Fire Truck Efficient Fire Extinguishing Truck Motorized Fire Extinguishing Truck
1 Piece
$31,0001 Piece
$38,000Product information
High-quality Fire Truck Efficient Fire Extinguishing Truck Motorized Fire Extinguishing Truck supplied by Hubei Dongmao Special Purpose Vehicle Co., Ltd. Bulk wholesale pricing ranges from $31,000 to $38,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Production Capacity:
1000
Horsepower:
230HP
Drive Wheel:
4×2
HS Code:
5101110001
Package Gross Weight:
5800.000kg
Volume:
7001-10000L
Package Size:
830.00cm * 230.00cm * 280.00cm
Payload:
8t
Specifications
Production Capacity:
1000
Horsepower:
230HP
Drive Wheel:
4×2
HS Code:
5101110001
Package Gross Weight:
5800.000kg
Volume:
7001-10000L
Package Size:
830.00cm * 230.00cm * 280.00cm
Payload:
8t
Transmission Type:
Automatic
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Container
Trademark:
DONGMAO SPECIAL
Fuel:
Diesel
Emission Standard:
Euro 4
Specification:
External dimensions: 8200 x 2500 x 3550 mm
Trade Term:
FOB, CIF, CFR, EXW
Purpose:
Fire Fighting Function
Model NO.:
GTY5180HVH
Method:
High Pressure Water Gun Extinguishes Fire
Certification:
ISO9000, CCC, CE
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Condition:
New
Material:
Q345 High-Strength Manganese Steel
Color:
Red
Type:
Rescue
Process:
Robot Automation
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019-12-26
Annual Revenue Amount:
Not specified
Numbers Of Employees:
30
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
Certificates
Product descriptions from the supplier
| order number | name | unit | quantity | remarks |
| 1 | fire hose | tray | 10 |
|
| 2 | water absorption tube | rice | 8 | |
| 3 | water-strainer | piece | 1 | |
| 4 | Water collector | piece | 1 | |
| 5 | Three points of water | piece | 1 | |
| 6 | Water suction tube wrench | individual | 2 | |
| 7 | Ground fire hydrant wrench | piece | 1 | |
| 8 | Underground fire hydrant wrench | piece | 1 | |
| 9 | The belt bridge | individual | 2 | |
| 10 | Water belt wrapped cloth | piece | 4 | |
| 11 | Water belt hook | piece | 4 | |
| 12 | a firemans axe | piece | 1 | |
| 13 | Iron desperate | piece | 1 | |
| 14 | spade | piece | 1 | |
| 15 | pick hammer | piece | 1 | |
| 16 | Waist axe | piece | 1 | |
| 17 | Different diameter interface | single | 2 | Bubuckle Φ 65 variable Φ 80 |
| 18 | Heterotypic different diameter interface | single | 1 | 150/100 |
| 19 | Switch DC water gun | branch | 1 | |
| 20 | Flower water gun | branch | 1 | |
| 21 | dry-chemical fire extinguisher | With | 1 | 3 kg, ABC dry powder |
- batholith
Engine brand: Yuchai 165 horsepower, Yunnei 170 horsepower
Wheelbase: 3,800 mm
engine type:YCY30165-60,D30TCIF1
Engine power: Yuchai 121 kw, cloud 125 k w
Overall dimension (mm): 6960 * 2200 * 2810
Emission standard: GB3847-2005, GB17691-2018 countries
Drive type: rear-wheel drive
- pilothouse
Seat setting: 2 + 3 people
Equipment: in addition to the original vehicle equipment, equipped with force collector control switch, 100W alarm, rotary alarm light switch, radio station power cable pile head;
The body external charging device, the rear is equipped with air respirator backrest;
- Can
Material: water tank: quality carbon steel, foam tank: quality stainless steel
Structure: Frame welding. Internal fortification swing plate
Equipment: 2 population holes, with quick locking and opening device.
2 liquid level indicators.
2 sewage outlets, with stainless steel ball valve.
2 water injection ports (one for left and right)
- Fire pump and piping system
Flow rate: atmospheric pressure of 30L / s
Pressure: a normal pressure of 1.0
Installation type: rear-position type
pipe system
Water absorption line: the water pump is equipped with Φ100mm water inlet, which can absorb water from the natural water source or from the liquid tank.
Water outlet road:
1 water outlet on each side;
There is an 89mm diameter water gun line through the top of the tank;
Waste water pipe: in order to protect the water pump and each ball valve, the waste water pipe is installed in the pipeline, and respectively equipped with ball valves.
Cooling water line: in order to make the force collector in the work to cope with various complex situations, the line is equipped with a cooling water line inlet and outlet line with stainless steel ball valve.
Foam ratio mixer: ring pump type, 3%~6%
- fire monitor
Flow rate: 30 (1 / s)
Range: 45m of water
Pressure: 1.0MPa
- power takeoff
Cooling mode: forced water cooling type
Lubrication mode: splash-type oil lubrication
- Equipment box and pump room
Structure: the equipment box separation with type steel structure, firm and reliable, improve the space utilization rate and variability.
Open the door: there are aluminum alloy rolling shutter doors on the left and right sides of the equipment box, light and reliable, low noise.
Equipment layout principle
-
- All the equipment is placed to ensure that the team members do not interfere when the battle starts;
- Place the equipment according to the frequency of use and the weight and shape of the equipment;
- Place the equipment according to the logical relationship between the combat arrangement and the equipment use;
- Place the equipment according to the human behavior science.
- Electrical system
The roof is equipped with 24V, 60W lighting 1;
The upper sides of the vehicle are equipped with flashing lights; side sign lights are installed below;
The alarm power is 100W; the alarm, alarm and flash light circuits are independent additional circuits, and the control devices are installed in the cab.
IX. Overall technical requirements
1. The vehicle performance meets the provisions of GB7956 "Fire Engine Performance Requirements and Test Methods".
2, the appearance of the vehicle to maintain a certain flatness, and comply with the relevant regulations.
3, all riveting to maintain a certain density, in line with the provisions of the enterprise standard.
4. All the welding is firm, smooth and smooth, and it is in line with the provisions of the enterprise standard.
5. All operating switches, instruments, equipment racks and vehicles shall have nameplate signs conforming to the specification.
Ten, with the car documents
1) Chassis use instruction manual 2) Chassis quality warranty card
3:3) Chassis maintenance manual: 4) Chassis qualification certificate
5) List of vehicle tools 6) Engine number rubbings
7) Chassis number rubbing; 8) Fire engine operation manual
9) List of fire engine fire fighting equipment 10) Fire engine certificate
11) Fire truck tracking service card 12) Fire protection exchange list
1:What payment methods do you support? - We support T/T and LC and other ways you need.
2:What is your minimum order quantity? - One unit.
3. How about the delivery time? - Generally it will takes 10 to 30 days after receiving your deposit. The sactual date will be depended on your order and item. We will contact you if we confirm the delivery date. And we will track the goods all the time until the goods reach to the destination.
4.How can I confirm whether your products will meet my needs? -You can tell us your needs such as size, material, volume, height and other information, our professional sales will provide solutions.
5. How do you pack the products? - Standard shipping packaging.
6. How about the price? - To provide the top quality product with competitive price is our mission all the time. We want a long-term business relatonship with our customers rather than cooperate for once.
7. How can I trust you? - We have 15 years of experience in the trailer manufacturing field; and we have our own factory. - We have supplied for many famous company at home and abroad; - We want to provide great service for you rather than just provide a price and product for you; - To meet you is the first step, then we would like to make friends and maintain the business relationship with you all the time.
