Electron-Axis Deviation Measuring Meter Testing Equipment
1 set
$2,9991 set
$1,199Product information
High-quality Electron-Axis Deviation Measuring Meter Testing Equipment supplied by JINAN JMLAB INSTRUMENT CO., LTD.. Bulk wholesale pricing ranges from $1,199 to $2,999 per set with a minimum order of 1 set. Inquiry for latest prices.
Weight:
0-100Kg
Instrument Range:
0-12.5mm
Rotating Speed:
0-30c/Min Adjustable
Graduation Value:
0.001mm
Accuracy Grade:
1
Production Capacity:
100 Sets/Month
Measurable Height:
15mm-400mm
Sample Diameter:
5-190mm
Specifications
Weight:
0-100Kg
Instrument Range:
0-12.5mm
Rotating Speed:
0-30c/Min Adjustable
Graduation Value:
0.001mm
Accuracy Grade:
1
Production Capacity:
100 Sets/Month
Measurable Height:
15mm-400mm
Sample Diameter:
5-190mm
Package Size:
50.00cm * 45.00cm * 65.00cm
Specification:
500x450x650mm
Package Gross Weight:
80.000kg
HS Code:
9031809090
Maxcapacity:
<1000KN
Max Diameter Of Workpiece:
<500mm
Mass Scope Of Workpiece:
<900kg
Power Source:
AC220V
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Control:
Computer Control
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Display:
Digital
Type:
Digital Display Automatic Axis Deviation Measuring
Load Way:
Electronic Load
Trade Term:
FOB, EXW, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA
Trademark:
JMLAB or OEM
Model NO.:
JMZPC-18
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Oil Cylinder Position:
None
Port Of Loading:
Qingdao port, Shanghai Port
Transport Package:
Standard Export Package
Loading Method:
Static Load
Payment Methods:
Support payments in USD
Instrument Indication Error:
±0.005mm
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2016-10-24
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA
Port Of Loading:
Qingdao port, Shanghai Port
Certificates:
Fatigue Tester Software Copyright, Patent Certificate, Sealing Tester Software Copyright, Texture Analyzer Software Copyright, UTM Software Copyright
Product descriptions from the supplier
Application:
It is used to measure the vertical axis deviation of various glass bottles, plastic bottles, infusion bottles, injection bottles, and porcelain bottle containers in the food, cosmetic, pharmaceutical and other industries. Fully automatic computer program test mode. The electronic shaft deviation measuring instrument will automatically rotate to read the size value and deviation value, and draw the roundness curve to help customers analyze the quality of the sample. It is a product with the highest test automation and precision among similar products.
Technical features
• Microcomputer control, touch screen display;
• With automatic statistics of size value and deviation value, the small scale value of the instrument is not less than 0.001mm;
• The fixture is easy to operate and has high centering accuracy, which improves the measurement accuracy;
| Items | Specification |
| Sample diameter | 5-190mm |
| Instrument range | 0-12.5mm |
| Graduation value | 0.001mm |
| Instrument indication error | ±0.005mm |
| Rotating speed | 0-30c/minadjustable |
| Measurable height | 15mm-400mm |
| Dimensions | 400mm×350mm×560mm(L*W*H) |
| weight | 67kg |
Yes, we are one of professional Manufacturers like Universal Testing machines, Fatigue Testing Machines,Torsion And Bending Testing Machines,Friction And Wear Testing Machines,Package Testers, Texture Analyzer,Plastic Rubber Testers, Adhesive testers and other testing Equipment.. .Every machines purchasing from our factory has 12 months warranty after shipment. Generally, we offer 12 months for the FREE maintenance. while considering of sea transportation,we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an E-mail or call ,we will try our best to find the problem through our conversation or by video chat if neccesary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What's the delivery term?
1-3 working days for the standard machine if we have stock in the warehouse. If there is no stock, normally, the delivery time is 3-15 working days after deposit receipt ( this is only for our standard machines). If you are in urgent need, we will making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4.How can I install and use the machine?
Once you have ordered the testing machines from us, we will send the operation manual and video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use. And if it's necessary, we can also assist you to install your machine on site.
5. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
Bottle Internal Pressure Resistance Tester ASTM D3078 Bottle Leak Tester Thickness Tester
