Fiberglass Pipes Pullwinding Production Machine HS Code 84778000 Model NO. BLR-2-200 Origin Jinan, China Trademark GOLD LEAD
1 Set
$85,0002 Set
$83,000Product information
High-quality Fiberglass Pipes Pullwinding Production Machine HS Code 84778000 Model NO. BLR-2-200 Origin Jinan, China Trademark GOLD LEAD supplied by Shandong Gold Lead Machinery Co., Ltd.. Bulk wholesale pricing ranges from $83,000 to $85,000 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Max. Diamerter:
250mm
Production Capacity:
30units/Month
HS Code:
84778000
Automation:
Automation
Model NO.:
BLR-2-200
Automatic Production Line:
Comprehensive
Trade Term:
FOB, CIF, CFR
Rhythm:
Flow Production Line
Specifications
Max. Diamerter:
250mm
Production Capacity:
30units/Month
HS Code:
84778000
Automation:
Automation
Model NO.:
BLR-2-200
Automatic Production Line:
Comprehensive
Trade Term:
FOB, CIF, CFR
Rhythm:
Flow Production Line
Trademark:
GOLD LEAD
Certification:
ISO, CE
Origin:
Jinan, China
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Production Scope:
Product Line
Port Of Loading:
Qingdao Port, Shanghai Port, Ningbo Port, Tianjin Port,
Transport Package:
as Customer's Requirement
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-03-05
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Qingdao Port, Shanghai Port, Ningbo Port, Tianjin Port,
Certificates:
CE certificate, ISO9001
Product descriptions from the supplier
| Total power: ≈20kW (not including die heating power) 380V/50Hz |
| Dimension: 35m(L)*2m(W)*2m(H) |
| Description | Technical Data | Qty | ||
| Roving Creels | Ivory paint, combined structure, easy accessibility | 2 | ||
| Equipped with tension device | ||||
| Qty/No. of layers: 90pcs/5 layers | ||||
| Dimension: 2000mm(L)x700mm(W)x2000mm(H) | ||||
| Not removable type | ||||
| Resin Bath | Dimension of bath body: 1030x720x190mm | |||
| Material of bath body:304 stainless steel | ||||
| Dimension of bath frame: 1610x810x1500mm | ||||
| Heating type or not: not | ||||
| Roving guider | No. of holes: 500 | 1 | ||
| Sizes of roving guider: 1000x800mm | ||||
| Material of guiding board: PE | ||||
| Mat support | Width of horizontal type mat support: ≤1000mm | 1 | ||
| Diameter of vertical type mat support disc: 360mm | ||||
| Qty: one horizontal type, two vertical type | ||||
| Die table | Width of die: 700mm | 1 | No. of heating zone can be increased | |
| Length of die: 900mm | ||||
| Adjustable height of die mounting board: 0-100mm | Manual adjust | |||
| Die adjustment method: three-dimensional adjustment | Power of temperature zone: 4kW-6kW. | |||
| Heating (temperature) zones: 4-6 | ||||
| Speed display: Omron touch screen | ||||
| Temperature display: Omron touch screen | ||||
| Operation panel: touch screen + knobs | ||||
| hydraulic pressure adjustment: pressure regulating valve | ||||
| Pressure display: pressure gauge | ||||
| Protection cover: carbon steel spraying | ||||
| Dimension: 4860x1150x2200mm | ||||
| Puller | Clamping sizes: 800x440mm | 1 | ||
| Length of clamping board: 610mm | ||||
| Max. pulling force: 300kN | ||||
| Max. clamping force: 300kN | ||||
| Pulling speed: 0.1-0.7m/min | ||||
| Max. pulling reciprocating stroke: 600mm | ||||
| Clamping stroke: 150mm | ||||
| Pulling cylinder: HSG Ø160X600 | ||||
| Clamping cylinder: HSG Ø 160X150 | ||||
| Type of oil pump motor: three phase | ||||
| Power of oil pump motor: 2x4kW 380V/50Hz | ||||
| Power of circulating water pump: 1.5kW 220V | ||||
| Dimension: 5200x1150x2000mm | ||||
| Winding machine | Central height of roller disc: 1280mm±40mm | 1 | ||
| Max. winding diameter: Ø 350mm | ||||
| No. of winding head: 1 | ||||
| No. of spindles: 24 | ||||
| Max. spindle diameter: Ø200mm | ||||
| Rotation speed: 0-10rpm | ||||
| Winding space is adjustable | ||||
| Power: 4.4kW | ||||
| Synchronous control with puller on touch screen | ||||
| Servo driving: YASKAWA | ||||
| Cutter | Max. cutting range: 800x220mm | 1 | ||
| Rotation speed of saw blade: 1450r/min | ||||
| Cutting motor: 3kW | ||||
| Dust collection method: vacuum cleaner 3.5kW 220V | ||||
| Diameter of saw blade: Ø600/Ø50mm | ||||
| Cutting modes: Auto/Manual | ||||
| Cutting tracking stroke: 700mm | ||||
| Fix length cutting method: optoelectronic switch | ||||
| Clamping method: front and back double clamping | ||||
| Dust cover equip at the entrance and exit | ||||
| Cutting feeding method: cylinder control | ||||
| Movement way of saw blade: transverse type | ||||
| Cutting precision: ±3mm | ||||
| Dimension: 2100x1800x2000mm | ||||
| Racking for finished products | Roller type | |||
| Dimension: 6000x700x900mm | ||||
| Electrical control system | PLC: Omron | |||
| Intermediate relay: Omron | ||||
| Speed display: Toky | ||||
| Temperature controller: YATAI | ||||
| Switching power supply: Omron | ||||
| MCB: HUYU | ||||
| AC Contactor: HUYU | ||||
| Switches and buttons: HUYU | ||||
| Hydraulic system | Each pulling head is separate hydraulic system | |||
| Rated pressure: 16Mpa | ||||
| Variable piston pump: HSU HONG | ||||
| Motor: HUALI | ||||
| Sealing elements: Hallite | ||||
| Stacked hydraulic change valve NORTHMAN | ||||
| Precise speed regulating valve: YUKEN | ||||
| Pressure regulating valve: NORTHMAN | ||||
