Four Column Hydraulic Press with Customized Specifications
1 Piece
$20,0001 Piece
$10,000Product information
High-quality Four Column Hydraulic Press with Customized Specifications supplied by Shanghai YingXin World Machinery Co., Ltd.. Bulk wholesale pricing ranges from $10,000 to $20,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Y32 100 Press:
100 Ton Hydraulic Press
Package Gross Weight:
10000.000kg
Production Capacity:
3000PCS/Year
Package Size:
450.00cm * 200.00cm * 200.00cm
HS Code:
84295212
After Sales Service:
Available
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Y32 100 Press:
100 Ton Hydraulic Press
Package Gross Weight:
10000.000kg
Production Capacity:
3000PCS/Year
Package Size:
450.00cm * 200.00cm * 200.00cm
HS Code:
84295212
After Sales Service:
Available
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Open Height:
Customized
Customized:
Customized
Trade Term:
FOB, CFR, CIF, EXW
Type:
Four-Column Hydraulic Press
Certification:
ISO9001, CE
Payment Term:
LC, T/T, Western Union
Condition:
New
Port Of Loading:
Shanghai
Payment Methods:
Support payments in USD
Trademark:
WORLD
Model NO.:
YW32
Specification:
ce iso
Transport Package:
in Container
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2008-01-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, Western Union
Preferred Trade Term:
FOB, CFR, CIF, EXW
Port Of Loading:
Shanghai
Certificates:
400ton straight side double crank press ce certificate, ce, ce certificate for construction machinery as loader and excavators, CE certificate of excavators, CE certificate of power press, CE certificate of wheel loaders, ce for h frame single crank press 160ton, CE of power press, excavators noise testing report by reputable 3rd party, GOST-R, GOST-R certificate of wheel loaders, iso, ISO certificate, JW31-200 straight side press ce certificate, noise testing report for 3ton wheel loader, noise testing report for 5ton loader, sgs certificate for construction machinery plant, sgs certificate for power press plant
Product descriptions from the supplier
four column hydraulic press with customized specifications
Features:
1) Computer optimized design, 3-beam, 4-column structure, simple but with high performance price ratio.
2) Cartridge valve integral unit equipped for hydraulic control system, reliable, durable and less hydraulic shock, with shorter connection pipeline and fewer releases points.
3) Independent electrical control, reliable, audio-visual and convenient for maintenance.
4) Centralized button control system,with adjustment and semi-auto operation modes at operator's choice.
5) Fixed stroke forming process or fixed pressure forming process selected through control panel, with pressure hold and time delay functions.
6) The operating force, no-load traveling and, low-speed movement and travel range can be adjusted subject to technological requirements.
Specifications
| MODEL | YW32-100 | YW32-160 | YW32-200 | YW32-315 | YW32-400 | ||
| Capacity | kN | 1000 | 1600 | 2000 | 3150 | 4000 | |
| Ejecting Force | kN | 400 | 400 | 400 | 500 | 630 | |
| Return Force | kN | 200 | 320 | 360 | 630 | 750 | |
| Slide Stroke | mm | 600 | 700 | 700 | 800 | 800 | |
| Ejecting Stroke | mm | 200 | 250 | 250 | 300 | 300 | |
| Max. Shut Height | mm | 900 | 1000 | 1100 | 1300 | 1500 | |
| Slide Speed | Idle Stroke | mm/s | 120 | 120 | 120 | 100 | 100 |
| Pressing | mm/s | 11 | 11 | 11 | 8-12 | 8-12 | |
| Return | mm/s | 110 | 110 | 110 | 80 | 80 | |
| Ejecting Speed | Eject | mm/s | 60 | 60 | 60 | 60 | 60 |
| Return | mm/s | 100 | 100 | 100 | 80 | 80 | |
| Bolster Size | LR | mm | 720 | 720 | 720 | 1260 | 2000 |
| FB | mm | 580 | 580 | 580 | 1200 | 1500 | |
| Main Motor Power | kW | 7.5 | 11 | 15 | 22 | 22 | |
| MODEL | YW32-500C | YW32-500D | YW32-630A | YW32-630B | YW32-800 | ||
| Capacity | kN | 5000 | 5000 | 6300 | 6300 | 8000 | |
| Ejecting Force | kN | 1000 | 1000 | 2000 | 2000 | 2500 | |
| Return Force | kN | 1250 | 1250 | 1250 | 1250 | 1500 | |
| Slide Stroke | mm | 1200 | 800 | 1000 | 900 | 1200 | |
| Ejecting Stroke | mm | 350 | 300 | 400 | 300 | 350 | |
| Max. Shut Height | mm | 1500 | 1500 | 1600 | 1500 | 1800 | |
| Slide Speed | Idle Stroke | mm/s | 200 | 220 | 200 | 200 | 200 |
| Pressing | mm/s | 8-20 | 8-20 | 7-20 | 6-15 | 6-15 | |
| Return | mm/s | 100 | 120 | 150 | 150 | 120 | |
| Ejecting Speed | Eject | mm/s | 60 | 80 | 80 | 60 | 60 |
| Return | mm/s | 100 | 100 | 100 | 100 | 100 | |
| Bolster Size | LR | mm | 2800 | 2700 | 2800 | 2200 | 3000 |
| FB | mm | 1800 | 1400 | 1800 | 1500 | 2200 | |
| Main Motor Power | kW | 44 | 44 | 60 | 44 | 90 | |
