Darlly Replacement High Flow Filter Cartridge

Darlly Replacement High Flow Filter Cartridge - Image 1
Darlly Replacement High Flow Filter Cartridge - Image 2
Darlly Replacement High Flow Filter Cartridge - Image 3
Darlly Replacement High Flow Filter Cartridge - Image 4
Darlly Replacement High Flow Filter Cartridge - Image 5
Darlly Replacement High Flow Filter Cartridge - Image 1
Darlly Replacement High Flow Filter Cartridge - Image 2
Darlly Replacement High Flow Filter Cartridge - Image 3
Darlly Replacement High Flow Filter Cartridge - Image 4
Darlly Replacement High Flow Filter Cartridge - Image 5

500 Piece

$5.2

Product information

High-quality Darlly Replacement High Flow Filter Cartridge supplied by Hangzhou Darlly Filtration Equipment Co., Ltd.. Bulk wholesale pricing is $5.2 per Piece with a minimum order of 500 Piece. Inquiry for latest prices.

Removal Rating:

1, 4.5, 6, 10,20,40,70,100µm

Inside Diameter:

3.5 Inch(89mm)

Length:

40 Inch(1016mm)

Outside Diameter:

6 Inch(152mm)

Production Capacity:

60000PCS/Month

HS Code:

84219990

Model NO.:

DLSHF-

Trademark:

Darlly

Specifications

Removal Rating:

1, 4.5, 6, 10,20,40,70,100µm

Inside Diameter:

3.5 Inch(89mm)

Length:

40 Inch(1016mm)

Outside Diameter:

6 Inch(152mm)

Production Capacity:

60000PCS/Month

HS Code:

84219990

Model NO.:

DLSHF-

Trademark:

Darlly

Seal Material:

EPDM

Trade Term:

FOB, EXW, CIF, DDP

Filter Connector:

Flat Connector

Cert:

ISO9001

Transport Package:

Individual Poly Bag and Box

Payment Term:

LC, T/T

Port Of Loading:

Ningbo, Shanghai

Activated Carbon Filter Type:

No Carbon

Type:

PP Filter

Filtration Grade:

PRE Filter

Support/Drainage:

Polypropylene (PP)

Filter Media:

Polypropylene, Glass Fiber

Specification:

SGS

Origin:

Zhejiang, China

Business Details

Country:

China

Business Types:

Not specified

Main Markets:

Not specified

Main Products:

Year Established:

2005-01-01

Annual Revenue Amount:

Not specified

Numbers Of Employees:

Not specified

Preferred Payment Term:

LC, T/T

Preferred Trade Term:

FOB, EXW, CIF, DDP

Port Of Loading:

Ningbo, Shanghai

Certificates:

Certificate of A Level by Custom, Certificate of SGS, High And New Tech Enterprises, ISO9001, NSF Certified, Top 7 Certificate By Local Government, WQA-Membership

Product descriptions from the supplier

Darlly Replacement High Flow Filter Cartridge

DLSHF High Flow Filter Cartridge
DLSHF High Flow Filter Cartridge
Outside Diameter : 6 inch(152mm)
Inside Diameter : 3.5 inch(89mm)
Length : 40 inch(1016mm)
Filter media  : Polypropylene, Glass Fiber
Support/Drainage  : Polypropylene (PP)
End Cap Material  : Glass Fiber reinforced PP
Seal Material  : EPDM
Removal Rating : 1, 4.5, 6, 10,20,40,70,100µm
Maximum Operating Temperature : 82°C
Maximum Differential Pressure : 3.4Bar, 82°C .

SHF Series Filter Cartridge
General  Description:
SHF Series Filter Cartridge is a replacement cartridges for the depth filtration and other 2-1/2" diameter cartridges for the high flow applications. Pre-Filtration for RO system is an example. Up to 1300 LPM flow rate per cartridge reduced the number of filter cartridges and the dimension of the filter housing required. Water treatment volume per Super-High Flowment filter cartridge equals to 10x40" length, 2-1/2" diameter cartridges. Inner O-ring insures no bypass and handle design makes the installation easier.
Applications:
-Prefiltration of RO, Pretreatment of sea water desalination
-Condensed water treatment for power plant
-API, solvents, and water filtration in BioPharm market
-The filtration of bottled water, high Fructose, edible oil, soft drinks, and milk
- Automotive Paints, inks, CD/DVD, magnetic media, Petrochemical, Refineries
-Microeletronics, film, fiber and resin
Features:
--High dirt holding capacity, longer service life
--Less cartridge change out to save the labor cost
--O-ring design cause no bypass to ensure the filtration efficiency
--Easy handing result in less manpower
--Wide chemical compatability for different applications
Specifications:
Dimensions
-Outside Diameter: 6 inch(152mm)
-Inside Diameter: 3.5 inch(89mm): - Length:  40 inch(1016mm)
Material Of Constructions:
-Filter media: Polypropylene, Glass Fiber;
- Support/Drainage: Polypropylene
- End Cap Material: Glass Fiber reinforced PP  -Seal Material: EPDM
Performance:
- Removal Rating: 1, 4.5, 6, 10,20,40,70,100µm
- Maximum Operating Temperature: 82°C
- Maximum Differential Pressure: 3.4Bar, 82°C.
- Suggested Maximum flow rate: 1300 LPM
