Fiberglass Flowmat Sandwich PP Chopped Core Strand for Rtm Flow Mat Composite Materials
1 Meter
$1.51 Meter
$1.25Product information
High-quality Fiberglass Flowmat Sandwich PP Chopped Core Strand for Rtm Flow Mat Composite Materials supplied by CHANGZHOU ZHONGJIE COMPOSITES CO., LTD.. Bulk wholesale pricing ranges from $1.25 to $1.5 per Meter with a minimum order of 1 Meter. Inquiry for latest prices.
Unit Density:
1380g (+/-5%)
Product Design:
3 Layers, Stitched Together by Polyester Yarn
MOQ:
360kgs on One Pallet
Specification:
40kgs/roll, 9 rolls in one pallet
Production Capacity:
500tons Per Month
HS Code:
7019140090
Applications:
Auto Parts, Wind Energy, FRP Tanks etc;
Origin:
Changzhou City, Jiangsu Provice, China
Specifications
Unit Density:
1380g (+/-5%)
Product Design:
3 Layers, Stitched Together by Polyester Yarn
MOQ:
360kgs on One Pallet
Specification:
40kgs/roll, 9 rolls in one pallet
Production Capacity:
500tons Per Month
HS Code:
7019140090
Applications:
Auto Parts, Wind Energy, FRP Tanks etc;
Origin:
Changzhou City, Jiangsu Provice, China
Fiber Appearance:
Chop Strand Stitched Mat
Product Structure:
Chopped Strands + PP Core + Chopped Strands
Glass Composition:
E-Glasss and ECR-Glass
Trade Term:
FOB, CIF, CFR, EXW
Diameter Of Filaments:
Intermediate Fibers
Payment Term:
LC, T/T
Product Code:
M600p180m600
Transport Package:
Roll Carton Packing, Per Into Pallets
Suitable Process:
Rtm, Vacuum Infusion, Mold Pressure etc;
Port Of Loading:
Shanghai Port
Trademark:
ZHONGJIE
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2009-02-25
Annual Revenue Amount:
Not specified
Numbers Of Employees:
84
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
ISO9001:2015
Product descriptions from the supplier
| Product Type: | ECR glass fiber PP core combination mat |
| ZHONGJIE Code: | EMNM600/180/600 |
| Unit weight: | 1380g/m2 (+/-5%) |
| Raw material: | Fiberglass assembled roving, PP core material, Polyester yarn |
| Technics: | ECR glass fiber PP core combination mat is made of chopped roving combined PP core layer and plus the chopped strands, then stitched together by polyester yarn as sandwich structure |
| Chopped density: | 600/600 g/m2 (top/bottom layer) |
| Prodcue Type: | 300/180/300, 300/250/300, 450/180/450, 450/250/450,600/180/600, 600/250/600 |
| PP core density | 180g/m2 (+/-5%) |
| Polyetser yarn: | 8g/m2 (+/-5%) |
| Roll packing width: | Normal size is 1270mm, tape size available from 200mm to 2600mm, depends on customer's real needs |
| Mositure content: | ≤0.15% |
| Wet speed | ≤45/S |
| Sizing/Coupling agent: | Silane |
| Combustible Content: | 0.4 - 0.8% |
| Usage process: | RTM, LRTM, Vaccum infusion,Compression molding etc; |
| Compatible resins: | Polyester resin, Vinyl resin, Epoxy resin, Phenolic resin etc; |
| Application: | Wind nacelle, Boats & Yachts, FRP vessel/Cover, Auto parts, Waterpark equipments etc; |
Catalog refer:
| Product code | Specification (Layer weight (g/m²) | Standard roll width (mm) | Surface fleece available | ||||
| Chopped strands | PP | Chopped strands | Stitch yarn | Unit weight (g/m2) | |||
| EMNM300/180/300 | 300 | 180 | 300 | 8 | 788 | 1270/2540 | Polyester tissue |
| EMNM450/180/450 | 450 | 180 | 450 | 8 | 1088 | 1270/2540 | Polyester tissue |
| EMNM600/180/600 | 600 | 180 | 600 | 8 | 1388 | 1270/2540 | Polyester tissue |
| EMNM300/250/300 | 300 | 250 | 300 | 9 | 859 | 1270/2540 | Polyester tissue |
| EMNM450/250/450 | 450 | 250 | 450 | 9 | 1159 | 1270/2540 | Polyester tissue |
| EMNM600/250/600 | 600 | 250 | 600 | 9 | 1459 | 1270/2540 | Polyester tissue |
EMNM750/250/750 |
750 | 250 | 750 | 9 | 1759 | 1270/2540 | Polyester tissue |
Product Introduction:
Fiberglass core mat is a type of composite material used in the manufacturing of reinforced plastics and composites. It consists of a core material made from glass fibers that are bonded together with a binder resin.
The primary component of fiberglass core mat is glass fibers. These fibers are typically made from E-glass, which is a type of glass known for its excellent mechanical properties and chemical resistance. The fibers may be chopped or continuous strands, depending on the specific application and manufacturing process.
Fiberglass core mat is used in a wide range of applications across various industries. It is commonly used as a core material in sandwich structures, where it provides strength and stiffness to the composite while keeping the overall weight low. It is also used in the construction of fiberglass panels, pipes, tanks, and other structural components.
Fiberglass core mat offers several advantages, including high strength-to-weight ratio, corrosion resistance, electrical insulation properties, and thermal stability. It is also relatively inexpensive compared to other core materials, making it a cost-effective choice for many applications.
• Incorporated surface veil offers reduced print-through, Stitch free for improved visual appearance
• Very good drapability, High-Flow version with faster flow rate
• Cut mat has tidy edges, clean and free of fraying with no fiber falling out
• Flexible range of applications and individually adaptable
• Clean splicing avoids thick overlaps of composite material, Better blister performance can remove the need for added barrier coat
• Incorporated surface veil offers reduced print-through, Stitch free for improved visual appearance
• Very good drapability, High-Flow version with faster flow rate
• Cut mat has tidy edges, clean and free of fraying with no fiber falling out
• Flexible range of applications and individually adaptable
• Clean splicing avoids thick overlaps of composite material, Better blister performance can remove the need for added barrier coat
Changzhou Zhongjie Composites Co., Ltd is specialized in the researching, Manufacturing and marketing of high performance fiberglass fabrics serving for the fields of wind energy, Boat building, Traffic vehicle, Sports equipment, Anti-corrosion industry...etc.ZHongjie Composites main products: Fiberglass multi-axial fabric, Woven roving, Chopped strand mat, Stitched mat, E-glass combo mat, PP core combo mat, Gel coat, Color paste, Resin...etc; Meanwhile, Zhongjie also acts as distrutors for some well-known international manufactures of equipments and materials which are using in LRTM, Vacuum infusion, SMC, Wind filament, Pultrusion process in China. Zhongjie engages in supplying one-stop composites solution provide for our valuable customers.It has several sets of advanced are machines and technology from Karl Mayer and Liba, also company has a professional technical and manufacture team in glass fiber reinforced composite industry for many years to ensure the glass fiber fabric and polymer synthesis products in competitive advantage and strong professional ability of continuous improvement.
Zhongjie Composites is able to offer first class quality and main products with full trace ability by ISO9001, ISO14001, CCS, DNV approved. The company always adhere to "Creating value for customers, Creating wealth for the society, Creating opportunities for employees" as development purposes, stick to "Professional focus, Innovative intrepreneurship" spirit, providing customers with the most valuable glass fiber reinforced plastic composite materials integration solutions.It consists of three parts: Zhongjie Fiberglass, Zhongjie Chemical and Zhongjie new functional material. We sincerely look forward to working with you hand in hand.
Applications refer:
ECR glass fiber PP core combination mat widely used in RTM applicated to Auto parts, Railways, Wind energy, Yachts building, Waste-water treatment, Waterpart equipments etc;
• Best fiberglass roving and chopped strand supply in China like JUSHI, CTG, CPIC, Shandong fiberglass keeps our products excellent performance and steady in quality.
• Well-known in FRP forming process and application keeps our products more outstanding and humanized.
• Professional and experienced staff makes our production line more efficient and contineous improvement.
• Good management makes our product more competitive in trunout and prices.
• More than 45 sets production lines with kinds of machines makes us great production capacity.
Exhibition notice (We will be there waiting for you):
• JEC Shanghai expo -- Sep., 2018
• India composites show -- Dec., 2018
• JEC Paris expo -- March., 2019
Q: Are you a factory or trading company?
A: We are a professional fiberglass fabrics and mats manufacturer from 2008, doing kinds of fierglass composites.
Q:Where is your factory located? How can I visit there?
A: Our factory located in Tianning district, Changzhou city, Jiangsu province. About 1.5-2 hours from Shanghai(air port and train station), All our clients, from home or abroad, are warmly welcome to visit us!
Q: What is your annual turn over?
A: In 2017, yearly output more than 18,000 tons, and turnover more than 150,000,000 RMB.
Q: How can you guarantee your quality?
A: Quality is priority. Zhongjie people always attach great importance to quality con trolling from the very beginning to the very end
1. All raw materials we used are from very famous, quality ensured factory like Jushi, CTG, Shandong Fiberglass...
2. Skillful workers care every details in production, packing, transporting. To make sure costomers recived our best made.
3. Quality control department with experienced professers, engineers who from authroized FRP Universities, Reaseach institutes...etc;
Q: What is your lead time?
A: Usually in 7-10 days for productions and stock always about 3-5 days.
