |
Jiangsu Bozhiwang Automation Equipment Co., Ltd. is a large-scale intelligent wire processing equipment manufacturer in China,located in the center of the beautiful and rich Yangtze River Delta---China's famous industrial equipment manufacturing base Changzhou City, Jiangsu Province.
The company covers an area of 40,000 square meters and a building area of 45,000 square meters with more than 400 employees,including more than 300 outstanding technicians. The company has successively passed ISO9001, QS-9000, CE certification, TUV certification, and developed a number of products with independent intellectual property rights, and obtained more than 60 invention patents, more than 100 utility model patents and 100 new appearance patents, the technology and comprehensive strength of product research and development ranks the top among the nationwide.
In the production process, the company strictly follows the ISO:9001 quality standard for daily production and management. It mainly focuses on the automotive, photovoltaic and new energy industries and has developed and produced a series of automatic processing equipment with
high quality, stable performance and high efficiency.
Mainly include automotive wiring harness/HSD/FAKRA radio frequency wire harness/new energy wiring harness and other related semi-automatic and fully automatic intelligent production lines, automatic double ends terminal machine with seal inserting, automatic ribbon cable terminal machine, automatic single-double-end terminal crimping machine, automatic wire stripping machine,JB box automation equipment, new energy automation equipment, and a complete set of equipment series for various semi-automatic wire harness processing. With the increasing annual output of the company, it has reached an annual output of more than 20,000 sets of intelligent assembly lines and various wire harness processing equipment, and the production equipment has the characteristics of high precision, high degree of automation, and strong supporting performance of the whole machine.
The company covers an area of 40,000 square meters and a building area of 45,000 square meters with more than 400 employees,including more than 300 outstanding technicians. The company has successively passed ISO9001, QS-9000, CE certification, TUV certification, and developed a number of products with independent intellectual property rights, and obtained more than 60 invention patents, more than 100 utility model patents and 100 new appearance patents, the technology and comprehensive strength of product research and development ranks the top among the nationwide.
In the production process, the company strictly follows the ISO:9001 quality standard for daily production and management. It mainly focuses on the automotive, photovoltaic and new energy industries and has developed and produced a series of automatic processing equipment with
high quality, stable performance and high efficiency.
Mainly include automotive wiring harness/HSD/FAKRA radio frequency wire harness/new energy wiring harness and other related semi-automatic and fully automatic intelligent production lines, automatic double ends terminal machine with seal inserting, automatic ribbon cable terminal machine, automatic single-double-end terminal crimping machine, automatic wire stripping machine,JB box automation equipment, new energy automation equipment, and a complete set of equipment series for various semi-automatic wire harness processing. With the increasing annual output of the company, it has reached an annual output of more than 20,000 sets of intelligent assembly lines and various wire harness processing equipment, and the production equipment has the characteristics of high precision, high degree of automation, and strong supporting performance of the whole machine.
