Fluke Tis20+ 9 Hz Thermal Camera
1-89 Set
$2,19990 Set
$2,166Product information
High-quality Fluke Tis20+ 9 Hz Thermal Camera supplied by Shenzhen HOBOY Instruments Co., Ltd.. Bulk wholesale pricing ranges from $2,166 to $2,199 per Set with a minimum order of 1 Set. Inquiry for latest prices.
Temperature Measurement Range:
-4 to 302°f (-20 to 150°c)
Infrared Resolution:
120 X 90 (10, 800 Pixels)
Package Gross Weight:
3.000kg
Display Resolution:
320 X 240 LCD
Lead Time:
4 days (1 - 100 Sets)To be negotiated ( > 100 Sets)
Specification:
45*36*33cm
Package Size:
45.00cm * 25.00cm * 30.00cm
Production Capacity:
50, 000 Pieces/Year
Specifications
Temperature Measurement Range:
-4 to 302°f (-20 to 150°c)
Infrared Resolution:
120 X 90 (10, 800 Pixels)
Package Gross Weight:
3.000kg
Display Resolution:
320 X 240 LCD
Lead Time:
4 days (1 - 100 Sets)To be negotiated ( > 100 Sets)
Specification:
45*36*33cm
Package Size:
45.00cm * 25.00cm * 30.00cm
Production Capacity:
50, 000 Pieces/Year
HS Code:
9031499090
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trademark:
FLUKE
Trade Term:
FOB, CIF, CFR, EXW
Focus System:
Fixed Focus
Model NO.:
Fluke TiS20+ 9 Hz
Spot Temperature:
Hot and Cold Spot Markers
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Operate Method:
Manual
Data Transfer:
Mini USB Used to Transfer Image to PC
Port Of Loading:
Shenzhen Port
Payment Methods:
Support payments in USD
Transport Package:
UPS/DHL/FedEx
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2025-03-25
Annual Revenue Amount:
Not specified
Numbers Of Employees:
2
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port
Product descriptions from the supplier
Easy-to-use and built to withstand harsh working conditions, this thermal imager is an ideal tool for electricians, HVAC/R, and maintenance technicians. With an infrared resolution of 120 x 90 (10,800 pixels) and a frame rate of 9 Hz, this camera can measure temperatures ranging between -4 to 302°F (-20 to 150°C).
120x90 Thermal Imager; 9 HZ
- 9Hz thermal imager
- Save time with the right level of infrared and analysis
- Continuous touchscreen IR-Fusion, slide your finger across the screen to adjust the setting
- 120 x 90 infrared resolution (10,800 pixels)
- 3.5" LCD touchscreen display for easy troubleshooting
- Automatically sort images with Fluke Connect Asset Tagging
- Can withstand drop up to 2 meters
- Water and dust resistant - IP54 enclosure rating
- IR-Fusion technology combines visible and infrared images for faster inspections and better reporting
- Compatible with Fluke Connect
Fluke TiS20+ 9 Hz Thermal Camera
9Hz thermal imager
- Save time with the right level of infrared and analysis
- Continuous touchscreen IR-Fusion, slide your finger across the screen to adjust the setting
- 120 x 90 infrared resolution (10,800 pixels)
- 3.5" LCD touchscreen display for easy troubleshooting
The Fluke TiS20+ is an easy to use thermal camera with very good image quality for everyday use. This camera is designed to make your job easier and quicker by empowering you to point, shoot, sort, and fix issues on the spot.
Save time with the right level of infrared and analysis
- Continuous touchscreen IR-Fusion, slide your finger across the screen to adjust the setting.
- 120 x 90 infrared resolution (10,800 pixels)
- 3.5" LCD touchscreen display for easy troubleshooting
- Automatically sort images with Fluke Connect Asset Tagging
| Key Specifications | |
| Infrared Resolution | 120 x 90 (10,800 pixels) |
| IFOV (Spatial Resolution) | 7.6 mRad, D:S 130:1 |
| Field of View | 50 x 38° |
| Minimum Focus Distance | 20" (50 cm) |
| Focus System | Fixed focus |
| Data Transfer | Mini USB used to transfer image to PC |
| Wireless Connectivity | Yes, (802.11 b/g/n (2.4 GHz)) |
| Fluke Connect Instant Upload | Yes, connect your camera to your building's WiFi network (802.11 b/g/n (2.4 GHz)), and images taken automatically upload to the Fluke Connect system or your local server for storage and viewing on your PC |
| Image Quality | |
| Display | 3.5" LCD touchscreen (landscape) |
| Display Resolution | 320 x 240 LCD |
| Level and Span | Smooth auto and manual scaling |
| IR-Fusion Technology | AutoBlend continuous 0 to 100%. Adds the context of the visible details to your infrared image |
| Thermal Sensitivity (NETD) | 60 |
| Frame Rate | 9 Hz |
| Data Storage and Image Capture | |
| Memory | Internal 4GB memory |
| Image Capture, Review, Save Mechanism | One-handed image capture, review, and save capability |
| Image File Formats | Non-radiometric (jpeg), or fully radiometric (.is2); no analysis software required for non-radiometric (jpeg) files |
| Software | Fluke Connect desktop software - full analysis and reporting software with access to the Fluke Connect system |
| Export File Formats with Software | .bmp, .dib, .jpg, .tif, .tiff |
| Temperature Measurement | |
| Temperature Measurement Range (Not Calibrated Below 0°C) |
-4 to 302°F (-20 to 150°C) |
| Accuracy | Target temperature at or over 32°F: Accuracy: ±35.6°C or ±2% at 77°C, whichever is the greater Target temperature at or over 0°C: Accuracy: ±2°C or ±2% at 25°C, whichever is the greater |
| On-Screen Emissivity Correction | Yes, material table |
| On-Screen Reflected Background Temperature Compensation | Yes |
| Center-Point Temperature | Yes |
| Spot Temperature | Hot and cold spot markers |
| Color Palettes | |
| Standard | 6: Ironbow, blue-red, high contrast, amber, hot metal, grayscale |
| General Specifications | |
| Temperature | Operating: 14 to 122°F (-10 to 50°C) Storage: -40 to 158°F (-40 to 70°C) |
| Relative Humidity | 95% non-condensing |
| Infrared Spectral Band | 8 to 14 μm (long wave) |
| Safety | IEC 61010-1: Pollution Degree 2 |
| Electromagnetic Compatibility | EN 61326-1, CISPR 11: Group 1, Class A |
| US FCC | CFR, Part 15C |
| Vibration and Shock | 10 to 150 Hz, 0.15 mm, IEC 60068-2-6; 30 g, 11 ms, IEC 60068-2-27 |
| Drop | Engineered to withstand 6.56' (2 m) drop |
| Battery | Type: Lithium ion smart battery pack with five-segment LED display to show charge level Life: ≥5 hours continuous (without WiFi) Charging time: 2.5 hours to full charge AC operation: AC operation with included power supply (100 to 240 V AC, 50/60 Hz) Power saving: Automatic shutdown: 5, 10, 15 and 20 minutes or never |
| Enclosure Rating | IP54 (protected against dust, limited ingress; protection against water spray from all directions) |
| Supported Languages | Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish |
| Dimensions | 10.5 x 4.0 x 5.7" (26.7 x 10.1 x 14.5 cm) |
| Weight | 1.6 lbs (0.72 kg) |
