Product information
High-quality Efficient Milling Machine Solutions Drilling Machine Deep Hole Boring Machine Honing Machine Deep Hole Drilling Machine Scraping and Rolling Machine supplied by Dezhou Jutai Machine Tool Manufacturing Co., Ltd. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
100
Max Machining Depth/Mm:
1000-12000
Specification:
12000*1100*1400mm
Package Gross Weight:
12000.000kg
Package Size:
12000.00cm * 1200.00cm * 1500.00cm
Max Boring Diameter/Mm:
200
Drilling Diameter Range/Mm:
30-120
Spindle Center Height/Mm:
350
Specifications
Production Capacity:
100
Max Machining Depth/Mm:
1000-12000
Specification:
12000*1100*1400mm
Package Gross Weight:
12000.000kg
Package Size:
12000.00cm * 1200.00cm * 1500.00cm
Max Boring Diameter/Mm:
200
Drilling Diameter Range/Mm:
30-120
Spindle Center Height/Mm:
350
Feed Rate Range (Stepless) Mm/Min:
5-260
Workpiece Clamping Range/Mm:
60-260
Spindle Speed Range R/Min:
61-1000 (12 Speeds)
Guide Rail Width/Mm:
650
Headstock Spindle Bore/Mm:
75
HS Code:
8459210000
Spindle Nose Taper/M:
85; 1:20
Automatic Grade:
Automatic
Controlling Mode:
CNC
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Origin:
Dezhou City, Shandong Province, China
Trade Term:
FOB, CIF, CFR, EXW
Certification:
GS, CE, RoHS, ISO 9001
Precision:
High Precision
Structure:
Horizontal Boring Machine
Coordinate Boring Machine Type:
Horizontal Type
Trademark:
Jutai
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Condition:
New
Port Of Loading:
Qingdao
Payment Methods:
Support payments in USD
Model NO.:
TK2220
Transport Package:
Wooden Box
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-11-26
Annual Revenue Amount:
Not specified
Numbers Of Employees:
62
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Qingdao
Certificates:
ISO9001:2015
Product descriptions from the supplier
SONA2024 2.2.1
The leading products are: the general category - deep hole drilling and boring machine (T2116, T2120), deep hole boring machine (T2225, T2235, the T2250), deep hole honing machine (2M2125A, 2M2135A); NC class - CNC deep hole drilling and boring machine (TK2120, TK2125), CNC deep hole boring machine (TK2235, TK2250). Deep hole gun drilling (ZK2102, ZK2103).
model | TK2216 | TK2220 | TK2225 | TK2235 | TK2240 |
Maximum diameter of boring hole /mm | 160 | 200 | 250 | 350 | 400 |
Drill hole diameter range /mm | 30-80 | 30-120 | 30-120 | 30-120 | 30-120 |
Maximum depth of machining /mm | 1500-3000 | 1000-12000 | 1000-12000 | 1000-12000 | 1000-12000 |
Workpiece clamping range /mm | 60-200 | 60-260 | 60-330 | 60-450 | 100-500 |
Guide rail width /mm | 510 | 650 | 650 | 650 | 650 |
Center height of spindle /mm | 300 | 350 | 350 | 450 | 550 |
Bedhead box spindle hole diameter /mm | 65 | 75 | 75 | 75 | 75 |
Spindle front cone hole /m | 75;1:20 | 85;1:20 | 85;1:20 | 85;1:20 | 85;1:20 |
The spindle speed range is r/min | 82-1250 (12 levels) | 61-1000 (12 levels) | 61-1000 (12 levels) | 65-523-(12 level) | 65-523 (Level 12) |
Feed speed range (stepless) mm/min | 5-260 | 5-260 | 5-260 | 5-260 | 5-260 |
The fast moving speed of the drag is m/min | 2 | 2 | 2 | 2 | 2 |
Main motor power /KW | 15 | 30 | 30 | 30 | 37 |
Motor power of hydraulic pump /KW | 1.5 | 2.2 | 2.2 | 2.2 | 2.2 |
Tablet quick motor power /KW | 3.6 (servo motor) | 3 (5-12m) | 3 (5-12m) | 3 (5-12m) | 3 (5-12m) |
Feed motor power /KW | 4 | 4.2 (servo motor) | 4.2 (servo motor) | 4.2 (servo motor) | 4.2 (servo motor) |
Cooling pump motor power /KW | 0.5 | 5.5 | 5.5 | 5.5, 4 | 5.5, 4 |
Rated pressure of cooling system /MPa | 200 | 0.5 | 0.5 | 0.5 | 0.5 |
Cooling system flow L/min | 6.3 | 300 | 300 | 300;200 | 300;200 |
Rated working pressure of hydraulic system /MPa | 6.3 | 6.3 | 6.3 | 6.3 | 6.3 |
Maximum axial force of the oil distributor /KN | 15 | 6.3 | 6.3 | 6.3 | 6.3 |
Maximum clamping force of the oil distributor on the workpiece /KN | 20 | 20 | 40 | 40 | |
Drill rod box spindle hole diameter/mm | 70 | 70 | 70 | 70 | |
Drill rod box spindle front cone hole /m | 80;1:20 | 80;1:20 | 80;1:20 | 80;1:20 | |
Motor power of drill rod box KW | 22 | 22 | 22 | 22 | |
Drill string box main shaft speed range, number of stages | 46-665 (8) | 46-665 (Grade 8) | 46-665 (Level 8) | 46-665 (Grade 8) |
Specification
High Accuracy Deep Hole Drilling Machine TK2235 Deep Hole Drilling and Boring Machine
TK2235 deep hole drilling and boring machine. According to the length of the workpiece, two processing techniques are selected for this product. The short workpiece is supplied with oil through an oil feeder and hydraulically clamped, while the long workpiece is supplied with oil through the end of the boring bar. The oil feeder adopts an innovative spindle structure, which greatly improves the load-bearing performance and higher rotation accuracy. The bed guide rail adopts suitable deep hole machining double flat guide rail, with high bearing capacity and good guiding performance. The guide rail has been quenched and has high wear resistance. It is suitable for boring and rolling processing in industries such as machine tool manufacturing, locomotives, ships, coal mining, hydraulic, power machine cores, and wind turbine cores, making the workpiece roughness reach 0.4-0.8 μ m. This series of deep hole boring machines can choose from the following working forms according to the workpiece situation: 1. Workpiece rotation, tool rotation, and feed motion. 2. Workpiece rotation, tool non rotation, and feed motion. 3. The workpiece does not rotate, the tool rotates, and the feed motion occurs.
1 Machine tool bed body
2 Bedside box drill box gearbox
3 The oil dispenser
Machine bed body rigid strong, good. After quenching treatment, high wear resistance.
The boring rod box uses servo motor to drive the spindle rotation, and the two-stage design realizes stepless speed regulation.
The spindle design adopts double thrust bearing, which can be pulled and bored.
The spindle design adopts double thrust bearing, which can be pulled and bored.
The illuminator is to supply oil to the tool and workpiece, while equipped with hydraulic device to tighten the workpiece, safe
and reliable.
and reliable.
4 Distribution box
5 Control system
6 Servo motor
Power distribution box is the control brain of the whole machine tool, using high-end electrical accessories, high configuration,
The control system adopts Beijing KND high-end system, with simple operation and powerful function and high precision.
The servo motor has constant torque, adjustable torque and high precision. High performance motor.
7 Three grasp card plate
8 Tool head and boring rod
9 Working bracket.
Three catch chuck high accuracy, strong stability, good to find.
All kinds of boring heads, rough heads, drills, drills, scraping, honing, etc can be customized to any size according to customer
The working bracket is a fixture to support and fix the workpiece.
CNC deep hole honing machine
CNC deep hole drilling and boring machine
CNC skiving roller burishing machine
Company Profile
Dezhou Jutai Machine Tool Manufacturing Co., Ltd.
he factory has a large mechanical processing equipment, 4000mm, 6000mm, 9000mm planer, various types of 1140 × 8000mm lathe, CNC boring machine, a large number of significant cross-section milling, large roller gear, machining centers, grinders, lathes, drilling machines, milling machines, more than 80 units.
The leading products are: the general category - deep hole drilling and boring machine (T2116, T2120), deep hole boring machine (T2225, T2235, the T2250), deep hole honing machine (2M2125A, 2M2135A); NC class - CNC deep hole drilling and boring machine (TK2120, TK2125), CNC deep hole boring machine (TK2235, TK2250). Deep hole gun drilling (ZK2102, ZK2103).
Deep hole machining tool, auxiliary: Standard Series - deep hole drills, deep hole boring head, rolling head, head and deep hole boring and roll combination honing first class, and to undertake non-standard deep hole tools, special hole drilling tool design manufacturing operations, according to production needs monomer tools and composite tools, product specifications from Φ30mm to Φ1000mm.
