Drilling and Milling Machine Zx5325c with 50mm Drilling Capacity
Piece
Negotiable
Product information
High-quality Drilling and Milling Machine Zx5325c with 50mm Drilling Capacity supplied by Anhui Chizhou Household Machine Tool Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Horse Power For Main Motor:
0.85/1.5kw
Face Milling Capacity:
120mm
Boring Capacity:
120mm
Vertical Milling Capacity:
30mm
Production Capacity:
5000 PCS/Year
Max.Drilling Diameter:
50mm
Controlling Mode:
Artificial
Certification:
CE, ISO 9001
Specifications
Horse Power For Main Motor:
0.85/1.5kw
Face Milling Capacity:
120mm
Boring Capacity:
120mm
Vertical Milling Capacity:
30mm
Production Capacity:
5000 PCS/Year
Max.Drilling Diameter:
50mm
Controlling Mode:
Artificial
Certification:
CE, ISO 9001
Specification:
CE, ISO9001, TUV
Origin:
China
Trade Term:
FOB, CIF
Transport Package:
Fumigation Wooden Case
Structure:
Gear Type
Precision:
High Precision
Milling Cutter Structure:
Indexable Type
Payment Term:
LC, T/T, D/P, Western Union
Condition:
New
Automatic Grade:
Semiautomatic
Port Of Loading:
Shanghai Port
Object:
Sheet
Milling Cutter Type:
Vertical Milling Cutter
Trademark:
White Eagle
Model NO.:
ZX5325C
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Year Established:
1994-06-30
Annual Revenue Amount:
Not specified
Numbers Of Employees:
122
Preferred Payment Term:
LC, T/T, D/P, Western Union
Preferred Trade Term:
FOB, CIF
Port Of Loading:
Shanghai Port
Certificates:
ISO9001:2015
Product descriptions from the supplier
ZX5325C DRILLING AND MILLING MACHINE
Drilling milling machine
Vertical milling spindle manual feed
Vertical milling head rotate 45 °for right side and
left side
working table rotate 45 °for right side and left side
Specification
Drilling milling machine
Vertical milling spindle manual feed
Vertical milling head rotate 45 °for right side and
left side
working table rotate 45 °for right side and left side
Specification
| ZX5325C | |
| Spindle taper | MT4.(ISO30.ISO40 ) |
| Drilling capacity | 50mm |
| Vertical milling capacity | 30mm |
| Face milling capacity | 120mm |
| Boring capacity | 120mm |
| Max.taping dia. | M16 |
| Spindle travel | 120mm |
| Table size | 1000X260 |
| Table travel(horizontal/cross/vertical) | 600x260x380mm |
| Head movement(left/right) | 45degrees |
| Max.swing angle of table surface | 45degrees |
| Spindle nose to worktable | 40-420mm |
| Spindle center to column | 320mm |
| Spindle speeds | (8)115-1750r/min |
| Max weight of workpiece | 200kg |
| T-slot number /width/distance | 3/14mm/60mm |
| Horse power for main motor | 0.85/1.5KW |
| Overall dimension | 1300x1200x2150mm |
| N.W./G.W. | 800/900kg |
| Item | Name | Q'TY |
| 1 | Drilling and milling machine | 1 |
| 2 | Drill chuck | 1 |
| 3 | Milling chuck | 1(8 pcs) |
| 4 | Reduction sleeve | 2 |
| 5 | Machine vise* | 1 |
| 6 | Wrench | 1 |
| 7 | Inner hexagonal spanner | 1 |
| 8 | Cam lock | 1 |
| 9 | Wedge shifter | 1 |
| 10 | Spindle arbor | 1 |
| 11 | Boring bolt | 1 |
| 12 | Operation manual | 1 |
