Fast Accurate Foif Rts102 Measuring and Surveying Instruments Total Station
1-4 set
$2,0005-9 set
$1,80010 set
$1,500Product information
High-quality Fast Accurate Foif Rts102 Measuring and Surveying Instruments Total Station supplied by Shanghai Hexin Survey Instrument Co., Ltd.. Bulk wholesale pricing ranges from $1,500 to $2,000 per set with a minimum order of 1 set. Inquiry for latest prices.
Working Temperature:
-20~+50
Transport Package:
1 Piece Packed in 1 Inner Carton
Warranty:
1 Year
Production Capacity:
10000 Pieces/ Year
Carton Weight:
11kg
Keyboard:
2 Sides Alphanumeric
Accuracy:
2"
Working Time:
26 Hours
Specifications
Working Temperature:
-20~+50
Transport Package:
1 Piece Packed in 1 Inner Carton
Warranty:
1 Year
Production Capacity:
10000 Pieces/ Year
Carton Weight:
11kg
Keyboard:
2 Sides Alphanumeric
Accuracy:
2"
Working Time:
26 Hours
Single Prism:
5000m
Specification:
55*43*33
HS Code:
9015800090
Angle Measurement:
Absolute Encoder
Trade Term:
CIF, FOB, CFR
Compensator:
Dual-Axis Compensation
Trademark:
FOIF
Model NO.:
FOIF RTS102
Payment Term:
LC, T/T, D/P, PayPal, Western Union
Vertical Lines:
None
Horizontal Line:
None
Origin:
Shanghai China
Port Of Loading:
Shanghai Port
After Sales Service:
Yes
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2013-08-26
Annual Revenue Amount:
Not specified
Numbers Of Employees:
12
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union
Preferred Trade Term:
CIF, FOB, CFR
Port Of Loading:
Shanghai Port
Certificates:
Star suppliers
Product descriptions from the supplier
PRODUCT DESCRIPTION
KEY FEATURES
Measuring distance: 600m (R600) / 1000m(R1000)
Same technical maintenance on R600 and R1000
Bluetooth cable-free connection ( Factory Optional)
1 20000 points and 40 Jobs can be saved
Can be operated with a data collector, FOIF FieldGenius,or other third party software is available
IP66 environmental protection
Alphanumeric keyboard
PRODUCT SHOW
PRODUCT SPECIFICATION
| Model | RTS102 | RTS105 |
| Angle Measurement | ||
| Reading system | Absolute Encoder | |
| Angle Unit | 1" | |
| Display resolution | 1"/5"/10" | |
| Accuracy | 2" 5" | |
| Telescope | ||
| Magnification | 30X | |
| Field of View | 1°30' | |
| Minimum Fousing Distance | 1.0m | |
| Length | 156mm | |
| Image | Erect | |
| Objective aperture | 45mm | |
| Compensator | ||
| compensator | Dual-axis | |
| Range | ±3' | |
| Accuracy | 1" | |
| Distance Measurement (with Reflector) | ||
| Single Prism | 1 to 5000m | |
| Reflective Sheet /RP60 | 800m | 800m |
| Accuracy | 2mm+2ppm | |
| Measuring Time | 1s/0.5s | 1s/0.5s |
| Distance Measurement (Reflectorless) | ||
| Reflectorless Range R600 | 600m | 600m |
| Reflectorless Range R1000 | 1000m | 1000m |
| Accuracy | 3mm+2ppm | |
| Measuring Time | 1.5s-5S, Max. 20s | |
| Communication | ||
| Memory | Approx.120000 points, support SD card(max. 16GB) | |
| Interface | USB/RS-232C/Bluetooth (factory optional) | |
| Data transfer software | FOIF Geomatics office (FGO) | |
| data collector | F58, fully rugged PDA (optional) | |
| Operation | ||
| Dimensions | 175*178*340mm | |
| Weight (including batteries) | 5.1kg | |
| Display | LCD, 6 lines *20 characters (96*160 dots) | |
| Keyboard | 2 sides Alphanumerical key board | |
| CPU | 32Bit | |
| Laser Plummet | ||
| Laser class | class 2/ IEC60825-1 | |
| Accuracy | 1mm/1.5m | |
| Laser spot brightness | adjustable | |
| Laser wave length | 635nm | |
| Optical Plummet (factory optional) | ||
| Accuracy | 0.8mm / 1.5m | |
| Image | Erect | |
| Magnification / Field of View | 3x/4 | |
| Focus range | 0.5m to infinite | |
| Environmental | ||
| Operating Temperature | -20ºC+50ºC(-4F~+122F) | |
| Storage Temperature | -40ºC+70ºC(-40F~158F) | |
| Temperature & Pressure | Manual input | |
| Dust & Waterproof (IEC60529 standard) | IP66 | |
| Power Supply | ||
| Battery Type | 3400mAh Li-ion Rechargeable | |
| Output Voltage/ Capacity | 7.4V(DC) | |
| Operating Time | Approx. 26 hours(at +20) (single distance measurement every 30 seconds) | |
| Charger | EDJ6-LI(100V/240V) | |
| Charging time | Approx. 4 hours | |
PAYMENT
COMPANY INFORMETION
Shanghai Hexin Survey Instrument Co., LTD has 8 years' experience in geodetic surveying and cadastration surveying, we are a professional and leading enterprise in the surveying industry in MainlandChina. We specialize in the R&D and manufacturing and sales of all kinds of surveying products, including total station, electronic theodolite, electronic distance meter, automatic level, laser level, reflector prism, surveying accessory, GPS receiver, mapping software, etc.The marketing model advocated by us is not a simple sense of "selling products", instead, pre-sales service, services during operation and after-sales service are integrated in entire operating activities. It makes the customers feel that they purchased not only a commodity, but also a professional service.We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
FAQ
Q:How to turn off voice broadcast of receiver?
A: a. Enter the WEBUI, find the voice switch in the settings page and turn it off.
b. Controller Software→Device→Device Setting, turn off the "enable voice", and click"ok"
Q: Can the base station and rover station be interchangeable?
A: The difference between the rover station and the base station is that the accessories are different, the function and hardware configuration are the same.You can use the controller to choose the working mode of the device and set it as the base station or rover station.
Q: What is CORS?
A: CORS is called a continuous operating reference station system. It can be understood as a bas e station that is erected at a fixed known point and works continuously for 24 hours and sends its own data to a specific serverthrough the network. The use of CORS operation eliminates the need for a base station, and CORS is equivalent to a base station in a normal network operation.
