Electric Induction Heat Treatment Furnce
1-4 Set
$15,0005 Set
$10,000Product information
High-quality Electric Induction Heat Treatment Furnce supplied by Shandong Kehua Intelligent Equipment Co., Ltd.. Bulk wholesale pricing ranges from $10,000 to $15,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Production Capacity:
1500 Pieces Per Year
Specification:
60KW
HS Code:
85166090
Origin:
China
Trade Term:
FOB, EXW, CFR, CIF, CIP, CPT, FCA
Model NO.:
GTR-10000 diathermy induction furnace
Structure:
Horizontal Type
Certification:
ISO
Specifications
Production Capacity:
1500 Pieces Per Year
Specification:
60KW
HS Code:
85166090
Origin:
China
Trade Term:
FOB, EXW, CFR, CIF, CIP, CPT, FCA
Model NO.:
GTR-10000 diathermy induction furnace
Structure:
Horizontal Type
Certification:
ISO
Type:
Induction Heating Machine
Payment Term:
LC, T/T, Western Union, Small-amount payment
Trademark:
Liuxingke
Brand:
Liuxingke
Port Of Loading:
QINGDAO Port
Transport Package:
Suitable for Sea Transportation
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2006-02-08
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, Western Union, Small-amount payment
Preferred Trade Term:
FOB, EXW, CFR, CIF, CIP, CPT, FCA
Port Of Loading:
QINGDAO Port
Product descriptions from the supplier
Energy-saving induction heating furnace
Equipment purpose:
1.Heating before forging:
used for heating before forging of gear, ring gear, half shaft connecting rod,bearing, shackle,rigging and other products
2.Oline heating:
pipeline anti-corrosion spraying, blue brittle blanking of bar stock,online tempering of steel (wire) pipe, ect.
3.Local heating:
bending of U-bolt, thermal assembly of drum, bending of steel pipe and other production heating processes.
Performance features:
1. Low power consumption
2.simple production operation, flexible incoming and outgoing materials, high degree of automation, online production can be realized.
3.high heating speed, less oxidation and decarburization, high efficiaency and good forging quality
4.wokpiece heating lenght, speed, temperature ect. can be accurately controlled
5.uniform heating of workpiece,small temperature difference between core and surface, high control accuracy
6.integrated design of inductor and furnace body, quick change connector for different inductor design, easy to change
7.comprehesive energy-saving and optimized design , low energy consumption , high efficiency and lower production cost than coal burning
8.meet the requirments of environmental protection, with small pollution, and reduce the labour intensity of workers.
GTR Series Diathermy Furnace Technical Parameters
After sale service
1.Quality Guarantee: 1 year. During the warranty period, provide accessories, free of charge
2.After the warranty period, provide accessories in time and guide installation and commissioning
3.Proving Installation and Commissioning
Supplier offers1-2Engineersfor instructing installation and commissioning. (10-15 days usually)
Equipment purpose:
1.Heating before forging:
used for heating before forging of gear, ring gear, half shaft connecting rod,bearing, shackle,rigging and other products
2.Oline heating:
pipeline anti-corrosion spraying, blue brittle blanking of bar stock,online tempering of steel (wire) pipe, ect.
3.Local heating:
bending of U-bolt, thermal assembly of drum, bending of steel pipe and other production heating processes.
Performance features:
1. Low power consumption
2.simple production operation, flexible incoming and outgoing materials, high degree of automation, online production can be realized.
3.high heating speed, less oxidation and decarburization, high efficiaency and good forging quality
4.wokpiece heating lenght, speed, temperature ect. can be accurately controlled
5.uniform heating of workpiece,small temperature difference between core and surface, high control accuracy
6.integrated design of inductor and furnace body, quick change connector for different inductor design, easy to change
7.comprehesive energy-saving and optimized design , low energy consumption , high efficiency and lower production cost than coal burning
8.meet the requirments of environmental protection, with small pollution, and reduce the labour intensity of workers.
GTR Series Diathermy Furnace Technical Parameters
| Model | Power Input | Power Output | |||||
| Inlet Voltage(V) | Inlet Current(A) | DC Voltage(V) | DC Current(A) | MF Frequency(KHz) | MF Voltage(V) | MF Power(KW) | |
| GTR-60 | 380 | 100 | 500 | 120 | 1-8 | 750 | 60 |
| GTR-100 | 380 | 160 | 500 | 200 | 1-8 | 750 | 100 |
| GTR-120 | 380 | 200 | 500 | 240 | 1-8 | 750 | 120 |
| GTR-160 | 380 | 260 | 500 | 320 | 1-8 | 750 | 160 |
| GTR-200 | 380 | 330 | 500 | 400 | 1-8 | 750 | 200 |
| GTR-250 | 380 | 410 | 500 | 500 | 1-8 | 750 | 250 |
| GTR-300 | 380 | 490 | 500 | 600 | 0.4-8 | 750 | 300 |
| GTR-400 | 380 | 650 | 500 | 800 | 0.2-6 | 750 | 400 |
| GTR-500 | 380 | 820 | 500 | 1000 | 0.2-6 | 750 | 500 |
| GTR-750 | 380 | 1200 | 500 | 1500 | 0.2-6 | 750 | 750 |
| GTR-750 | 660 | 680 | 890 | 850 | 0.2-6 | 1300 | 750 |
| GTR-1000 | 380 | 1650 | 500 | 2000 | 0.2-1 | 750 | 1000 |
| GTR-1000 | 660 | 920 | 890 | 1150 | 0.2-1 | 1300 | 1000 |
| GTR-1500 | 380 | 2500 | 500 | 3000 | 0.2-1 | 750 | 1500 |
| GTR-1500 | 660 | 1400 | 890 | 1700 | 0.2-1 | 1300 | 1500 |
| GTR-2000 | 580 | 2100 | 780 | 2600 | 0.2-0.5 | 1170 | 2000 |
| GTR-2000 | 660 | 1850 | 880 | 2300 | 0.2-0.5 | 1300 | 2000 |
| GTR-2000 | 1250 | 1000 | 1650 | 1200 | 0.2-0.5 | 1300 | 2000 |
| GTR-2500 | 580 | 2600 | 780 | 3200 | 0.2-0.5 | 1170 | 2500 |
| GTR-2500 | 660 | 2300 | 880 | 2850 | 0.2-0.5 | 1300 | 2500 |
| GTR-2500 | 1250 | 1300 | 1650 | 1500 | 0.2-0.5 | 1300 | 2500 |
| GTR-3000 | 580 | 3100 | 780 | 3850 | 0.2-0.5 | 1170 | 3000 |
| GTR-3000 | 1250 | 2800 | 1650 | 2400 | 0.2-0.5 | 2400 | 3000 |
| GTR-5000 | 1250 | 4600 | 1650 | 3800 | 0.2-0.5 | 2400 | 5000 |
| GTR-10000 | 1250 | 9200 | 1650 | 7600 | 0.2-0.3 | 2400 | 10000 |
After sale service
1.Quality Guarantee: 1 year. During the warranty period, provide accessories, free of charge
2.After the warranty period, provide accessories in time and guide installation and commissioning
3.Proving Installation and Commissioning
Supplier offers1-2Engineersfor instructing installation and commissioning. (10-15 days usually)
