Cutting-Edge Immersion Cooling Systems for Mobile Data Centers
1-4 Piece
$18,0005 Piece
$17,500Product information
High-quality Cutting-Edge Immersion Cooling Systems for Mobile Data Centers supplied by Shanghai Shenglin M&E Technology Co., Ltd.. Bulk wholesale pricing ranges from $17,500 to $18,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Fan Quantity:
14PCS
Inlet Air Temperature:
20 Degree C
Inlet/Outlet Water Temperature:
25 Degree C
Production Capacity:
300 Units/Month
Total Motor Power:
38.5kw
Power Supply:
400V-3pH-50Hz
Water Flow:
60L/Sec
Cooling Capacity:
694kw
Specifications
Fan Quantity:
14PCS
Inlet Air Temperature:
20 Degree C
Inlet/Outlet Water Temperature:
25 Degree C
Production Capacity:
300 Units/Month
Total Motor Power:
38.5kw
Power Supply:
400V-3pH-50Hz
Water Flow:
60L/Sec
Cooling Capacity:
694kw
HS Code:
8415901000
Type:
Air-Cooled
Model NO.:
Customized
Inlet/Outlet Connection:
DN125
Fans Species:
Double-speed fan
Trade Term:
FOB, CFR, CIF, DDP, EXW
Product Name:
Floorstanding Compact Air Dry Refrigeration Cooler
Application Fields:
Industrial
Cooling Water:
Industrial Water
Noise Level:
Low
Condition:
New
System Type:
Open System
Certification:
RoHS, CE
Origin:
Shanghai
Port Of Loading:
Shanghai, Ningbo
Trademark:
Shenglin
Payment Term:
T/T, Western Union
Transport Package:
Wrap Film/Pallet
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2009-12-29
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
T/T, Western Union
Preferred Trade Term:
FOB, CFR, CIF, DDP, EXW
Port Of Loading:
Shanghai, Ningbo
Certificates:
CE Heat Pump-EMC, CE Heat Pump-LVD, CE Rooftop AC-EMC, CE Rooftop AC-LVD, CE-Chiller, CE-Dry Cooler, ROHS, UL-Dry Cooler
Product descriptions from the supplier
Floorstanding compact Air Dry Refrigeration Cooler
Features
Technical Data
Fluid cooler SHSL-D1 series parameter(fin space 2.1mm)
Note: Standard SHSL-D1 remote radiator is vertical air discharge, for horizontal air discharge please add "H" in nomenclature, for excmple:SHSL-D1-005H-1X350
Features
| Air discharge direction |  |
| Performance ranges | Cooling capacity: from 5 to 649 kw Air volume: from 2828 to 263503 m3/h Sound pressure level: from 31 to 69 dB A(10m) Fluid coolers:customized on demand |
| High efficiency heat exchanger | Capacity designs for maximizing the heat transfer relative to the energy consumption of the fan. Tube and tube coupling design for low pressure drop in the coil on the media sides(maximum 100KPa at water designing condition). Our thermodynamic and aerodynamic designing software is long year tested and proved in Germany |
| Fan | Only choose low specific energy consumption fans. Fan nozzle designs for maximum air flow and air throw. Our fans from the world`s leading manufacturer are practically proved to be reliable in operation and long lasting. Motor: protection class IP 54 and insulation class F. Voltage:400V/3N/50Hz Air separator for each fan. |
| Testing | Heat exchangers are supplied clean and tested at a pressure of 30 bars |
| Options | Coil design refrigerant: water, oil, glycol. Multiple circuits. Sub-cooling circuits. Stainless steel or aluminum casing. Coated aluminum or copper fins. Explosion ploof motor. Customized fin spacing. |
Technical Data
Fluid cooler SHSL-D1 series parameter(fin space 2.1mm)
| Type | SHSL-D1-005-1x350 | SHSL-D1-006-1x350 | SHSL-D1-007-1x350 | SHSL-D1-009-1x450 | SHSL-D1-011-1x450 | SHSL-D1-013-1x450 | SHSL-D1-014-1x500 | SHSL-D1-017-1x500 | SHSL-D1-020-1x500 | ||||||
| Capacity | Water | 35ºC outdoor temp. | Inlet | 45ºC, | △ | KW | 4.89 | 5.90 | 6.83 | 9.39 | 10.99 | 13.33 | 14.32 | 17.01 | 19.80 |
| outlet | 40ºC | Y | |||||||||||||
| 20% Glycol | Inlet | 45ºC | △ | 4.72 | 5.69 | 6.69 | 8.90 | 10.61 | 13.05 | 13.91 | 16.11 | 19.29 | |||
| outlet | 40ºC | Y | |||||||||||||
| Medium | Water flow | M3/h | 0.85 | 1.03 | 1.20 | 1.63 | 1.91 | 2.30 | 2.50 | 3.00 | 3.50 | ||||
| Pressure drop | kPa | 36.00 | 31.00 | 58.00 | 25.00 | 40 | 80 | 50 | 60 | 40 | |||||
| Air flow | △ | M3/h | 2828 | 2712 | 2492 | 6199 | 5827 | 5225 | 8469 | 8168 | 7601 | ||||
| Y | |||||||||||||||
| Fan motor | Phase | 1 | 1 | 1 | 3 | 3 | 3 | 3 | 3 | 3 | |||||
| △ | W | 140 | 140 | 140 | 540 | 540 | 540 | 830 | 830 | 830 | |||||
| Y | |||||||||||||||
| △ | A | 0.60 | 0.60 | 0.60 | 1.10 | 1.10 | 1.10 | 1.45 | 1.45 | 1.45 | |||||
| Y | |||||||||||||||
| Fan | No X φ | 1x1x350 | 1x1x350 | 1x1x350 | 1x1x450 | 1x1x450 | 1x1x450 | 1x1x500 | 1x1x500 | 1x1x500 | |||||
| Sound pressure level | △ | dB(A) | 31 | 31 | 31 | 43 | 43 | 43 | 49 | 49 | 49 | ||||
| Y | 10m | ||||||||||||||
| Dimension | L | mm | 870 | 870 | 870 | 1020 | 1020 | 1020 | 1220 | 1220 | 1220 | ||||
| W | mm | 525 | 525 | 525 | 625 | 625 | 625 | 825 | 825 | 825 | |||||
| H | mm | 797 | 797 | 797 | 820 | 820 | 820 | 870 | 870 | 870 | |||||
| A | mm | 690 | 690 | 690 | 840 | 840 | 840 | 1040 | 1040 | 1040 | |||||
| B | mm | -- | -- | -- | -- | -- | -- | -- | -- | -- | |||||
| C | mm | -- | -- | -- | -- | -- | -- | -- | -- | -- | |||||
| D | mm | 490 | 490 | 490 | 490 | 490 | 490 | 490 | 490 | 490 | |||||
| Inlet φ | mm | 3/4" | 3/4" | 3/4" | 1" | 1" | 1" | 1-1/4" | 1-1/4" | 1-1/4" | |||||
| Inlet φ | mm | 3/4" | 3/4" | 3/4" | 1" | 1" | 1" | 1-1/4" | 1-1/4" | 1-1/4" | |||||
| Product weight(empty) | kg | 38 | 42 | 48 | 55 | 60 | 67 | 75 | 82 | 91 | |||||
Note: Standard SHSL-D1 remote radiator is vertical air discharge, for horizontal air discharge please add "H" in nomenclature, for excmple:SHSL-D1-005H-1X350
