Enameled Wire Insulation Varnish (BPU) 180 Polyurethane
16000 Kg
$3.516000 Kg
$4Product information
High-quality Enameled Wire Insulation Varnish (BPU) 180 Polyurethane supplied by SWAN Wire Engineering. Bulk wholesale pricing ranges from $3.5 to $4 per Kg with a minimum order of 16,000 Kg. Inquiry for latest prices.
Recomd. Wire Size:
0.02mm to 1.6mm
Specification:
200kg/drum
Solid Content:
22 to 34(1g/1h/180℃)
Thermal Rating:
220 220
Model NO.:
BPU 180
Origin:
China
Wire:
Enameled
Trade Term:
FOB, CIF, CFR, EXW
Specifications
Recomd. Wire Size:
0.02mm to 1.6mm
Specification:
200kg/drum
Solid Content:
22 to 34(1g/1h/180℃)
Thermal Rating:
220 220
Model NO.:
BPU 180
Origin:
China
Wire:
Enameled
Trade Term:
FOB, CIF, CFR, EXW
Certification:
ISO9001
Type:
Insulation Varnish
Payment Term:
LC, T/T
Chemistry:
Polyurethane
Material:
Polyurethane
Trademark:
SWAN
Port Of Loading:
Shanghai Port
Transport Package:
Steel Drums
Brand:
Swan
Recomd Coating Method:
Via Felt or Die
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2011-08-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
8
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
ISO, OHSAS, Reach, ROHS, UL
Product descriptions from the supplier
SW-BPU 2180 polyurethane insulating enamel varnish
The enamels possess high heat resistance, high cut through temperature, excellent soldering performance, and good pin hole performance. They are widely used in DV higher horizontal and vertical machines, and can be used alone or coated with aliphatic nylon enamels. The products can be applied to flat wire. The products have been UL listed.
| Products type | Solid content | Viscosity | Recomd wire size | Recomd coating method | ||
| 1g/1h/180ºC | 1.2g/3h/120ºC | D4 cup, 25ºC/s | Cone plate, 25ºC/(mPa.s)) | |||
| BPU 2180/22 | 22±1% | 25±1% | 15-20 | -- | 0.02-0.06 | Via felt |
| BPU 2180/25 | 25±1% | 30±1% | 18-24 | -- | 0.05-0.15 | Via felt |
| BPU 2180/30 | 30±1% | 35±1% | 25-40 | -- | 0.10-0.30 | Via felt |
| BPU 2180/34 | 34±1% | 40±1.5% | 80-120 | 350-600 | 0.30-1.60 | Via die |
Enameled wire's performance
| Film thickness | 0.010mm | 0.050mm |
| Flexibility, Adhesion | Jerk test, no bare | 15% winding tension, 1D |
| Heat shock | 200ºC,0.15mm | 200ºC, 1D |
| Cut through temp. | 250ºC | 250ºC |
| Pin hole | 3%,5% Elongation, 0 hole | 3%,5% Elongation, 0 hole |
| Breakdown voltage | 1000V | 8000V |
| Solderability(375ºC) | 2s | 4s |
| TgD | 165ºC | 170ºC |
The products with 200L iron drums or 1000L plastic IBC packages are available.
SWAN INT'L , based in Shanghai , is the manufacturer and exporter of wire , cable and its manufacturing equipments ; the company also provides the consulting service for international bidding projects, Chinese supplier sourcing service for the industrial products supply chain development .
The company has developed its business with more than 100 overseas clients in more than 20 countries and regions such as Germany,Italy, Brazil, Southeast Asia, Russia, Turkey, the Middle East Region , Africa, etc.For wire and cable industry , the company provide the overall whole factory technology solutions for wire and cable companies , including the whole factory tailor made technical design , manufacturing equipment technology consulting service , equipments selection and innovation. We supply wire and cable products and OEM service .
Our equipments includes :full line for copper rod up-casting manufacturing,Tandem line for CAT5/6/7 series and coaxial cable manufacturing,Equipment units for Drawing/Stranding/Bunching /Extrusion .Our wire and cable products includes : Power cable,telecommunication cable , Enameled copper ( aluminum ) wire ,etc .
China government's new " Road and Belt " policy , provide one brand new chance for industry manufacturing capacity cooperation with overseas country and regions .By this new policy ,Shanghai SWAN INT'L sincerely hope to establish and develop long-term , mutual benefit relationship with you in the future
