Customizable Freezer Cold Room with 75mm Panel Thickness and Storage
Set
Negotiable
Product information
High-quality Customizable Freezer Cold Room with 75mm Panel Thickness and Storage supplied by ChangZhou Mammoth International Trading Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Model NO.:
001
Warranty:
1-2 Years
Production Capacity:
5000
Panel Thickness:
50mm, 75mm, 100mm, 120mm, 150mm, 200mm, 250mm
HS Code:
8418699090
Compressor Brand:
Bizter or Copeland
Origin:
China
Surface Material:
Colored Steel, 304 S.S Sheet.Aluminum Sheet
Specifications
Model NO.:
001
Warranty:
1-2 Years
Production Capacity:
5000
Panel Thickness:
50mm, 75mm, 100mm, 120mm, 150mm, 200mm, 250mm
HS Code:
8418699090
Compressor Brand:
Bizter or Copeland
Origin:
China
Surface Material:
Colored Steel, 304 S.S Sheet.Aluminum Sheet
Evaporator:
Customization
Transport Package:
Customization
Specification:
Customization
Trade Term:
FOB, CIF, CFR, EXW
Usage:
Food, Blood, Medicine
Installation Method:
Ground Installation
Certification:
ISO
Accessories:
Included
Payment Term:
LC, T/T, D/P, PayPal, Small-amount payment, Western Union
Condition:
New
Application:
Ranch
Port Of Loading:
Shanghai Port
Shape:
Square
Material:
Steel
Feeding Method:
Top Loading
Feature:
Ventilation
Trademark:
Yangchuan
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Small-amount payment, Western Union
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Product descriptions from the supplier
SONA2024 2.2.1
Good sound insulation. The porosity of the polyurethane material is stable and basically closed-cell structure, which not only has excellent heat preservation performance but also has resistance to freezing and thawing and sound absorption.
Strong resistance to deformation, not easy to crack, stable, and a safe finish.
Fire retardant and high-temperature resistant Polyurethane is a flame-retardant, self-extinguishing material after adding flame retardant. Its softening point can reach above 250 °C, and it will only decompose at higher temperatures.
2. Can you offer refrigeration equipment?
Yes, we can offer a panel insulation system and an equipment refrigeration system.
3. What brand of compressor can you offer?
Normally, with the original Bizter and Copeland compressors. Famous in the world.
4. How about the delivery time?
For panels, our delivery time is around 7~15 days. For equipment, our delivery time is around 25 working days.
Time will be shorter if you are in a hurry.
Product Description
Product Explanation :
Low-temperature quick-freezing is the key to long-term high-quality preservation of food. Rapid cooling can make food quickly pass through the ice crystal formation zone, prevent the formation of large ice crystals in food cells, avoid damage to the cell wall, and perfectly maintain the original quality and taste of the food. The temperature of the quick-freezer is generally -15 ° C ~ -35° C. It is mainly used for low temperature and rapid freezing of food, medicine, medicine, and other items. Cooling down quickly and the preservation effect is good.
We need to know this information!
Because the cold room is customized, we design the cold room according to the customer's remand.
So, we want to know more about your project.
1. The size of the cold room. We want to know L*W*H.
1. The size of the cold room. We want to know L*W*H.
2. The temperature you want, or share what kind of food will store in the cold room.
Mark:Meat, chicken, and fish: -18 Celsius
Fruit and vegetable: -5~+5 Celsius.
Mark:Meat, chicken, and fish: -18 Celsius
Fruit and vegetable: -5~+5 Celsius.
Blast freezer: -45~-35 Celsius
Can you share your WhatsApp so that we can discuss it easily?
3D show
3D design
We can make 3D renderings for each customer based on the detailed parameters provided by the customer, so that the customer can intuitively view the actual construction effect and avoid any errors.
Specification
1. Cold Room Panels For Cold Room
Good waterproof performance, Polyurethane cold storage board with moisture and water resistance. The rigid polyurethane has a closed-cell ratio of more than 90% and is a hydrophobic material. It does not increase the thermal conductivity due to moisture absorption, and the wall surface will also seep.
Good sound insulation. The porosity of the polyurethane material is stable and basically closed-cell structure, which not only has excellent heat preservation performance but also has resistance to freezing and thawing and sound absorption.
Strong resistance to deformation, not easy to crack, stable, and a safe finish.
Fire retardant and high-temperature resistant Polyurethane is a flame-retardant, self-extinguishing material after adding flame retardant. Its softening point can reach above 250 °C, and it will only decompose at higher temperatures.
Product Name | PU sandwich panel |
Surface Material | color steel(PPGI), stainless steel, aluminum |
Core material | Polyurethane foam |
PU density | 45±2KG/m3 |
Fire grade | B2 |
Width | standard width 1000mm, maximum 1050mm |
Length | Customized, maximum 11980mm |
Thickness | 50/75/100/150/200mm |
Panels thickness (mm) | Temperature gap between internal-external environment | Height of wall panel (max) | Roof length (max) |
mm | ºC | m | m |
50 | 30 | 3.5 | 2.4 |
75 | 40 | 4.5 | 3.8 |
100 | 50 | 5 | 4.5 |
120 | 60 | 5.5 | 6 |
150 | 70 | 6 | 6.5 |
200 | 90 | 7 | 7.6 |
If there is a pressure gap between the internal-external environment without wind load, over-length or wind-load need to set steel wall beam. | |||
Tips:the data above is figured out according to 8-10 W / heat flux. | |||
2. Condensing Unit For Cold Room
Unit Cold Room Condensing Condenser Unit Evaporator Equipment For Cold Room
Yangchuan Condensing unit is the optimized combination of efficiency, reliability, easy installation, and sound performance. It is optimized designed and manufactured to reduce installation and maintenance costs, more efficient while making your production even more efficient and less noise impact for the neighborhood.
Yangchuan Condensing unit is the optimized combination of efficiency, reliability, easy installation, and sound performance. It is optimized designed and manufactured to reduce installation and maintenance costs, more efficient while making your production even more efficient and less noise impact for the neighborhood.
3. Evaporators For Cold Room
Dimension : | Length(m)×Width(m)×Height(m) / FT | |||
Refrigeration unit/Condsenor unit : | Famous Brand etc | |||
Refrigeration type/Air cooler/Evaporator : | Air-cooled/water-cooled/evaporation cooled | |||
Refrigeration : | R22,R404A,R407C,R507a Refrigerant | |||
Defrost Type : | Electric defrosting | |||
Voltage : | 220V/50Hz,220V/60Hz,380V/50Hz,380V/60Hz,440V/60Hz optional | |||
PU Panel : | New material polyurethane insulation panel,45 kg/m³ | |||
Panel thickness : | 50mm,75mm,100mm,150mm,200mm | |||
Type of door : | Hanged door, sliding door,double swing electric sliding door,truck door | |||
Temp of room : | -60°C~+20°C optional/Customization | |||
Fittings : | All necessary fittings are included,optional | |||
Place to assemble : | Indoor/out door(concrete construction building/steel construction bullding | |||
Company Profile
FAQ
1. Can you customize the cold storage room dimensions and temperature?
Yes, we can customize the cold room dimensions and temperature according to your requirements.Any size will do.
Yes, we can customize the cold room dimensions and temperature according to your requirements.Any size will do.
If you have no idea, please tell me the total amount of your cargo, and our engineer can design it for you.
2. Can you offer refrigeration equipment?
Yes, we can offer a panel insulation system and an equipment refrigeration system.
3. What brand of compressor can you offer?
Normally, with the original Bizter and Copeland compressors. Famous in the world.
4. How about the delivery time?
For panels, our delivery time is around 7~15 days. For equipment, our delivery time is around 25 working days.
Time will be shorter if you are in a hurry.
