Diesel Pump Fuel Injection Code Generation Diagnostic Common Rail Test Bench. Jz-919
Piece
Negotiable
Product information
High-quality Diesel Pump Fuel Injection Code Generation Diagnostic Common Rail Test Bench. Jz-919 supplied by Wuxi Chengshunda Automobile Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Rail Pressure:
0-2700 Bar
Net Weight:
1260 Kg
Engine Tank Volume:
20L
Specification:
2440*1350*1980mm
Power:
3-Phase 4-Wire 380V 50/60Hz
Fuel Temperature:
38-42℃
Diesel Tank Volume:
40L
Rail Pressure Precision:
5 Bar
Specifications
Rail Pressure:
0-2700 Bar
Net Weight:
1260 Kg
Engine Tank Volume:
20L
Specification:
2440*1350*1980mm
Power:
3-Phase 4-Wire 380V 50/60Hz
Fuel Temperature:
38-42℃
Diesel Tank Volume:
40L
Rail Pressure Precision:
5 Bar
Production Capacity:
50pieces/Month
HS Code:
9031200090
Filter Precision:
< 5 Um
Software:
Coding System
Trade Term:
FOB, CIF, CFR
Model NO.:
JZ-919
Trademark:
Jing Zheng Hong Ye
Payment Term:
LC, T/T
Condition:
New
Standard:
Nonstandard
Port Of Loading:
Shanghai Port
Transport Package:
Wooden High Density Board
Origin:
Wuxi City, Jiangu, China
Update Method:
by Internet
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2017-12-18
Annual Revenue Amount:
Not specified
Numbers Of Employees:
12
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
Product Introduction
JZ-919 multi-function test bench adopts full automatic control, which can conveniently repair and test Euro-3-----6 injectors andhigh-pressure pumps. It can test thousands of injectors and high-pressure pumps, including B-osch, D-elphi, D-enso, S-iemens, C-aterpillar and so on. The experimental data are complete.
It can also be equipped with unit pumps & unit injectors, medium pressure injectors testing, actuated pumps and other optional functions.
Functions Description
Standard Functions
1. Can test actuator pump
2. Can test smart injectors
3. Can test piezo injectors
4. Can test solenoid valve injector
5. Can test HEUI common rail injector
6. Can test pump nozzle and unit pump
7. Can test high-pressure common rail pump
Optional Functions
1. Can test 4-pin injector
2. Can X15, Q60 HPI
3. Test C-ummins HPI actuators
4. Can test 4-6 injectors at the same time
5. B-osch 4-plunger common rail pump
6. D-enso 4-plunger common rail pump
Hardware Configuration
1. Gear flow sensor
2. Dual DRV configuration
3. 4 Flow sensor metering units
4. Common rail pipe with filter function
5. Injection drive and system voltage monitor
6. Built-in oil actuated pump and high pressure common rail pump
Assist Functions
1. High pressure filter clogging reminder
2. Flow sensor linear calibration
3. Fuel tank oil level lower limit alarm
4. Oil nozzle opening pressure flow
5. Common rail pump plunger pressure curve
6. Pump nozzle working pressure testing
Capabilities
1. Generate B-osch 6-10 digit code
2. Generate D-enso 16, 24, 30 digit QR code
3. Generate D-elphi C2i, C3i correction code
4. Generate B-osch piezo IMA, ISA code
5. Generate S-iemens VDO-IIC code
6. Generate C-ummins correction code
Product Details
Technical Parameters
Testing Scope
Related Products
Our Company
Why Choose Us
1. Our company has our own maintenance center with an area of 1200 square meters. It has been servicing the diesel fuel engine system for 20 years. Rich maintenance experience, let our products pay more attention to solving the difficult problems in maintenance.
2. Independent design and development team,and produce experience.
3. Almost all important parts of the equipment are come from top suppliers in the industry, such as DRV, common rail tube, CP3 pump, from original of B-osch.
4. Strict QC, good pre-sale and after-sale service, Providing remote assistance services free.
5. Customized according to customer requirements, such as appearance, color, etc.
Djame| Sales
Wuxi Jia Miao Auto Technology Co., Ltd
Wuxi Chengshunda Automobile Technology Co., Ltd.
Address: No. 117 Xinzhuang Road, Zhutang Town Wuxi City, Jiangsu Province, China
Website: jm888888.en.made-in-china.com
JZ-919 multi-function test bench adopts full automatic control, which can conveniently repair and test Euro-3-----6 injectors andhigh-pressure pumps. It can test thousands of injectors and high-pressure pumps, including B-osch, D-elphi, D-enso, S-iemens, C-aterpillar and so on. The experimental data are complete.
It can also be equipped with unit pumps & unit injectors, medium pressure injectors testing, actuated pumps and other optional functions.
Functions Description
Standard Functions
1. Can test actuator pump
2. Can test smart injectors
3. Can test piezo injectors
4. Can test solenoid valve injector
5. Can test HEUI common rail injector
6. Can test pump nozzle and unit pump
7. Can test high-pressure common rail pump
Optional Functions
1. Can test 4-pin injector
2. Can X15, Q60 HPI
3. Test C-ummins HPI actuators
4. Can test 4-6 injectors at the same time
5. B-osch 4-plunger common rail pump
6. D-enso 4-plunger common rail pump
Hardware Configuration
1. Gear flow sensor
2. Dual DRV configuration
3. 4 Flow sensor metering units
4. Common rail pipe with filter function
5. Injection drive and system voltage monitor
6. Built-in oil actuated pump and high pressure common rail pump
Assist Functions
1. High pressure filter clogging reminder
2. Flow sensor linear calibration
3. Fuel tank oil level lower limit alarm
4. Oil nozzle opening pressure flow
5. Common rail pump plunger pressure curve
6. Pump nozzle working pressure testing
Capabilities
1. Generate B-osch 6-10 digit code
2. Generate D-enso 16, 24, 30 digit QR code
3. Generate D-elphi C2i, C3i correction code
4. Generate B-osch piezo IMA, ISA code
5. Generate S-iemens VDO-IIC code
6. Generate C-ummins correction code
Product Details
Technical Parameters
| Technical Parameters | |
| Output | 22KW |
| Power | 3-Phase 4-Wire 380V 50/60HZ |
| Speed | 0~4000 RPM |
| Rail Pressure | 0~2700 Bar |
| Rail Pressure Precision | ±5 Bar |
| Oil Tank Volume | Diesel: 40L Engine: 20L |
| Fuel Temperature | 40±2ºC |
| Filter Precision | < 5μm |
| Gross Weight | 1200 kg |
| Packing Size | 2440*1350*1980mm |
| Speed Control Model | Converter Control |
| Temperature Control System | Air Conditioning Heat Dissipation |
| Nozzle Sensor | Imported Original Elliptical Type Flow Sensor |
| Fuel Pump Sensor | Imported Original Vane Type Flow Sensor |
| Language | English, Spanish, Russian,etc |
| Material | Metal Plate |
| Painting | Powder Painting, Durable |
| Color | Green (can be customized) |
| Logo | Jing Zheng Hong Ye (can be customized) |
| MOQ | 1 Piece |
| Payment | 40% Deposit, the rest paid before shipment |
| Warranty Time | 12 months |
| Delivery time | 30 days after prepaid |
| Shipping Packing | Wooden Case |
Testing Scope
Related Products
Our Company
Why Choose Us
1. Our company has our own maintenance center with an area of 1200 square meters. It has been servicing the diesel fuel engine system for 20 years. Rich maintenance experience, let our products pay more attention to solving the difficult problems in maintenance.
2. Independent design and development team,and produce experience.
3. Almost all important parts of the equipment are come from top suppliers in the industry, such as DRV, common rail tube, CP3 pump, from original of B-osch.
4. Strict QC, good pre-sale and after-sale service, Providing remote assistance services free.
5. Customized according to customer requirements, such as appearance, color, etc.
Djame| Sales
Wuxi Jia Miao Auto Technology Co., Ltd
Wuxi Chengshunda Automobile Technology Co., Ltd.
Address: No. 117 Xinzhuang Road, Zhutang Town Wuxi City, Jiangsu Province, China
Website: jm888888.en.made-in-china.com
