Darlly Replacement High Flow Filter Cartridge
500 Piece
$5.2Product information
High-quality Darlly Replacement High Flow Filter Cartridge supplied by Hangzhou Darlly Filtration Equipment Co., Ltd.. Bulk wholesale pricing is $5.2 per Piece with a minimum order of 500 Piece. Inquiry for latest prices.
Removal Rating:
1, 4.5, 6, 10,20,40,70,100µm
Inside Diameter:
3.5 Inch(89mm)
Length:
40 Inch(1016mm)
Outside Diameter:
6 Inch(152mm)
Production Capacity:
60000PCS/Month
HS Code:
84219990
Model NO.:
DLSHF-
Trademark:
Darlly
Specifications
Removal Rating:
1, 4.5, 6, 10,20,40,70,100µm
Inside Diameter:
3.5 Inch(89mm)
Length:
40 Inch(1016mm)
Outside Diameter:
6 Inch(152mm)
Production Capacity:
60000PCS/Month
HS Code:
84219990
Model NO.:
DLSHF-
Trademark:
Darlly
Seal Material:
EPDM
Trade Term:
FOB, EXW, CIF, DDP
Filter Connector:
Flat Connector
Cert:
ISO9001
Transport Package:
Individual Poly Bag and Box
Payment Term:
LC, T/T
Port Of Loading:
Ningbo, Shanghai
Activated Carbon Filter Type:
No Carbon
Type:
PP Filter
Filtration Grade:
PRE Filter
Support/Drainage:
Polypropylene (PP)
Filter Media:
Polypropylene, Glass Fiber
Specification:
SGS
Origin:
Zhejiang, China
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2005-01-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, EXW, CIF, DDP
Port Of Loading:
Ningbo, Shanghai
Certificates:
Certificate of A Level by Custom, Certificate of SGS, High And New Tech Enterprises, ISO9001, NSF Certified, Top 7 Certificate By Local Government, WQA-Membership
Product descriptions from the supplier
DLSHF High Flow Filter Cartridge
| DLSHF High Flow Filter Cartridge |
| Outside Diameter : | 6 inch(152mm) |
| Inside Diameter : | 3.5 inch(89mm) |
| Length : | 40 inch(1016mm) |
| Filter media : | Polypropylene, Glass Fiber |
| Support/Drainage : | Polypropylene (PP) |
| End Cap Material : | Glass Fiber reinforced PP |
| Seal Material : | EPDM |
| Removal Rating : | 1, 4.5, 6, 10,20,40,70,100µm |
| Maximum Operating Temperature : | 82°C |
| Maximum Differential Pressure : | 3.4Bar, 82°C . |
SHF Series Filter Cartridge
General Description:
SHF Series Filter Cartridge is a replacement cartridges for the depth filtration and other 2-1/2" diameter cartridges for the high flow applications. Pre-Filtration for RO system is an example. Up to 1300 LPM flow rate per cartridge reduced the number of filter cartridges and the dimension of the filter housing required. Water treatment volume per Super-High Flowment filter cartridge equals to 10x40" length, 2-1/2" diameter cartridges. Inner O-ring insures no bypass and handle design makes the installation easier.
Applications:
-Prefiltration of RO, Pretreatment of sea water desalination
-Condensed water treatment for power plant
-API, solvents, and water filtration in BioPharm market
-The filtration of bottled water, high Fructose, edible oil, soft drinks, and milk
- Automotive Paints, inks, CD/DVD, magnetic media, Petrochemical, Refineries
-Microeletronics, film, fiber and resin
Features:
--High dirt holding capacity, longer service life
--Less cartridge change out to save the labor cost
--O-ring design cause no bypass to ensure the filtration efficiency
--Easy handing result in less manpower
--Wide chemical compatability for different applications
Specifications:
Dimensions
-Outside Diameter: 6 inch(152mm)
-Inside Diameter: 3.5 inch(89mm): - Length: 40 inch(1016mm)
Material Of Constructions:
-Filter media: Polypropylene, Glass Fiber;
- Support/Drainage: Polypropylene
- End Cap Material: Glass Fiber reinforced PP -Seal Material: EPDM
Performance:
- Removal Rating: 1, 4.5, 6, 10,20,40,70,100µm
- Maximum Operating Temperature: 82°C
- Maximum Differential Pressure: 3.4Bar, 82°C.
- Suggested Maximum flow rate: 1300 LPM
