Electronic 100kN Tensile Testing Machine Plastic Tensile Impact Strength Testing Machine
1 Piece
$3,302Product information
High-quality Electronic 100kN Tensile Testing Machine Plastic Tensile Impact Strength Testing Machine supplied by Dongguan Huanyi Instrument Technology Co., Ltd.. Bulk wholesale pricing is $3,302 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Test Speed:
0.004-510mm/Min Keyboard Input Control
Production Capacity:
10000pieces/Year
Test Width:
120mm
Machine Capacity:
2 Kg, 5 Kg, 10 Kg, 20 Kg, 50 Kg, 100 Kg, 200 Kg, 5
HS Code:
9024109000
Test Accuracy:
<±0.5%
Power Source:
AC380V
Machine Weight:
About 70kg
Specifications
Test Speed:
0.004-510mm/Min Keyboard Input Control
Production Capacity:
10000pieces/Year
Test Width:
120mm
Machine Capacity:
2 Kg, 5 Kg, 10 Kg, 20 Kg, 50 Kg, 100 Kg, 200 Kg, 5
HS Code:
9024109000
Test Accuracy:
<±0.5%
Power Source:
AC380V
Machine Weight:
About 70kg
Origin:
China
Control:
Computer Control
Specification:
Customized
Display:
Digital
Trade Term:
FOB, CFR, EXW, CIF
Trademark:
HUANYI
Multiple Unit Switching:
Kg, G, Lb, N, kN, etc.
Maxcapacity:
Other
Load Way:
Other
Oil Cylinder Position:
Other
Loading Method:
Other
Accuracy Grade:
Other
Mass Scope Of Workpiece:
Other
Max Diameter Of Workpiece:
Other
Weight:
Other
Port Of Loading:
Shenzhen
Transport Package:
Standard Export Wooden Box
Payment Term:
T/T, LC, D/P, PayPal, Western Union, Small-amount payment
Type:
Tensile Testing Machine
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2007-03-20
Annual Revenue Amount:
Not specified
Numbers Of Employees:
41
Preferred Payment Term:
T/T, LC, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CFR, EXW, CIF
Port Of Loading:
Shenzhen
Certificates:
CE, ISO14001, ISO45001:2018, ISO9001:2015
Product descriptions from the supplier
Microcomputer controlled electronic universal testing machine/Tension testing machine suitable for rubber, plastic, leather and other flexible materials with large deformation. It can complete tensile, tearing, bonding strength, peeling and other tests. It is equipped with a large deformation extensometer with special terms for measuring sample deformation, which is suitable for mechanical property testing of materials with large deformation.
Applied industries: Universal material testing machines are widely used in measurement and quality inspection; clothing and footwear industry; rubber and plastics; metallurgy and steel; machinery manufacturing; electronic appliances; automobile production; textile and chemical fibers; wires and cables; packaging materials and food; instruments and meters; medical equipment ; Civilian nuclear energy; civil aviation; colleges and universities; scientific research laboratories; commodity inspection and arbitration, technical supervision departments; building materials and ceramics; petrochemical industry; other industries.
Microcomputer controlled electronic universal testing machine is mainly used for mechanics such as tension, compression, bending, shearing, peeling, tearing, friction, etc. of metal, rubber, plastic, fiber, leather, braid, wire, cable, building materials, wood, etc. Performance testing is a new material testing machine that combines a new generation of green electronic technology with sophisticated mechanical transmission. This series of models has low standby power consumption, low noise, long life and no pollution to the environment.
The testing machine has a reasonable structure, stable loading and precise control. The measurement and control system adopts the AEC-1200 controller and cooperates with the all-round modular TestLive computer test software to ensure stable operation of the entire system, accurate measurement, and reliable testing.
This series of models complies with the requirements of the "GB/T 16491-2008 Electronic Universal Testing Machine" standard.
The universal material testing machine uses imported photoelectric encoders for displacement measurement. The controller adopts an embedded single-chip microcomputer structure and has built-in powerful measurement and control software, integrating measurement, control, calculation, and storage functions. It has the function of automatically calculating stress, elongation (requiring an extensometer), tensile strength, and elastic modulus, and automatically counting the results; automatically recording the force value or elongation of the maximum point, breaking point, and designated point; using a computer to conduct tests Dynamic display of process and test curves, and data processing. After the test, the curve can be enlarged through the graphics processing module for data re-analysis and editing, and reports can be printed.
| Machine capacity | 2 kg, 5 kg, 10 kg, 20 kg, 50 kg, 100 kg, 200 kg, 500 kge |
| Test speed | 0.004-510mm/min keyboard input control |
| Multiple unit switching | Kg, g, lb, n, kn, etc. |
| control method | Variable frequency, stepping and servo can be fully automatic control (with automatic return origin) |
| Machine trip | 650mm (without fixture) Standard stroke 1000mm (including fixture) can be extended according to customer needs |
| Test width | 120mm |
| Machine weight | About 70kg |
| Test accuracy | <±0.5% |
| Force measurement | Resolution 1 / 25000 accuracy 0.3%. |
| Load cell | Load capacity 5N-5000KN, |
| Accuracy is | 0.5% |
| Comply with BS EN ISO 7500 Part 1 and ASTM E4. | |
| For precision | 0.5% |
| The reading drops to 2% of the load range | |
| And the reading drops to zero load | |
