Fire Truck Remote Fire Extinguishing Truck Forest Fire Extinguishing Truck Prairie Fire Extinguishing Truck
1 Piece
$180,0001 Piece
$120,000Product information
High-quality Fire Truck Remote Fire Extinguishing Truck Forest Fire Extinguishing Truck Prairie Fire Extinguishing Truck supplied by Hubei Dongmao Special Purpose Vehicle Co., Ltd. Bulk wholesale pricing ranges from $120,000 to $180,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Production Capacity:
1000
Package Size:
1330.00cm * 280.00cm * 380.00cm
Package Gross Weight:
13800.000kg
Payload:
25t
HS Code:
5101110001
Horsepower:
560HP
Drive Wheel:
8X4
Transmission Type:
Automatic
Specifications
Production Capacity:
1000
Package Size:
1330.00cm * 280.00cm * 380.00cm
Package Gross Weight:
13800.000kg
Payload:
25t
HS Code:
5101110001
Horsepower:
560HP
Drive Wheel:
8X4
Transmission Type:
Automatic
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Container
Trademark:
DONGMAO SPECIAL
Fuel:
Diesel
Emission Standard:
Euro 4
Specification:
External dimensions: 8200 x 2500 x 3550 mm
Trade Term:
FOB, CIF, CFR, EXW
Purpose:
Fire Fighting Function
Model NO.:
GTY5359YGV
Method:
High Pressure Water Gun Extinguishes Fire
Certification:
ISO9000, CCC, CE
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Condition:
New
Material:
Q345 High-Strength Manganese Steel
Color:
Red
Type:
Rescue
Process:
Robot Automation
Port Of Loading:
Shanghai Port
Payment Methods:
Support payments in USD
Volume:
＞10000L
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019-12-26
Annual Revenue Amount:
Not specified
Numbers Of Employees:
30
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
Certificates
Product descriptions from the supplier
| order Number |
name | unit | quantity | remarks |
| 1 | fire hose | tray | 10 | Φ65 4 Plate Φ80 6 Disc |
| 2 | water absorption tube | rice | 8 | |
| 3 | water-strainer | piece | 1 | |
| 4 | Water collector | piece | 1 | |
| 5 | Three points of water | piece | 1 | |
| 6 | Water suction tube wrench | individual | 2 | |
| 7 | Ground fire hydrant wrench | piece | 1 | |
| 8 | Underground fire hydrant wrench | piece | 1 | |
| 9 | The belt bridge | individual | 2 | |
| 10 | Water belt wrapped cloth | piece | 4 | |
| 11 | Water belt hook | piece | 4 | |
| 12 | a fireman's axe | piece | 1 | |
| 13 | Iron desperate | piece | 1 | |
| 14 | spade | piece | 1 | |
| 15 | pick hammer | piece | 1 | |
| 16 | Waist axe | piece | 1 | |
| 17 | Different diameter interface | single | 2 | Bubuckle Φ 65 variable Φ 80 |
| 18 | Heterotypic different diameter interface | single | 1 | 150/100 |
| 19 | Switch DC water gun | branch | 1 | |
| 20 | Flower water gun | branch | 1 | |
| 21 | dry-chemical fire extinguisher | With | 1 | 3 kg, ABC dry powder |
| 22 | Foam gun | branch | 1 | PQ8 |
| 23 | Foam pipette | branch | 1 |
| order number | name | unit | quantity | remarks |
| 1 | fire hose | tray | 10 |
|
| 2 | water absorption tube | rice | 8 | |
| 3 | water-strainer | piece | 1 | |
| 4 | Water collector | piece | 1 | |
| 5 | Three points of water | piece | 1 | |
| 6 | Water suction tube wrench | individual | 2 | |
| 7 | Ground fire hydrant wrench | piece | 1 | |
| 8 | Underground fire hydrant wrench | piece | 1 | |
| 9 | The belt bridge | individual | 2 | |
| 10 | Water belt wrapped cloth | piece | 4 | |
| 11 | Water belt hook | piece | 4 | |
| 12 | a firemans axe | piece | 1 | |
| 13 | Iron desperate | piece | 1 | |
| 14 | spade | piece | 1 | |
| 15 | pick hammer | piece | 1 | |
| 16 | Waist axe | piece | 1 | |
| 17 | Different diameter interface | single | 2 | Bubuckle Φ 65 variable Φ 80 |
| 18 | Heterotypic different diameter interface | single | 1 | 150/100 |
| 19 | Switch DC water gun | branch | 1 | |
| 20 | Flower water gun | branch | 1 | |
| 21 | dry-chemical fire extinguisher | With | 1 | 3 kg, ABC dry powder |
First, the bottom tray
mould Sinotruk Jinan Truck Co., Ltd. / ZZ5447TXFV466MF5Engine: China Heavy Duty Vehicle Group Co., Ltd. Model: MC11.46-61
Power: 338kW
Drive type: rear-wheel drive
axle Distance: 1950 + 4600 + 1400mm
Emission standard: GB3847-2005, GB17691-2018 country 6
2. pilothouse
bear Structure: flat head, original double row seat four door passenger room. Seat setting: 2 people in front and 4 people in back.Install a guardrail and handrail in front of the seat. On the way to the fire fighting and rescue, the firefighters quickly carried the air breathing apparatus. After arriving at the fire site, they quickly entered the fire fighting and rescue operations.
Cab structure: Install a suitable hydraulic tipping mechanism.
Equipment in the cab: except for the original vehicle equipment, install the force device control switch, 100W alarm, alarm light switch, etc.
Outside the cab: a long row alarm light is installed on the front of the top of the cab.
Three, let jar
hold Quantity: water: 20,900 Kg Foam: 3,824 kgtimber Quality: water tank: high-quality steel plate, through high-tech anti-corrosion treatment
Foam tank: 304 stainless steel plate, with high-tech anticorrosion treatment
bear Structure: frame welding, vertical and horizontal anti-swing plate in the tank to reduce the impact of the water on the tank; the front and rear walls of the tank are broken with trapezoidal bars, so that the tank has sufficient strength and stiffness.
The roof of the tank is equipped with a fast open manhole to facilitate the access of maintenance personnel. The tank is equipped with a device and a filter screen to prevent the pump from absorbing water and forming a vortex, thus affecting the flow rate.
The tank is equipped with a stainless steel floating ball level indicator, which can show the capacity of the fire extinguishing agent in the tank through the level table on the instrument panel; the sewage outlet with ball valve at the bottom of the tank has two 76mm overflow pipes and two 76mm injection ports on each side of the car to facilitate water supply and liquid for other vehicles.
set up Preparation: 2 population holes, with quick locking and opening device.
2 liquid level indicators.
2 sewage outlets, with stainless steel ball valve.
4 water injection outlets (left and right)
Process: conduct firm and reliable welding, remove defects such as slag clamp and deficiency welding; conduct 24-hour hydrostatic test after welding to ensure no leakage.
4. Fire pump and piping system
Fire pump: CB 20.10/40.80 medium and low pressure fire pump (Shanghai Rongshen) flow Quantity: 40 / 80L / spress Force: 1.7MPa (2.0MPa-1.0MPa)
Installation type: rear vacuum pump: piston type;
Vacuum pump material: wear resistance, corrosion resistance to meet the sealing requirements;
Water diversion time is 80s, and the suction depth is 7m. Maximum vacuum degree: 85 kPa;
pipe system
Water suction line: the pump is equipped with Φ 150mm water inlet, which can absorb water from natural water source, liquid tank, fire reservoir, and can be added to connect the fire hydrant water supply, water suction pipe is placed on the roof.1 water inlet with Φ150mm butterfly valve for connection to the water tank.
Water outlet road:
The roof is equipped with a Φ100mm water outlet fire gun pipeline and control valve, using a flexible joint;
1 Φ80mm and 1 Φ65mm manual ball valve controlled outlet are provided on the left and right sides of the pump room. Water injection pipeline: 1 Φ65mm pump water injection pipeline and control valve into the tank;
There is 1 Φ 80mm water injection port on the left and right sides of the front of the car, and 2 Φ 80mm water injection ports on the left and right sides of the car, which can be injected into the tank. The interface is internal buckle interface, with Φ 80mm to Φ 65mm and conversion joint.
Waste water pipe: in order to protect the water pump and each ball valve, the waste water pipe is installed in the pipeline, and respectively
Equipped with ball valve.
Cooling water pipeline: in order to make the force collector cope with various complex situations, it is equipped with a cooling water pipeline and control valve connected with the inlet and outlet water pipe.
5. Remote control fire gun
mould No.: Type P LKD 8 / 80 fire gun (West) flow Quantity: 80 (1 / s)shoot Cheng: The water is 70m Foam at 65m pressure Force: 1.0MPa
Position Set: on top of the water tank.
accuse System: using remote control control, convenient operation.
Six, force collector
mould Formula: full power sandwich force collector cooling mode: forced water coolingLubrication mode: splash-type oil lubrication
Operation mode: the force collector is operated at the instrument panel in the cab, which is convenient and smooth.peaceful Installation: the force collector matches well with the engine, it is accurately installed, and there is no self-shedding phenomenon after the combination.
Seven, pump room
Main material:The skeleton and skin are high quality carbon steel; the interior panel is oxidized aluminum plate.fundamental structure:
1, for the overall structure, the front for the water tank, the back for the pump room.
2. The rear is the pump room, equipped with instrument panel and operating system, and the pump room is equipped with locked shutter door. Frame solds the structure and ensures its strength and stiffness.
3. The pump room is equipped with lighting lights to meet the lighting needs of fire fighting at night. Aluminum alloy rolling shutter door:
1, the pump room with lock rolling shutter door, handle and lock pin durable, no deformation, sealing performance after water shower experiment, to ensure that no leakage phenomenon.
2. There are rivets in the slide on both sides of the shutter door so as to avoid falling off.
3. There are lights in each equipment box, which is controlled by the opening and closing of the rolling shutter door.
4, the rear left and right are equipped with aluminum alloy curtain door, a rear tail, safe and reliable, beautiful and practical.fundamental principle:
(1) Integration of design equipment according to combat composition and combat operation;
(2) Design various equipment brackets according to the ergonomic principle;
(3) No need for any climbing tools, take any of the equipment in the box.
(4) Place the equipment according to the logical relationship and frequency of use;
(5) Stand on the ground or on the pedal in the 1-2 action to take any equipment.
Eight, electrical system
1. The top of the cab is equipped with a red long row of luxury alarm lights.
2. The power of the alarm is 100W;
3. In order to ensure the safety of the use, the whole vehicle line is made of the overall wiring harness, and the waterproof plug is used at the connection point to ensure the safety of the line in the process of use.
4. The roof is equipped with 1 fire lighting lamp; safety sign lights below the two sides of the vehicle, and reflective signs are pasted on the body and tail according to the standard.
5. All equipment boxes are installed with LED lights to facilitate night combat lighting.
6. On both sides of the vehicle are equipped with four flashing lights and side lights (combination), safety sign lights and side reflector (combination), equipped with front and rear profile lights, one turn signal on each side, and lights in the passenger room, equipment box and pump room.
7, alarms, alarm lights, strobe lights, circuits are independent additional circuits, control devices are installed in the cab.
8. All lines are protected by casing, and different colors are used to distinguish the connection form and function.
9. Equipment on the instrument panel in the pump room: liquid level gauge, tachometer, pressure gauge, vacuum gauge, equipment box lighting switch, etc.
IX. Instrument panel and on-board equipment
1. The instrument panel is located in the pump room at the rear end of the car, with a control board and sufficient lighting;2, all control handles, switches, indicators near the Chinese logo;
3, there are operation steps description.
4. All signs are persistent and high attachment, and can withstand the effects of temperature and climate.
5, the operation panel uses high quality aluminum plate, beautiful, durable, the overall weight is light.
6. The operating system of the pump room is set at the rear of the vehicle, without pressure outlet, to ensure the safety of the operator, and there are panel lights.
X. Overall technical requirements
1. The vehicle performance meets the provisions of GB7956 "Fire Engine Performance Requirements and Test Methods".2, the appearance of the vehicle to maintain a certain flatness, and comply with the relevant regulations.
3, all riveting to maintain a certain density, in line with the provisions of the enterprise standard.
4. All the welding is firm, smooth and smooth, and it is in line with the provisions of the enterprise standard.
5. All operating switches, instruments, equipment racks and vehicles shall have nameplate signs conforming to the specification.
Xi. Vehicle documents
1) Chassis instruction insert 2) chassis quality warranty card3) Chassis maintenance manual 4) Chassis qualification certificate
5) List of onboard tools 6) Engine number rubbings
7) Chassis number rubbing parts 8) Fire engine operating manual
9) List of fire fighting equipment 10) Fire engine qualification certificate
1:What payment methods do you support? - We support T/T and LC and other ways you need.
2:What is your minimum order quantity? - One unit.
3. How about the delivery time? - Generally it will takes 10 to 30 days after receiving your deposit. The sactual date will be depended on your order and item. We will contact you if we confirm the delivery date. And we will track the goods all the time until the goods reach to the destination.
4.How can I confirm whether your products will meet my needs? -You can tell us your needs such as size, material, volume, height and other information, our professional sales will provide solutions.
5. How do you pack the products? - Standard shipping packaging.
6. How about the price? - To provide the top quality product with competitive price is our mission all the time. We want a long-term business relatonship with our customers rather than cooperate for once.
7. How can I trust you? - We have 15 years of experience in the trailer manufacturing field; and we have our own factory. - We have supplied for many famous company at home and abroad; - We want to provide great service for you rather than just provide a price and product for you; - To meet you is the first step, then we would like to make friends and maintain the business relationship with you all the time.
