Galvanized Metal/Steel 7m Traffic Light Poles with Factory Price
2 Piece
$282 Piece
$288Product information
High-quality Galvanized Metal/Steel 7m Traffic Light Poles with Factory Price supplied by Yangde Electric Group Co., Ltd.. Bulk wholesale pricing ranges from $28 to $288 per Piece with a minimum order of 2 Piece. Inquiry for latest prices.
Package Gross Weight:
150.000kg
Specification:
2M/4M/6M/8M/10M/12M
Shaft Thickness:
3-12mm
Wind Speed:
30m/S
Production Capacity:
5000 Piece/Pieces Per Month
Package Size:
700.00cm * 40.00cm * 40.00cm
HS Code:
7308900000
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Package Gross Weight:
150.000kg
Specification:
2M/4M/6M/8M/10M/12M
Shaft Thickness:
3-12mm
Wind Speed:
30m/S
Production Capacity:
5000 Piece/Pieces Per Month
Package Size:
700.00cm * 40.00cm * 40.00cm
HS Code:
7308900000
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shaft Shape:
Conical/Octagonal/Polygonal
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Anchor Bolts:
Customized
Flange Plate:
Customized
Arm Bracket:
Customized
Material Standard:
En 10025
Welding Standard:
En 1011
Coating Standard:
En 40
Design Standard:
En 40-5
Galvanizing Standard:
En ISO 1461
Trade Term:
FOB, CIF, CFR, EXW
Transport Package:
Felt Cloth
Quality Management System:
ISO 9001:2008
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Trademark:
Quicklite
Type:
Round
Port Of Loading:
Shanghai Port
Material:
Steel
Payment Methods:
Support payments in USD
Model NO.:
YD-DG-X
Origin:
Yangzhou Jiangsu
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE led lamp, CE lighting pole, CE solar street light, ISO 9001
Product descriptions from the supplier
TECHNICAL PARAMETER SHEET
|
OCTAGONAL POLES - STANDARD SPECIFICATIONS |
||||||||||
|
Height (m) |
Top Diameter (mm) |
Bottom Diameter (mm) |
Shaft Thick (mm) |
Base Plate |
Foundation Bolt |
|||||
|
Dimensions (mm) |
Yield Stress (N/mm²) |
J-Bolt (mm) |
Yield Stress (N/mm²) |
Pitch Circle Diameter (mm) |
Bolt Length (mm) |
Projected Bolt Length (mm) |
||||
|
3 |
70 |
130 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
450 |
80 |
|
4 |
70 |
130 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
450 |
80 |
|
5 |
70 |
130 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
600 |
80 |
|
6 |
70 |
130 |
3 |
220*220*12 |
345 |
4-M20 |
280 |
205 |
600 |
100 |
|
7 |
70 |
130 |
3 |
220*220*14 |
345 |
4-M20 |
280 |
205 |
700 |
100 |
|
8 |
70 |
135 |
3 |
225*225*16 |
345 |
4-M20 |
280 |
210 |
750 |
100 |
|
9 |
70 |
155 |
3 |
260*260*16 |
345 |
4-M24 |
280 |
250 |
750 |
125 |
|
10 |
70 |
175 |
3 |
275*275*20 |
345 |
4-M24 |
280 |
270 |
750 |
125 |
|
11 |
90 |
210 |
3 |
300*300*20 |
345 |
4-M24 |
280 |
300 |
850 |
125 |
|
12 |
90 |
240 |
3 |
320*320*20 |
345 |
4-M24 |
280 |
325 |
850 |
125 |
|
CONICAL POLES - STANDARD SPECIFICATIONS |
||||||||||
|
Height (m) |
Top Diameter (mm) |
Bottom Diameter (mm) |
Shaft Thick (mm) |
Base Plate |
Foundation Bolt |
|||||
|
Dimensions (mm) |
Yield Stress (N/mm²) |
J-Bolt (mm) |
Yield Stress (N/mm²) |
Pitch Circle Diameter (mm) |
Bolt Length (mm) |
Projected Bolt Length (mm) |
||||
|
3 |
75 |
105 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
450 |
80 |
|
4 |
75 |
115 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
600 |
80 |
|
5 |
75 |
125 |
3 |
200*200*12 |
240 |
4-M16 |
280 |
200 |
600 |
80 |
|
6 |
75 |
135 |
3 |
225*225*12 |
345 |
4-M20 |
280 |
210 |
600 |
100 |
|
7 |
75 |
145 |
3 |
240*240*12 |
345 |
4-M20 |
280 |
235 |
700 |
100 |
|
8 |
75 |
155 |
3 |
240*240*14 |
345 |
4-M20 |
280 |
235 |
750 |
100 |
|
9 |
75 |
165 |
3 |
275*275*16 |
345 |
4-M24 |
280 |
270 |
850 |
125 |
|
10 |
75 |
175 |
3 |
275*275*16 |
345 |
4-M24 |
280 |
270 |
850 |
125 |
|
11 |
85 |
195 |
3 |
300*300*16 |
345 |
4-M24 |
280 |
300 |
850 |
125 |
|
12 |
96 |
216 |
3 |
320*320*16 |
345 |
4-M24 |
280 |
300 |
850 |
125 |
Why our poles?
One-stop Service
You can find solutions for almost all outdoor lighting from us, like street lighting, square lighting, landscape lighting, traffic lighting and commercial lighting and so on.
Vertically Integrated Production System
You will enjoy high-quality product with cost-effective price from us because we manufacture most of the main components from LED source, light fixture, solar panel, pole and even painting powder to control the cost and quality.
15 Years Manufacturing Experience
Since 2012, we have started manufacturing street lighting. The 10 years' experiences have been a persuasive insurance for us to offer reliable products.
Large Factory with Complete Facility
We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .
Advanced Technology
Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand LUYOU.
Cost Efficiency
Manufacturing main components to save cost. YANGDE ELECTRIC manufactures the solar panel, light fixture and pole to control the cost and quality.
