Continously Soft Ice Cream Machine
Piece
Negotiable
Product information
High-quality Continously Soft Ice Cream Machine supplied by Wuxi Danxiao Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
100 Units/Year
HS Code:
8418699020
Model NO.:
BNJ-1200B
Certification:
CE, ISO
Specification:
CE, SGS
Trade Term:
FOB
Origin:
Jiangsu
Payment Term:
LC, T/T
Specifications
Production Capacity:
100 Units/Year
HS Code:
8418699020
Model NO.:
BNJ-1200B
Certification:
CE, ISO
Specification:
CE, SGS
Trade Term:
FOB
Origin:
Jiangsu
Payment Term:
LC, T/T
Application:
Machine Parts
Surface Treatment:
No
Refrigerant:
R404A
Trademark:
Runyu
Port Of Loading:
Shanghai
Material:
Steel
Transport Package:
Wooden Cases
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2001-02-15
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB
Port Of Loading:
Shanghai
Certificates:
CE, CE Certificate, ISO9001, ISO9001:2008
Product descriptions from the supplier
Application
BNJ series Ice-cream freezing machines are the ideal equipments for large-scale and continuous soft ice-cream production.Mixing and froze the material and air to make ice-creams, it can produce high quality ice-creams continuously and automatically, which will help reduce the cost in processing.
System
BNJ-1200 Ice-cream Freezing Machine is continuous ice-cream freezer with external cold source. And is equipped with simple bulking control system, durable self-cleaning slurry transfer pump, stable and dependable refrigeration system (all refrigeration control valves are international advanced brands). Star-moon pump and related parts are made of high quality materials. Compressed air is sent into the freezing drum by supplying forced air, qualified expansion rate can be acquired by adjusting the quantity of air supply, thereby to guarantee the quality and efficiency of ice-creams. The machine is easy for operation, and it can be conveniently assembled and unassembled for cleaning.
Operational principle
Ice-cream material and proper air enter the freezing drum through the gearing pump, and Freon compressor will start refrigerating. Scraper inside freezing drum begin to mix the material and air, and stainless steel blade will scrape the frozen ice-cream on the internal wall, then ice-cream will be out through the discharge pump.
|
|
Model |
|
|
|
BNJ-1200 ICE CREAM FREEZER (include 34HP Copland compressor R404A) |
1200L /HOUR |
|
|
|
|
|
1 |
Feeding double piston pump |
China Hoyer manufacture |
|
2 |
Heat exchanger |
|
|
3 |
Refrigerant system |
Valves: Dan Foss of Denmark |
|
4 |
Pneumatic component |
FESTO of Germany |
|
5 |
Electrical parts |
Schneider of Germany (Transducer: Panasonic) |
|
6 |
Freezing tube material copper |
China Hoyer manufacture |
|
7 |
Solenoid valve |
Festo |
|
8 |
Compressed Air inlet |
Compressor air dry and filtered |
|
9 |
CIP cleaning |
|
NO. |
Parameters |
Unit |
Value |
|
|
1 |
Maximum capacity(overrun 100%) |
L/h |
1200 |
|
|
|
Conditions: Feed temperature |
ºC |
+2-+4 |
|
|
Discharge temperature |
ºC |
≤-4 |
||
|
Evaporating temperature |
ºC |
-30 |
||
|
Air-return temperature |
ºC |
-34 |
||
|
Oil content |
ppm |
<30 |
||
|
2 |
Refrigerant |
|
R717 |
|
|
3 |
Cooling Capacity |
Kcal/KW |
27000/31 |
|
|
4 |
Compressed Air |
Pressure |
MPa |
≥0.6 |
|
Consumption |
m3/min |
2 |
||
|
Tube |
mm |
6 |
||
|
5 |
Piping system (External dimensions) |
Feeding pipe |
mm |
25 |
|
Discharge pipe |
mm |
38 |
||
|
Air-return conduit |
mm |
48 |
||
|
Liquid inlet pipe |
mm |
18 |
||
|
Hot ammonia pipe |
mm |
18 |
||
|
Emptying pipe |
mm |
18 |
||
|
Safety pipeline |
mm |
18 |
||
|
6 |
Power |
Stirrer motor |
Kw |
15 |
|
Feed pump motor |
Kw |
0.75 |
||
|
Power standard |
phase/V/Hz |
3/ 400/ 50 |
||
|
7 |
Dimensions(L×W×H) |
m |
1.82×0.83×2.16 |
|
|
8 |
Net Weight |
Ton |
1.3 |
|
Wuxi Danxiao Machinery Co., Ltd. was established in 2000 and is located in Wuxi, the core city of the Yangtze River Delta Economic Circle. It is an enterprise integrating development, design, research, production, and sales of various ice cream production lines. The company has a full range of ice cream processing equipment. Includingice cream mixing plant ,freezer,extrusion line, fillingmachine,stick ice cream machine, sandwichepacking machine, etc
After more than 20 years of development, Danxiao has the technology and manufacturing experience in line with international standards. Its business covers nearly 50 countries and regions in Europe, America, Oceania,the Middle Eastetc. The machine is recognized and praised by Unilever, LADY M, Baxi, Mengniu and other brands. It has successively obtained high-tech enterprises, ISO9001 quality management system certification, CE certification, famous enterprises in Jiangsu Province, and a number of patents.
We always adhere to the corporate spirit of honesty and pragmatism, rigorous focus, pioneering and innovative, and the pursuit of excellence, and are committed to providing customers with more efficient and energy-saving complete ice cream equipment solutions!
