Coriolis Flow Sensor Air Mass Flowmeter Coriolis Mass Flow Meters
1-49 Piece
$1,56750 Piece
$1,500Product information
High-quality Coriolis Flow Sensor Air Mass Flowmeter Coriolis Mass Flow Meters supplied by Hebei Xukang Meter Manufacturing Co., Ltd.. Bulk wholesale pricing ranges from $1,500 to $1,567 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Accuracy Grade:
0.2g
Package Gross Weight:
25.000kg
Output Signal:
4-20mA, Pulse, RS485, Hart
Package Size:
50.00cm * 50.00cm * 50.00cm
Production Capacity:
6000 PCS/Month
HS Code:
90261000
Apprications:
All Industrial
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Accuracy Grade:
0.2g
Package Gross Weight:
25.000kg
Output Signal:
4-20mA, Pulse, RS485, Hart
Package Size:
50.00cm * 50.00cm * 50.00cm
Production Capacity:
6000 PCS/Month
HS Code:
90261000
Apprications:
All Industrial
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Measurement Object:
Closed Pipeline
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Type:
Coriolis Mass Flow Meter
Size:
DN1.5~DN200
Output Signal Type:
Digital Type
Trade Term:
FOB, CIF, CFR
Modulation Formats:
Frequency State Modulation
Functional Type:
Functional
IP Rating:
IP65
Application:
Industrial Production
Production Process:
Integration
Certification:
JIS, DIN, ANS, GB, CE, ISO
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Measuring Media:
Liquid and Gas
Flow Fluid Measured:
Liquid, Air, Solid Flow
Measuring Principle:
Physical Properties Fiber Optic Sensor
Payment Methods:
Support payments in USD
Port Of Loading:
Tianjin Port
Origin:
Tianjin, China
Indicate:
Transient Flow+Accumulated Flow + Density + Temper
Sensor:
Tube/Flange
Fluid Types:
Two-Phase Flow, Three-Phase Flow
Trademark:
U-ideal
Model NO.:
UIB-CMF
Main Application:
Water, Wastewater, Diesel Fuel, Fuel Oil, Nature Gas, Corrosive Liquid/Gas
Transport Package:
Wooden Case or Carton
Specification:
sgs, iso
Accuracy:
±0.2%~±0.15%, ±0.2-0.5%
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-03-17
Annual Revenue Amount:
Not specified
Numbers Of Employees:
42
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Tianjin Port
Certificates:
certificate, company certificate, export certificate
Product descriptions from the supplier
Introduction
DMF-1-Series Coriolis Mass Flow Meters' measuring principleisbased on the controlled generation of Coriolis forces. The measurementwouldnotbeaffected by thepressure, temperature, viscosity, density,etc.Andthe compensation calculationisnot required. The structure contains two parts: Sensor & Transmitter. The Coriolis Mass Flow Meters are designed and manufactured based on the national standard of safe explosion proof. The Explosion- proof standardisEX dibII C T5 Gb.
Specification |
DN (mm) | Flow range(kg/h) | Zero Stability, kg/h | Rated Pressure (MPa) |
NW (kg) |
GW (kg) |
||
| 0.2% | 0.15% | 0.1% | ||||||
| UICMF-003 | 3 | 0~96 | 0.018 | 0.012 | 0.012 | 40 | 8 | 19 |
| UICMF-006 | 6 | 0~540 | 0.099 | 0.066 | 0.066 | 20 | 12 | 22 |
| UICMF-008 | 8 | 0~960 | 0.18 | 0.12 | 0.12 | 20 | 12 | 23 |
| UICMF-010 | 10 | 0~ 1500 | 0.27 | 0.18 | 0.18 | 20 | 11 | 24 |
| UICMF-015 | 15 | 0~3000 | 0.63 | 0.42 | 0.42 | 20 | 12 | 25 |
| UICMF-020 | 20 | 0~6000 | 1.17 | 0.78 | 0.78 | 16 | 20 | 34 |
| UICMF-025 | 25 | 0~9600 | 2.025 | 1.35 | 1.35 | 16 | 21 | 35 |
| UICMF-032 | 32 | 0~ 18 000 | 3.6 | 2.4 | 2.4 | 16 | 27 | 45 |
| UICMF-040 | 40 | 0~30 000 | 5.4 | 3.6 | 3.6 | 12 | 35 | 55 |
| UICMF-050 | 50 | 0~48 000 | 9 | 6 | 6 | 12 | 40 | 60 |
| UICMF-080 | 80 | 0~ 120 000 | 24 | 16 | 16 | 8 | 90 | 150 |
| UICMF-100 | 100 | 0~ 192 000 | 40.5 | 27 | 27 | 8 | 170 | 245 |
| UICMF-150 | 150 | 0~360 000 | 90 | 60 | 60 | 6 | 255 | 350 |
Accuracy(Liquid) :( With FT-522 Transmitter):
Measurement accuracy: ±0.1% ±(zero stability/measurement value)%
Measurement accuracy: ±0.15% ±(zero stability/measurement value)%
Measurement accuracy: ±0.2% ±(zero stability/measurement value)%
Repeatability: 1/2 measurement accuracy %
Density(Liquid) measuring range and accuracy (With FT-522 series transmitter)Range: 0.3~3.000g/cm3Accuracy: ±0.002g/cm3
Temperature measuring range and accuracy (With FT-522 transmitter):Temperature measuring range: -200~350ºCAccuracy: ±1ºCAmbient temperature: -20ºC~60ºC
Material : The measuring tube SS316L Housing: SS304
Working pressure: 0~4.0MPa
Explosion-proof level : Exd (ia)C T6Gb
Measurement accuracy: ±0.1% ±(zero stability/measurement value)%
Measurement accuracy: ±0.15% ±(zero stability/measurement value)%
Measurement accuracy: ±0.2% ±(zero stability/measurement value)%
Repeatability: 1/2 measurement accuracy %
Density(Liquid) measuring range and accuracy (With FT-522 series transmitter)Range: 0.3~3.000g/cm3Accuracy: ±0.002g/cm3
Temperature measuring range and accuracy (With FT-522 transmitter):Temperature measuring range: -200~350ºCAccuracy: ±1ºCAmbient temperature: -20ºC~60ºC
Material : The measuring tube SS316L Housing: SS304
Working pressure: 0~4.0MPa
Explosion-proof level : Exd (ia)C T6Gb
| Size | A | B | C | D | E | NW(only sensor) |
| mm | mm | mm | mm | mm | kg | |
| 20 | 540 | 478 | 468 | 108 | 245 | 17 |
| 25 | 540 | 492 | 468 | 108 | 245 | 17.5 |
| 32 | 544 | 517 | 468 | 108 | 245 | 24 |
| 40 | 600 | 635 | 500 | 140 | 267 | 32 |
| 50 | 606 | 653 | 500 | 140 | 267 | 36 |
| 80 | 866 | 857 | 779 | 219 | 316 | 87.5 |
| 100 | 950 | 977 | 833 | 273 | 340 | 165 |
