Flex Plus Fast MP Delivery Flex PCB with One Stop Service in China
1 Piece
$0.081 Piece
$10Product information
High-quality Flex Plus Fast MP Delivery Flex PCB with One Stop Service in China supplied by Flex Plus(Xiamen) Co., Ltd. Bulk wholesale pricing ranges from $0.08 to $10 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Package Gross Weight:
1.000kg
Production Capacity:
100kpcs/Week
Sample Delivery:
3~5days
Package Size:
50.00cm * 50.00cm * 50.00cm
MP Delivery:
7~10days
HS Code:
85340090
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Package Gross Weight:
1.000kg
Production Capacity:
100kpcs/Week
Sample Delivery:
3~5days
Package Size:
50.00cm * 50.00cm * 50.00cm
MP Delivery:
7~10days
HS Code:
85340090
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Application:
Consumer Electronics
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Material:
Copper
Base Material:
Copper
Specification:
Customized
Processing Technology:
Electrolytic Foil
Insulation Materials:
Epoxy Resin
Trade Term:
FOB, EXW, CIF, DDP, DAP, CPT, FCA
Brand:
Flex Plus
Trademark:
Flex Plus
Payment Term:
LC, T/T
Copper Thickness:
Max 5oz
Length:
Max. 4m (XL Exposure Machine)
Line Width:
Min 0.05mm
Model NO.:
Rigid PCB
Payment Methods:
Support payments in USD
Flame Retardant Properties:
V0
Transport Package:
Vacuum Package with Foam Protection & Carton
Port Of Loading:
Xiamen
Color:
Yellow
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2004-08-02
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, EXW, CIF, DDP, DAP, CPT, FCA
Port Of Loading:
Xiamen
Certificates:
ISO14001, Others, ISO9001:2015
Product descriptions from the supplier
SONA2024 2.2.1
Q5: What kinds of PCB file format can you accept for production?
A: Gerber, protel 99SE, protel DXP, CAM350, ODB+(.TGZ)
Q6: What test methods do you provide?
A: The FPCBs will go through 100% AOI, 100% E test, X-ray, Default circuit testing, Reliability testing in regular, and more testing as customer required.
Company Profile
Established in 2004, Flex Plus (Xiamen) Co., Ltd. is dedicated in high-quality & cost effective flexible printed circuit board (Flex PCB) R&D, manufacturing and sales. To effectively respond to the technological expectations of its customers and satisfy the different market needs,Flex Plusis able to offer a wide and complete range of products ranging from printed circuits with standard characteristics to highly complex ones. Including Single-sided FPCBs, Double-sided Flex PCBs, Multi-layer FPC, Rigid-Flex PCB, Dual-access FPCBs (bare backed Flex PCB), new innovation TPU Circuits etc.
To assure stable and reliable quality and better serving customers, Flex Plus continually improve the quality management and we have passed ISO9001:2005 certified and obtained the certificate approval IATF16949 & ISO 13485:2016. Flex plus as a brand enterprise, when creating enterprise profit at the same time paid more attention on the social management and environmental protection, we have obtained UL certificate and IS014001:2015.
By years of effort, Flex Plus flex PCBs are widely used in the field of Medical and Health, Automotive Electronics, Communication Equipment, Mobile Phone Precision Modules, Hearing Aids and other scientific and technological fields, and has earned the trust of over 2,500 customers in the worldwide, especially in North American, European, Japan, South East Asia and China. Flex Plus is increasingly called upon by customers to become a partner in the development of solutions that achieve this objective. Especially if they are non-standard solutions.
Capability
Item | Description |
Layer | Flex board: 1-12 Layers Flex-Rigid Board: 2-22 Layers |
Base Material | Pl, PET, PEN, FR-4 |
Final Thickness | Flex board:0.002''-0.032'' (0.05-0.8mm) Flex-rigid board:0.0024''-0.04'' (0.06-1.0mm) |
Surface Treatment | Lead-Free: Gold Plating, ENIG Gold, OSP, Immersion Tin, Tin Plating |
Max Size | Width: 500mm Length: 4000mm |
Min Trace Width / Min Clearance | Inner: 1/2oz:3/3mil1oz:4/4mil2oz:5/6mil Outer:1/3oz-0.5oz:4/4mil1oz:4/4mil2oz:5/6mil |
The smallest via diameter Hole PAD ( Flex Board 2L-6L) | 2mil / 12mil |
The smallest via diameter Hole PAD ( Rigid Flex Board 2L-6L) | 8mil / 24mil |
Copper Thickness | 1/7oz - 8oz |
Max/Min insulation Thickness | PI:2mil/0.5mil (50um/12.5um)PET:10mil/1mil (250um/25um) |
Min Hole Size and Tolerance | Min hole:6milTolerance:PTH±3mil, NPTH±2mil |
Min Slot | 20mil x 30mil |
Circuit trace to outline (1L~2L) | 6mil |
Circuit trace to outline (>=3L) | 8mil |
Solder Mask Alignment Tolerance | ±4mil |
Silkscreen Alingment Tolerance | ±6mil |
Silkscreen Line Width | 5mil |
Gold Plating | Nickel: 80u''-320u'' Gold: 1u''-6u'' |
Immersion Nickel / Gold | Nickel: 80u''-300u'' Gold: 1u''-3u'' |
Tin Plating | Film: 40u''-600u'' |
Immersion Tin | Film: 8u''-20u'' |
OSP | Film: 1u''-3u'' |
Test Voltage | Testing Fixture: 50-300V |
Profile Tolerance of Punch | Accurate mould: ±2mil Ordinary mould: ±4mil Knife mould: ±6mil |
Applied Materials | ||
Copper foil | Copper type: ED, RA, HA | 1/3oz. 1/2oz, 1oz, 2oz. etc. |
Base material: PI/PET | 1/2mil, 1mil, 2mil, etc. | |
With adhesiveless/ adhesive-free | 13µm, 20µm | |
Coverlay | Base material: PI/PET/PET | 1/2mil, 1mil, 2mil, etc. |
Adhesive thickness | 15µm, 25µm, 35µm, etc. | |
Solder mask | Green/ White/ Yellow/ Back | 15µm-25µm |
Stiffener | PI(polyimide) | 2mil, 3mil, 7mil, 8mil, etc. |
PET(polyester) | 100µm, 188µm, etc. | |
FR4/ Copper/ Aluminum etc. | Copper sheets:0.1mm, 0.2mm, 0.3mm, 0.4mm, 1.6mm, etc. Aluminum sheets:0.5mm, 1.0mm, 1.6mm, 2.0mm | |
Double sided adhesive/adhesive only | Pressure senstive adhesive, Heat-press type | 30µm, 50µm, 75um, etc. |
Production Workflow
Certifications
ISO13485, IATF16949, ISO14001, ISO9001, UL
Main Customer
Packaging & Shipping
FAQ
Q1: What is needed for quotation?
A: For Flexible PCB, we need quantity, Gerber file and Technic requirements (material, surface finish treatment, copper thickness, board thickness, ...)
For Flex PCB Assembly: we need Flex PCB information, BOM, (Testing documents...)
A: For Flexible PCB, we need quantity, Gerber file and Technic requirements (material, surface finish treatment, copper thickness, board thickness, ...)
For Flex PCB Assembly: we need Flex PCB information, BOM, (Testing documents...)
Q2. Do you have MOQ?
There is no MOQ in Flex PCB. We are able to handle Small as well as large volume production with flexibility.
There is no MOQ in Flex PCB. We are able to handle Small as well as large volume production with flexibility.
Q3: How soon can i expect a response for my RFQs request ?
A: We will respond to your quotation within 24 hours.
A: We will respond to your quotation within 24 hours.
Q4: Are my files safe?
A:Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.
A:Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.
Q5: What kinds of PCB file format can you accept for production?
A: Gerber, protel 99SE, protel DXP, CAM350, ODB+(.TGZ)
Q6: What test methods do you provide?
A: The FPCBs will go through 100% AOI, 100% E test, X-ray, Default circuit testing, Reliability testing in regular, and more testing as customer required.
Q7:What is the delivery time?
As Normal: 5-10 working days for samples, 10-35working days for bulk production depends on order quantity and forecast order provided.
For Urgent project, We can arrange preferential processing and control the delivery time as you request
As Normal: 5-10 working days for samples, 10-35working days for bulk production depends on order quantity and forecast order provided.
For Urgent project, We can arrange preferential processing and control the delivery time as you request
Q8: What is standard shipping time?
A: It's about 3-7 working days shipping by DHL, FEDEX, UPS, or by Ocean shipping.
A: It's about 3-7 working days shipping by DHL, FEDEX, UPS, or by Ocean shipping.
